Nautilus Hyosung MX7600I User manual

Installation Manual
MX7600I System
V01.00.04(2015.04.12)
© 2012 Nautilus Hyosung Inc. All Rights Reserved.

© 2012 Nautilus Hyosung, Inc. All Rights Reserved.
I
Revision History
No. Version Date Description of Change Chapter
1
V1.0
2011/11
New Publication
All
2 V1.1 2012/5 Added “Appendix 1. Module Setting (CCIM)” Appendix
Modified “Maintenance Space for MX7600I ATM: Plan View
(1)”
Modified “Anchor”
3 V01.00.02 2012/08/27 Added “Height and Depth Main Fascia Items” Chapter3
4
V01.00.03
2012/10/10
Added “Safety Precautions” in French
Chapter1
5 V01.00.04 2015/04/12 Added the weight of MX7600I Chapter3
© 2011 Nautilus Hyosung All Rights Reserved.
The content of this specification is protected bycopyright laws.
2015.04.12. 5th Release
Installation Manual – MX7600I System

© 2012 Nautilus Hyosung, Inc. All Rights Reserved.
II
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose.........................................................................................................................................................1-1
Audience .......................................................................................................................................................1-1
Support Information............................................................................................................................................. 1-1
What is in This Manual........................................................................................................................................ 1-1
Conventions......................................................................................................................................................... 1-2
Abbreviations of ATM.........................................................................................................................................................1-2
Safety Precautions (English).........................................................................................................................1-4
Précautions pour la sécurité (French)...........................................................................................................1-5
Related Document .............................................................................................................................................. 1-8
Chapter2. Introduction ...................................................................................................................2-1
About the MX7600I .......................................................................................................................................2-1
System Identification Label...........................................................................................................................2-2
Chapter3. Installation Information.................................................................................................3-1
Installation Condition and Space ....................................................................................................................... 3-1
Packing Dimensions & Weight......................................................................................................................3-2
ATM Dimensions...........................................................................................................................................3-3
Height and Depth Main Fascia Items............................................................................................................3-5
Fascia Item Locations for Voice Guidance....................................................................................................3-6
Recommended Installation and Service Clearance......................................................................................3-7
AC Inlet Box ................................................................................................................................................3-10
Terminal Block Interface..............................................................................................................................3-12
Chapter4. System Installation........................................................................................................4-1
Unpacking the ATM............................................................................................................................................................4-1
Bolting Down the MX7600I............................................................................................................................4-2
Appendix.......................................................................................................................................... A-1
Precaution ...................................................................................................................................................... A-1
Topper Installation ……...................................................................................................................................... A-1
ATM Signage....................................................................................................................................................... A-3
Cash & Check in Module (CCIM) in the Safety Body..................................................................................A-4
Removing the Protective Material from the main body of Cash & Check In Module .............................A-4
Removing the locking section from the main body of Cash & Check In Module....................................A-5
SeparatingtheCassetteSection.............................................................................................................A-6
Installing Section........... ............................................................................................................................. A-7
Notes.......................................................................................................................................Notes-1

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-1
InstallationManual Chapter1.Preface
Chapter 1. Preface
Purpose
►This manual provides guidelines for preparing and installing the MX7600I ATM.
Audience
►This manual is written for bank branch personnel who are installing the MX7600I.
Additional audiences include designers and construction workers involved in this
installation.
Support Information
►For questions or if errors occur while preparing and installing the MX7600I, please
contact the Nautilus Hyosung maintenance team.
For contact information, see the
email addresses
and telephone numbers provided to you separately.
What is in This Manual
►In addition to installation guidelines for the MX7600I, this manual includes important
warnings you must take into consideration during installation.
►All measurements in this manual are in metric with inches provided in braces
( ).
►All informationdescribed in this manual is a licensed product of Nautilus
Hyosung.
Some of the information in this manual may differ according to the network processor
to be connected and may be subsequently updated for the bank’s needs or from
improvements byNautilus Hyosung.
It is the policy of Nautilus Hyosung to improve products as new technology,
components, software, and firmware become available. Therefore Nautilus Hyosung
reserves the right to change specifications without notice.

