MRC LCEN-401P User manual

LCEN-401P
PLEASE READ THIS MANUAL CAREFULLYBEFORE OPERATION
Hagavish st. Israel 58817 Tel: [phone], Fax: [phone] [email protected]
MRC.2.22
PRP/PRF/CGF CENTRIFUGE

Contents
Safety Reminder.............................................................................................................................................1
1. Intended use ...........................................................................................................................................3
2. Specifications.............................................................................................................................................3
3. Declaration of Conformity .........................................................................................................................4
4. Required Operational Conditions...............................................................................................................4
4.1 Basic operational conditions ............................................................................................................4
4.2 Transport and storage conditions......................................................................................................4
5. Installation..................................................................................................................................................5
5.1 Location............................................................................................................................................5
5.2 Connection of the power cord and grounding..................................................................................5
6. Structure.....................................................................................................................................................6
8. Rotor Preparation.......................................................................................................................................7
8.1 Prepare the samples..........................................................................................................................7
8.2 Inject the samples into tubes ............................................................................................................7
8.3 Keep the tubes balanced...................................................................................................................8
8.4 Inspect the rotor................................................................................................................................8
8.5 Symmetrically load centrifuge tubes into rotor................................................................................8
9. Operation....................................................................................................................................................8
9.1 Normal operation..............................................................................................................................8
9.2 RCF operation................................................................................................................................ 11
9.3 Reset............................................................................................................................................... 11
10. Maintenance...........................................................................................................................................11
10.1 Cleaning ....................................................................................................................................... 11
10.2 Rotor Installation..........................................................................................................................12
11. Troubleshooting......................................................................................................................................13
11.1 Possible problems and solutions...................................................................................................13
11.2 How to open the door...............................................................................................................14
12. Instructions for the rotor and tubes.........................................................................................................14
12.1 Rotor instructions.........................................................................................................................15
12.2 Tubes............................................................................................................................................16
13. Calculate RCF........................................................................................................................................17
14. Returning and Disposal..........................................................................................................................17
14.1 Returning Devices........................................................................................................................17
14.2 Disposal........................................................................................................................................18
15．Warranty...............................................................................................................................................18
15.1 Warranty of centrifuge..................................................................................................................18
15.2 Warranty of the rotor....................................................................................................................18
After-sales service........................................................................................................................................18

1
Safety Reminder
Common safety precautions
Carefully read the following safety precautions for a thorough understanding.
⚫Follow the instructions and procedures described in this manual to operate this centrifuge safely.
⚫Carefully read all safety messages in this manual and the safety instructions on the centrifuge.
⚫Safety messages are labeled as indicated below. They are in combination with signal words of
“WARNING” and “CAUTION” with the safety alert symbol to call your attention to items or
operations that could be dangerous to you or other persons using this centrifuge. The definitions of
signal words are as follows:
WARNING：Personal Danger
Warning notes indicate any condition or practice, which if not strictly observed, could result in personal
injury or possible death.
CAUTION：Possible damage to centrifuge
Caution notes indicate any condition or practice, which if not strictly observed or remedied, could result in
damage or destruction of the centrifuge.
NOTE：Notes indicate an area or subject of special merit, emphasizing either the product’s capability or
common errors in operation or maintenance.
⚫Do not operate the centrifuge in any manner not described in this User Manual. When in doubt or
have any troubles with this centrifuge,ASK FOR HELP.
⚫The precautions described in this User Manual are carefully developed in an attempt to cover all the
possible risks. However, it is also important that you are alert for unexpected incidents. Be careful
operating this centrifuge.
WARNING
⚫This centrifuge is not explosion-proof. Never use explosive or flammable samples.
⚫Do not install the centrifuge in or near places where inflammable gases are generated or chemicals are
stored.

