quadient CS-200 User manual

CS-200
Quick Installation Guide
2
Insert meter (b).
3
Plug in LAN cable (c) and power cable (d).
d
d
When you plug the system, the machine is switched on automatically.
45
Select LAN and press ‘OK’ to test connection type.
734478
OK
Installation Process
Enter your registration code
xxxx
Enter the registration code.
6
DO NOT add money to the meter at this step.
Press NO.
Non
7
Do you want to add credit?
Installation Process
Yes No
Complete the declaration by following the
screen.
Installation Process
Press “OK” to activate the
machine for Online Services.
8
Next
9
Open the door, insert ink cartridge (e) and follow the steps to complete alignment test.
A C E G I K
B D F H J
1
Unpack box, remove packaging.
Your machine is now ready to use. Please turn over for your Quick User Guide.
11
Amount
Press the button to add funds.
10
Credit Available
100.00
Enter amount:
10
Box content includes:
3
Machine base
Meter
LAN cable Power cable
Ink cartridge
d

CS-200 Quick User Guide
3When all steps are completed...
Print the tax stamp:
1. Insert the document into the
machine, the stamp will print on the
upper right hand side.
2. Push the document to the back and
right of the machine. Hold in position
until printing has finished, then remove.
Adding credit
Press choose ‘Credit’ and follow
the instructions on screen.
Note: in order to add credit to the
machine there must be funds available
in your tax account.
Changing the ink cartridge
1. Open the machine by pulling the left
hand side front panel towards you.
2. On the keypad, press
and select Cartridge > Headset
Replacement. The cartridge
moves to a replacement position
and a waiting message is displayed
on the screen.
3. Pull the blue lever to free the empty
cartridge. Remove the cartridge.
4. On the new ink cartridge, remove
the protective strip from the
printing head.
5. Insert the new ink cartridge in the
carriage, and then lock it by pushing
the blue lever back in place.
6. Close the front panel and
press on the control panel.
7. Follow the steps on screen.
2Select a rate:
2. Use the keypad to choose a rate
or service option, or use the
wizard for access to more rates.
Currently selected rate is
indicated at the
top of the screen.
AFF
No services
29.01.20
0000005000
Change rate:
1. Press
The Rate selection screen
is displayed.
0000005000
AFF
No services
1AFFIDAVI T
8Wizard
3. When done, press
to confirm your selection and
return to the home screen.
Quick steps to printing your tax stamp
1To reset the machine...
Press:
to reset default rate.
to wake the machine
up with default settings.
to return to the home screen.
For more specific information on your tax
machine, please visit:
kbhelp.quadient.com/cs200_ug_fee A0130160/B - 03/03/2020
0000005000
AFF
No services
29.01.20
Getting to know your Tax Machine
Screen Information
A1 Rate and services
A2 Date printed
A3 Amount
A4 Quantity (not applicable)
A2
Shortcut keys
B1 Sleep/On/O-mode (amber/
green/flashing amber)
B2 Rate and tax services selection
B3 Quantity (not applicable)
B4 Memory Job (not applicable)
B5 Credit management
B1
A3
A1
Enter the PIN code
Login
xxxx
Enter PIN code
When the machine starts,
enter the PIN code:
xxxx
B3
B5
B4
B2
1A4