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-2
InstallationManual Chapter1.Preface
Conventions
►Terminology
In this document the terminology listed below is used as follows:
▪ Customer and consumer refer to anyperson who transacts business through the
ATM.
▪ Device and unit refer to the standard and optional ATM equipment, such as monitor,
card reader, printer and dispenser.
▪ Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
▪ Module refers to a plug-in device that can be serviced or replaced.
▪ Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
▪ Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep theATM operational.
▪ Screen refers to the text appearing on the customer display.
Abbreviations of ATM
►The abbreviations listed below are used in this manual:
#
Abbreviations
Description
1 AD board Analog to Digital conversion board
2 ADA TheAmerican Disabilities Act
3 ALG AlignmentModule
4 AP ApplicationProgram
5
Assy
Assembly
6
BATT S/W
BatterySwitch
7
BC
Bill Checker
8
BM1
BodyModule1
9 BM2 BodyModule2
10 BM3 BodyModule3
11 BUNDLE Bulk Note Separation Module
12 CAM Camera Unit
13 CASSETTE Cash & Check Cassette
14 CCIM Cash & Check In Module
15
CCR
Contactless Card Reader
16
CDU
Cash Dispenser Unit
17
CE
ControlElectronics
18
Earphone Jack
Voice Converter for Visually Disabled Persons (ADA)
19
EMV
Europay, Mastercard, Visa

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-3
InstallationManual Chapter1.Preface
#
Abbreviations
Description
20 EP ElementaryProgram
21 EPP Encryption PIN Pad
22 ESCROW EscrowModule
23
FELT
Ink Head Cleaner Felt
24
H/W
Hardware
25
I/F
Interface
26
ISO
InternationalStandard Organization
27
JPR
Journal Printer
28 LCD Liquid Crystal Display
29 MCU Magnetic Card Unit
30 OPL Operation Panel for Customers to Operate
31 OSD board On Screen Display Board
32 P/S Power Supply
33 PIN PersonalIdentification Number
34
PNC
Panel Control Board
35
PRT
EndorsementModule
36
PTR
Printer (mainly Receipt Printer)
37
RECOG
RecognitionModule
38 REJECT RejectModule
39 RT/A6 Retract & A6 Cassette
40 S/W Switch
41 SCM Separator Control Module
42 SIU Sensor and Indications Unit
43 SP ServiceProvider
44
SPR
Slip Printer (Receipt Printer)
45
TTU
Text Terminal Unit (OPL or SPL)
46
VFD
Vacuum Fluorescent Display

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-4
InstallationManual Chapter1.Preface
Safety Precautions (English)
▶Common Safety Precaution
Precautions outlined this manual provide information on safe
and proper handling of the product. Non-compliance of the
precautions may result in injury or damage to the product.
This precaution symbol with sample term tells you safety
warnings during equipment handlings.
▶Please read the following instructions before operating equipment.
▪ Operate equipment in the order outlined in this manual.
▪ Follow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to the
product.
▪ Avoid operations not addressed in this manual.
▪ If you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
▪ Any change or modifications in construction of this device which are not expressly
approved bythe party responsible for compliance could void the user’s authority to
operate the equipment.
<Note!>
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, maycause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
▶Description of Precaution Symbols
Symbol Description
Electrical Shock Warning
▪ Do not remove cover. Only a maintenance engineer is
allowed to open the cover.
▪ Do not touch. You mayreceive electric shock.
▪ Make sure to turn off the power when servicing the
equipment.
High Temperature Warning
▪ Do not touch the equipment when it is running.
▪ The equipment can get extremely hot and may cause a
burn.
▪ Make sure to close the cover before running the
equipment.