LCEN-401P
2
⚫Do not place dangerous materials within 30cm of the centrifuge.
⚫Prepare all necessary safety measures before using samples that are toxic, radioactive or contaminated
with pathogenic micro-organisms. Use of these is at your own responsibility.
⚫If the centrifuge, rotor and accessories that have been contaminated by solutions with toxic,
radioactive or pathogenic materials, clean it according to the decontamination procedure as specified.
⚫If you require service at site, please sterilize and decontaminate the centrifuge in advance, and then
notify the service center the details of the materials and procedure.
⚫To avoid electrical shocks, insure hands are dry before handling the power cord or turning on/off the
power switch.
⚫For safety purposes, do not enter within 30cm around this centrifuge when it is in operation.
⚫While the rotor is rotating, never release the door lock.
⚫Unauthorized repairs, disassembly, or modifying the centrifuge except by our service center are
strictly prohibited.
CAUTION
⚫This centrifuge must be located on a firm and level table.
⚫Make sure the centrifuge is horizontal before running.
⚫Do not move or relocate the centrifuge when it is running.
⚫If fluid spills in the rotor chamber, please promptly clean and dry with a dry cloth to avoid sample
contamination.
⚫Ensure to remove any objects and fragments of the tubes dropped inside the rotor chamber before
running the centrifuge.
⚫Cautions with rotor
(1) Always check for corrosion and damage on the rotor surface before using it. Do not use the rotor
if an abnormality is found.
(2) Do not set the speed beyond the allowable minimum speed of the rotor kits (rotor and adapters).
Make sure to run it below the allowable maximum speed.
(3) Do not exceed the allowable imbalance.
(4) Use the rotor and tubes within their actual capacities.
If any abnormal condition occurs during operation, please stop it immediately and contact our
service center. Notify the service center is a warning code if displayed.
⚫Vibrations are likely to damage the centrifuge, contact our service center if abnormality observed.

LCEN-401P
3
1. Intended use
This device is a medical product (laboratory centrifuge) within the context of the IVD Directive 98/79/EC.
The centrifuge is used for the centrifugal separation of human blood or urine samples in the rotor in
accordance with EN ISO 12772. Operator should be trained before using the centrifuge. Detailed operation,
please refer to the User Manual below.
2. Specifications
Maximum speed
4500rpm(300-4500rpm), increment: 10rpm
Maximum RCF
2490×g, increment: 10×g
Maximum capacity
10ml×12, 15ml×8
Timer
30seconds -99minutes
Noise
56dB(A)
Driving Motor
Brushless DC motor
Safety devices
Door interlock, Over-speed detector, Error code runtime display
Power requirements
Single-phase, 100V-240V, 50Hz/60Hz, 3A.
Ambient condition
-Set-up site
-Altitude
-Ambient temperature
-Humidity
-Excess-voltage category
-Pollution degree
Indoor only
Up to 2000 m above sea level
2°C ～40°C
80%
II
2
Device protection class
I
EMC
-Emitted interference,
Interference immunity
EN/IEC 61326-1
Class A
FCC Class A
Dimensions（mm）
（L）354×（W）304×（H）215
Weight
6kg
Additional features
Speed/RCF switch, LCD display of runtime status, buzzer notification
& alert

LCEN-401P
4
3. Declaration of Conformity
Construction in accordance with the following safety standards:
EN 61010-1
EN 61010-2-020
EN 61010-2-101
Construction in accordance with the following EMC standards:
EN 61326-1/ FCC Part 15 Subpart B/ IECS 001
EN 61326-2-6
Associated EU guidelines:
EMCderective:2014/30/EU
LVD derective: 2014/35/EU
IVD derective: 98/79/EC
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme àla norme NMB-001 du Canada.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
4.Required Operational Conditions
4.1 Basic operational conditions
（1）Power: 100V-240V, 50Hz/60Hz, 3A.
（2）Ambient temperature: 2℃~40℃.
（3）Relative humidity: ≤80%.
（4）No vibration and airflow around.
（5）No electric dust, explosive and corrosive gases around.
4.2 Transport and storage conditions
（1）Storage temperature: -40℃~55℃.
（2）Relative humidity: ≤93%.

