Uplus Lighting 19X15Z WASH User manual

User manual
19X15Z WASH
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
2.Technical Specifications…………………………………………………………………………4
3.Control Menu ……………………………………………………………………………………4-5
4.DMX Channels ……………………………………………………………………………………5-12
5.Trouble Shooting…………………………………………………………………………………13
6.Fixture Cleaning………………………………………………………… ………………………13
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is

4
firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to
which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s
weight. Also always use a safety cable that can hold 12 times of the weight of the unit when
installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Power supply: 110-240V, 50/60HZ
Power consumption: 350W
Light source: 19 15w high power RGBW 4 in 1 LED
Backlight LED: 30 0.18w RGB 3 in 1 LED
DMX Channel: 14/25 CH
Zoom angle: 10°-60°
Horizontal scanning: 540° (16bit precision scanning) Electronic error correction
Vertical scanning: 270° (16bit precision scanning) Electronic error correction
Strobe: 1-25 times/S or random strobe
Dimming: 0-100% linear adjustment
Control: DMX512
Dimension: 30*20*37.5cm, NW:12 kgs
3.Control Menu
Menu Operation
Address: Click to enter the address code setting
Settings: Click to enter system settings

5
Test: Click to enter manual mode
Calibration: Click to enter the password to enter the system calibration mode
Reset: Click to enter the system reset mode
Information: Click to enter to view system information
Main Menu
Second
Third / Fourth
address
001 - 512
Set up
Operating mode
DMX
Auto
Voice control
Local number
000 - 255
Channel mode
14CH
25CH
Horizontal reversal
switch
Vertical reverse
switch
Horizontal and vertical
swap
switch
Motor position error
correction
switch
Signal hold
Keep/clear
screen protector
switch
Language
Chinese/English
reset
confirm
cancel
test
Corresponding to the
current channel
calibration
enter password
Lamp calibration
Reset
Reset all
information
Current information
4.DMX Channels
14 CH Mode
CH
Function
Value
content
1
Strobe
0 - 19
Turn off dimming
20 - 24
Turn on dimming
25 - 64
Strobe light 1 (fast-slow)
65 - 69
turn on
70 - 84
Strobe 2: Turn on pulse (fast-slow)
85 - 89
turn on
90 - 104
Flash 3: Turn off pulse (fast-slow)
105 - 109
turn on
110 - 124
Strobe 4: Random strobe (fast-slow)

6
1
Strobe
125 - 129
turn on
130 - 144
Strobe 5: random turn on pulse (fast-slow)
145 - 149
turn on
150 - 164
Strobe light 6: turn off pulse randomly (fast-slow)
165 - 169
turn on
170 - 184
Strobe 7: burst pulse (fast-slow)
185 - 189
turn on
190 - 204
Strobe 8: random burst pulse (fast-slow)
205 - 209
turn on
210 - 224
Strobe 9: Sine wave (fast-slow)
225 - 229
turn on
230 - 244
Strobe 10: continuous shooting (fast-slow)
245 - 255
turn on
2
Dimming
0 - 255
0-100％
3
focusing
0 - 255
Linear focus
4
X axis
0 - 255
Horizontal 0°-540°
5
X-axis fine adjustment
0 - 255
Level fine adjustment
6
Y axis
0 - 255
Vertical 0°-232°
7
Y-axis fine adjustment
0 - 255
Vertical fine adjustment
8
Macro function
0 - 9
No function
10-14
Reset
15 - 39
No function
40 - 44
PTSP = NORM2
45 - 49
PTSP = FAST2
50 - 54
PTSP = SLOW2
55 - 59
No function
60 - 64
Fan fast mode
65 - 69
No function
70 - 74
Fan low speed mode
75 - 89
No function
90 - 94
Calibrated color output mode COLOR CALIB = ON3
95 - 99
No function
100 - 104
Original color output mode COLOR CALIB = OFF3
105 - 109
No function
110 - 114
Fast dimming, unlimited change speed 2
115 - 119
No function
120 - 124
Smooth dimming, slightly limited change speed 2
125 - 249
No function
250 - 255
Illuminate the display