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-5
InstallationManual Chapter1.Preface
Use Precaution when Moving
▪ The equipment is heavy. Make sure at least 2 people lift or
move the equipment.
▪ Do not attempt to move the equipment alone. You may be
injured from dropping the heavy equipment.
Fire Hazard
▪ Place the equipment in an area away from any
combustiblematerials.
▪ The equipment maycatch on fire from overheating or short
circuit of the power supply unit.
DisassemblyWarnings
▪ Do not disassemble or modify the equipment unless you
are a certified engineer.
▪ Contact the service center for maintenance, adjustments
and repairs.
▪ Improper disassembly may cause fire or electrical shock.
CollapsePrecautions
▪ Do not place the equipment where the floor cannot sustain
the weight of the equipment, or on slanted or unstable
surface.
▪ Equipment mayfall and cause injury or damage.
Unplug the Equipment
▪ Stop using the equipment immediately if it smokes, emits
an unusual smell, makes abnormal sounds, or if liquids or
other foreign materials enter the equipment.
▪ If the above-mentioned abnormalities occur, immediately
turn off the power, unplug the equipment and contact the
servicecenter.
▪ If you ignore these symptoms, the equipment may catch on
fire or cause electric shock.
<CAUTION>
1. TO REDUCE THE RISK OF FIRE, USE ONLY No. 26 AWG OR LARGER
TELECOMMUNICATIONLINECORD
2. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSED OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
3. FOR PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE INSTALLED
NEAR THE EQUIPMENT AN SHALL BE EASILY ACCESSIBLE
4. THE EQUIPMENT IS TO BE SECURED TO THE BUILDING STRUCTURE BEFORE
OPERATION

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-6
InstallationManual Chapter1.Preface
Précautions pour la sécurité (French)
►Précaution générale pour la sécurité
Précautions décrits de ce manuel fournissent des informations
sur une manipulation sûre et appropriée du produit. Le non-
respect des précautions peut causer des blessures ou
endommager le produit.
Ce symbole de précaution avec le terme d’example vous
indique des consignes de sécurité lors de la manipulation de
l'équipement.
►Veuillez lire des instructions suivantes avant d'utiliser l'équipement
▪ Fonctionner l'équipement dans l'ordre indiqué dans ce manuel.
▪ Suivre les précautions indiquées dans ce manuel, ainsi que l'équipement lui-même.
Le défaut de traiter correctement de ces précautions peut entraîner des blessures ou
endommager le produit.
▪ Évitez des opérations non traitées dans ce manuel.
▪ Si vous ne pouvez pas résoudre des problèmes du système en utilisant des méthodes
décrites dans ce manuel, veuillez se référer aux informations de contact figurant dans
le manuel, s’il vous plaît.
▪ Certain changement ou des modifications dans la construction de ce dispositif qui ne
sont pas expressément approuvés par la partie responsable de la conformité
pourraient annuler l'autorité de l'utilisateur de faire fonctionner l'équipement.
<REMAQUE!>
Cet équipement a été testé et fondé pour se conformer aux limites pour un équipement
numérique de classe A, conformément à la partie 15 des règles FCC. Ces limites sont
conçues pour fournir une protection raisonnable contre des interférences nuisibles
lorsque l'équipement est utilisé dans un environnement commercial. Cet équipement
génère, utilise et peut émettre des fréquences radios et, s'il n'est pas installé et utilisé
conformément aux instructions de ce manuel, peut causer des interférences nuisibles
aux communications radios.
Le fonctionnement de cet équipement dans une zone résidentielle est susceptible de
provoquer des interférences nuisibles dans le cas, l'utilisateur devra corriger ces
interférences à ses propres frais.
►Description des symboles de précaution
Symbole Description
Chocélectrique
• Ne pas retirer le couvercle. Seul le technicien d'entretien est
autorisé à ouvrir
le couvercle.
• Ne pas toucher. Vous pouvez avoir un choc électrique.
• Assurez-vous d'éteindre l'appareil lors de l'entretien de
l'équipement.