LCEN-401P
5
5.Installation
This section describes the instructions that you should abide when install the centrifuge to ensure your
safety and the optimum performance. Before moving the centrifuge, the rotor must be removed.
WARNING
⚫Improper power supply may damage centrifuge.
⚫Make sure the power source conforms to the required power supply before connecting.
5.1 Location
（1）Place this centrifuge on a firm、flat and level surface, ensure the four feet of this centrifuge stand on
the counter firmly. Avoid installing on a slippery surface or surface prone to vibration.
（2）Ideal ambient temperature is 20℃±5 ℃, avoid placing the centrifuge in direct sunlight if temperature
exceeds 30℃.
（3）Keep clear of the centrifuge at least 10cm on both sides and at least 30cm behind it to guarantee the
cooling efficiency.
（4）Keep away from heat or water to avoid sample temperature issues or centrifuge failures.
5.2 Connection of the power cord and grounding
WARNING
⚫To avoid electrical shocks, ensure your hands are dry when touching the power cord.
⚫This centrifuge must be grounded properly.
An minimum 10A outlet providing a sufficient ground is required, and this must meet local safety
requirements.

LCEN-401P
6
6.Structure
Figure 6-1 Front view of the centrifuge
Figure 6-2 Rear view of the centrifuge
7.Operation panel
Door lock hook
Rotor
Operation panel
Door release hole
LCD Display
Power inlet
Power switch
Air vents
View
Door hole
1 2 3 4 5

LCEN-401P
7
Figure 7-1 Operation panel
Item
Symbol
Name
Function
1
Program button
Press the button to choose the programs
2
Step button
Press for step choose and hold on 5s for RCF switch display
3
Open/ lock button
Press the button to open the door The button is not available
when the centrifuge is running.
4
Start/ Stop button
Press the button to start running. The centrifuge will brake to
stop running if pressed during centrifugation.
5
Parameter knob
Clockwise rotate to increase program values. Rotate
anti-clockwise to decrease parameter values.
Press the button 5s, change the preloaded program
parameters.
Figure 7-2 The main interface
Main interface is as figure 7-2. The program is for PRP function. The speed is set to be 3480rpm, the door
lock is released and the running time is 3 minutes. When speed symbol is rotating, this indicates the
centrifuge is running. If the rotation is faster, the speed is higher. Time symbol displays the time
setting.
8. Rotor Preparation
8.1 Prepare the samples
8.2 Inject the samples into tubes
Program Speed area Lock status Time area

LCEN-401P
8
⚫Do not exceed the actual capacity allowed in the user manual.
8.3 Keep the tubes balanced
⚫Although the centrifuge can accept sample balancing by eye, we recommend that you keep this
centrifuge in a well-balanced condition to extend its life expectancy.
⚫Never intentionally run the centrifuge under an unbalanced condition even though the allowable
imbalance is not exceeded.
8.4 Inspect the rotor
Check the rotor for corrosion or scratches before using.
CAUTION
⚫If any abnormality such as corrosion or scratches are found, stop using the rotor and contact our
service center.
⚫Only manufacturer’s rotors must be used with the unit.
8.5 Symmetrically load centrifuge tubes into rotor
CAUTION
⚫Make sure the rotor lid is securely fixed on the rotor, as well as the rotor and shaft are tightened.
Otherwise, the rotor may be moved off while rotating and cause damage to the centrifuge and rotor.
⚫Firmly tighten the rotor lid to the rotor.
9. Operation
9.1 Normal operation
Turn on the power switch, centrifuge will display the running interface last time after passing the
self-diagnostic checks.
CAUTION
⚫Do not overload samples into the centrifuge which will cause leaking.
CAUTION
⚫Do not push or lean against the centrifuge while it is running.
⚫Do not run the centrifuge when fragments or sample solutions are left in the centrifuge chamber.
Always keep the centrifugal chamber clean.
⚫If the centrifuge makes strange noise during operation, stop it immediately and contact our service
center. Notify them of the warning code if displayed.