7
9
colour
0 - 9
Turn on RGBW color mixing
10 - 14
Moroccan pink
15 - 19
Pink
20 - 24
Special rose pink
25 - 29
Fool fan
30 - 34
Fuchsia pink
35 - 39
Surprise pink
40 - 44
Congo blue
45 - 49
Tokyo blue
50 - 54
Navy blue
55 - 59
blue
60 - 64
Medium blue
65 - 69
Double CT Blue
70 - 74
Slate blue
75 - 79
Full CT blue
80 - 84
Half CT blue
85 - 89
Steel blue
90 - 94
Light blue
95 - 99
Light blue
100 - 104
Medium blue green
105 - 109
dark green
110 - 114
light green
115 - 119
Moss green
120 - 124
Fern green
125 - 129
JAS green
130 - 134
lemon green
135 - 139
Spring yellow
140 - 144
Dark amber
145 - 149
Chrome orange
150 - 154
Orange
155 - 159
Golden amber
160 - 164
Daughter
165 - 169
Dark golden amber
170 - 174
Flame red
175 - 179
turn on
180 - 201
Clockwise, fast to slow
202 - 207
stop
208 - 229
Counterclockwise, slow to fast
230 - 234
turn on
235 - 239
Random and fast
240 - 244
Random medium speed
245 - 249
Random slow
250 - 255
turn on

8
10
red
0 - 255
Red 0-100%
11
green
0 - 255
Green 0-100%
12
blue
0 - 255
Blue 0-100%
13
white
0 - 255
White 0-100%
14
CTC (color temperature control)
0 - 19
NO CTC
20 - 255
CTC 10 000K - 2 500K
25 CH Mode
CH
Function
Value
content
1
Strobe
0 - 19
Turn off dimming
20 - 24
Turn on dimming
25 - 64
Strobe light 1 (fast® slow)
65 - 69
turn on
70 - 84
Strobe 2: Turn on pulse (fast® slow)
85 - 89
turn on
90 - 104
Flash 3: Turn off pulse (fast® slow)
105 - 109
turn on
110 - 124
Strobe 4: Random strobe (fast® slow)
125 - 129
turn on
130 - 144
Strobe 5: random turn on pulse (fast® slow)
145 - 149
turn on
150 - 164
Strobe light 6: turn off pulse randomly (fast ® slow)
165 - 169
turn on
170 - 184
Strobe 7: Burst pulse (fast® slow)
185 - 189
turn on
190 - 204
Strobe 8: random burst pulse (fast® slow)
205 - 209
turn on
210 - 224
Strobe 9: Sine wave (fast® slow)
225 - 229
turn on
230 - 244
Strobe 10: continuous shooting (fast® slow)
245 - 255
turn on
2
Dimming
0 - 255
0-100%
3
focusing
0 - 255
Linear focus
4
X axis
0 - 255
Horizontal 0°-540°
5
X-axis fine adjustment
0 - 255
Level fine adjustment
6
Y axis
0 - 255
Vertical 0°-232°
7
Y-axis fine adjustment
0 - 255
Vertical fine adjustment
8
Macro function
0 - 9
No function

9
8
Macro function
10 - 14
Reset
15 - 39
No function
40 - 44
PTSP = NORM2
45 - 49
PTSP = FAST2
50 - 54
PTSP = SLOW2
55 - 59
No function
60 - 64
Fan fast mode
65 - 69
No function
70 - 74
Fan low speed mode
75 - 89
No function
90 - 94
Calibrated color output mode COLOR CALIB = ON3
95 - 99
No function
100 - 104
Original color output mode COLOR CALIB = OFF3
105 - 109
No function
110 - 114
Fast dimming, unlimited change speed 2
115 - 119
No function
120 - 124
Smooth dimming, slightly limited change speed 2
125 - 249
No function
250 - 255
Illuminate the display
9
colour
0 - 9
turn on. Enable RGBW color mixing
10 - 14
Moroccan pink
15 - 19
Pink
20 - 24
Special rose pink
25 - 29
Fool fan
30 - 34
Fuchsia pink
35 - 39
Surprise pink
40 - 44
Congo blue
45 - 49
Tokyo blue
50 - 54
Navy blue
55 - 59
blue
60 - 64
Medium blue
65 - 69
Double CT Blue
70 - 74
Slate blue
75 - 79
Full CT blue
80 - 84
Half CT blue
85 - 89
Steel blue
90 - 94
Light blue
95 - 99
Light blue
100 - 104
Medium blue green
105 - 109
dark green
110 - 114
light green
115 - 119
Moss green