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-7
InstallationManual Chapter1.Preface
À hautetemperature
• Ne pas toucher l’équipement quand il est en marche.
• L’équipement peut devenir extrêmement chaud et peut
provoquer une brûlure.
• Assurez-vous de fermer le couvercle avant de lancer
l'équipement.
Soyez prudent lors du déplacement
• L'équipement est lourd.Assurez-vous d'au moins 2
personnes pour soulever ou déplacer l'équipement
• N'essayez pas de déplacer l’équipement seul. Vous pouvez
être blessés par la chute de l'équipement lourd.
Risqued'incendie
• Placer l’équipement dans une zone éloignée de tous les
matériauxcombustibles.
• L'équipement peut s'enflammer de surchauffe ou de court-
circuit de l'unité d'alimentation.
Démontage
• Ne pas démonter ou de modifier l'équipement, sauf si vous
êtes ingénieur certifié.
• Contacter le centre de service pour l'entretien, le réglage et
la réparation.
• Le mauvais démontage peut provoquer un incendie ou un
choc électrique.
Tomber
• Ne pas placer l'équipement dont le sol ne peut pas
supporter le poids de l'équipement, ou sur une surface
inclinée ou instable.
• L'équipement peut tomber et provoquer des blessures ou
des dommages.
Débrancher l'équipement
• Cessezd'utiliser l’équipement immédiatement si il fume,
émet une odeur inhabituelle, fait des bruits anormaux ou si
des liquides ou d'autres matériaux étrangers dans
l'équipement.
• Si les anomalies mentionnées ci-dessus se produisent,
éteignez immédiatement la puissance, débranchez
l'appareil et contactez le centre de service.
• Si vous ignorez ces symptômes, l’équipement peut prendre
feu ou provoquer un choc électrique.
AVERTISSEMENT :
1. POUR RÉDUIRE LES RISQUES D'INCENDIE, UTILISEZ UNIQUEMENT AWG n ° 26 OU
LA LIGNES DE TELECOMMUNICATION PLUS GROSSE
2. RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN TYPE
INCORRECT. DISPOSER POUR UTILISATION DES BATTRIES SELON LES
INSTRUCTIONS
3. POUR LES APPAREILS RACCORDES, LA PRISE DOIT ETRE INSTALLEE PRES
D’EQUIPEMENT POUR ÊTRE FACILEMENT ACCESSIBLE

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
1-8
InstallationManual Chapter1.Preface
4. L’EQUIPEMENT DOIT ETRE SECURISE A LA STRUCTURE DU BATIMENT AVANT
D'UTILISER
Related Document
►Related documents are listed as follows. If needed, please contact the Nautilus Hyosung
technical support team or maintenance team for copies.
▪ Operator Manual
▪ MaintenanceManual
►To contact the Nautilus Hyosung maintenance staff, see the email addresses
and
telephone numbers provided separately.

© 2012 Nautilus Hyosung, Inc. All Rights Reserved.
2-1
InstallationManual Chapter2.Introduction
Chapter 2. Introduction
About the MX7600I
►The MX7600I is a full serviceATM. Consumers can deposit mixed cash/check in one
slot
a nd receive dispensed cash and transaction records through openings in the
fascia.
The Monimax7600I ATM is installed on a new or existing concrete island. The
terminal is weather-sealed to allow for exposure to the weather.
The MX7600I is a versatile, easily maintained delivery system that can be modified to
keep pace with the bank's changing needs.
►The benefits that the new concept MX7600I provides are as follows:
1. Removes inconvenience which occurs when bank tellers directly handle cash and
checks with customers and relieves workload upon tellers by processing
deposit/withdrawal of cash/check automatically.
2. Relieves risks and burden of directly handling cash/check bydirectly keeping
cash/check deposited in a safe.
3. Allows tellers to calculate and close amount on hand faster than the existing manual
calculation.
4. Abank customer and a teller can easily interact on a touch screen, just like talking,
through Nautilus Hyosung’s intuitive and easy UI.
5. Supports expanded options as well as basic functions of deposit/withdrawal of
cash/check.
6. Allows easy and quick installation and maintenance.

© 2012 Nautilus Hyosung, Inc. All Rights Reserved.
2-2
InstallationManual Chapter2.Introduction
System Identification Label
▶The System Label below shows the layout of the product identification label which is
fixed inside the side box of theATM

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-1
InstallationManual Chapter3. Installation Information
Chapter 3. Installation Information
Installation Condition and Space
►When you determine the location of your MX7600IATM, ensure that the physical
environment, including the temperature and humidity, meets the requirements.
Following conditions should be met before installing equipment.
1. Avoid locations where intense direct light is reflected off the LCD screen.
2. Avoid locations where strong static electricity can occur.
3. The floor must allow easy wheelchair access from the front or the side.
4. Space required for servicing the machine should be considered before installation.
<Note!>
1. A canopy is recommended for the convenience of consumers, optimum
performance, and ease of servicing.
2. When you determine the location of your Monimax7600I ATM, ensure that the
physical environment, including the temperature and humidity, meets the
requirements.
3. Environmental specification below:
Operating
TemperatureRange
-35°C ~ +40°C (-31°F ~ 104°F)
Maximum temperature
change rate -10°C / hour (14°F / hour)
Storage TemperatureRange -10°C ~ 50°C (14°F ~ 122°F)
Maximum temperature
change rate 15°C /hour (59°F /hour)
Operating RelativeHumidity 15% ~ 100%
Storage
RelativeHumidity
10% ~ 90%

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-2
InstallationManual Chapter3. Installation Information
Packing Dimensions & Weight
►Packaging Dimensions
In some cases it may be necessary to store the ATM (in its box) before it is installed.
See figure below for information on the dimensions of a boxed Monimax7600I ATM.
►Weight of MX7600I: 1100kg (2,425.1lbs)

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-3
InstallationManual Chapter3. Installation Information
ATM Dimensions
►The figure below shows the dimensions of MX7600I ATM viewed from the front.

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-4
InstallationManual Chapter3. Installation Information
►The figure below shows the dimensions of MX7600I ATM viewed from the side.

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-5
InstallationManual Chapter3. Installation Information
Height and Depth Main Fascia Items
►The following pictures and tables give the height and depth to the main fascia items
located on the fascia. The height dimensions are calculated from the base of the ATM.
That satisfies theADAstandard and allows good accessibility and convenience for
both of unhandicapped and handicapped people.
The height and depth of main fascia items
Symbol
Height /Depth
Remarks
A 46.16”[1172.6mm] Top of the touch screen
B 42.84” [1088.0mm] Top of the function key
C 40.18” [1020.5mm] EPP
D
35.65” [905.4mm]
Card Reader
E 30.39” [771.8mm]
Cash Dispenser, Cash & Check
Input Module
F 41.26”[1048.0mm]
G 46.00”[1168.3mm]
H 48.03” [1220.0mm]
I 3.37” [85.7mm]
J 55.71” [1415.0mm]
K 35.20” [894.0mm]

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-6
InstallationManual Chapter3. Installation Information
Fascia Item Locations for Voice Guidance
Unit MCU CCIM CDU SPR
Symbol A B C D
Distance 127.6mm 254.5mm 406.1mm 72.2mm
From (5.02in) (10.01in) (15.98in) (2.84in)
No.5 Key
Clock
Face
5
5
7
1
Position

© 2012 Nautilus Hyosung Inc. All Rights Reserved.
3-7
InstallationManual Chapter3. Installation Information
Recommended Installation and Service Clearance
►The Monimax7600I ATM can be placed on a new or existing concrete island
►The following diagrams describe the recommended areas required for installing and servicing
the MX7600I. (Plan View)