10
9
colour
120 - 124
Fern green
125 - 129
JAS green
130 - 134
lemon green
135 - 139
Spring yellow
140 - 144
Dark amber
145 - 149
Chrome orange
150 - 154
Orange
155 - 159
Golden amber
160 - 164
Daughter
165 - 169
Dark golden amber
170 - 174
Flame red
175 - 179
turn on
180 - 201
Clockwise, fast® slow
202 - 207
stop
208 - 229
Counterclockwise, slow ® fast
230 - 234
turn on
235 - 239
Random and fast
240 - 244
Random medium speed
245 - 249
Random slow
250 - 255
turn on
10
red
0 - 255
Red 0-100%
11
green
0 - 255
Green 0-100%
12
blue
0 - 255
Blue 0-100%
13
white
0 - 255
White 0-100%
14
CTC (color temperature
control)
0 - 19
NO CTC
20 - 255
CTC 10 000K-2 500K
15
FX1 (Effect 1)
0 - 4
No function
5 - 255
Pre-programmed effect 1 selection
16
Effect 1 speed
0 - 255
Slow to fast
• If synchronization is not set on channel 19, please adjust FX1
• If synchronization is set on channel 19, adjust the
synchronized FX1 + FX2 speed
17
FX2 (Effect 2)
0 - 4
No function
5 - 255
Pre-programmed effect 2 selection
18
Effect 2 speed
0 - 255
Slow to fast
• If synchronization is not set on channel 19, please adjust FX2
• If synchronization is set on channel 19, it is invalid
19
Operation effect mode
0 - 5
No sync

11
19
Operation effect mode
6 - 255
Speed synchronization
20
Backlight strobe
0 - 19
Turn off dimming
20 - 24
Turn on dimming
25 - 64
Strobe light 1 (fast® slow)
65 - 69
turn on
70 - 84
Strobe 2: Turn on pulse (fast® slow)
85 - 89
turn on
90 - 104
Flash 3: Turn off pulse (fast® slow)
105 - 109
turn on
110 - 124
Strobe 4: Random strobe (fast® slow)
125 - 129
turn on
130 - 144
Strobe 5: random turn on pulse (fast® slow)
145 - 149
turn on
150 - 164
Strobe light 6: turn off pulse randomly (fast ® slow)
165 - 169
turn on
170 - 184
Strobe 7: Burst pulse (fast® slow)
185 - 189
turn on
190 - 204
Strobe 8: random burst pulse (fast® slow)
205 - 209
turn on
210 - 224
Strobe 9: Sine wave (fast® slow)
225 - 229
turn on
230 - 244
Strobe 10: continuous shooting (fast® slow)
245 - 255
turn on
21
Backlight dimming
0 - 255
0-100%
22
Backlight color
0 - 9
turn on. Enable RGBW color mixing
10 - 14
Moroccan pink
15 - 19
Pink
20 - 24
Special rose pink
25 - 29
Fool fan
30 - 34
Fuchsia pink
35 - 39
Surprise pink
40 - 44
Congo blue
45 - 49
Tokyo blue
50 - 54
Navy blue

12
22
Backlight color
55 - 59
blue
60 - 64
Medium blue
65 - 69
Double CT Blue
70 - 74
Slate blue
75 - 79
Full CT blue
80 - 84
Half CT blue
85 - 89
Steel blue
90 - 94
Light blue
95 - 99
Light blue
100 - 104
Medium blue green
105 - 109
dark green
110 - 114
light green
115 - 119
Moss green
120 - 124
Fern green
125 - 129
JAS green
130 - 134
lemon green
135 - 139
Spring yellow
140 - 144
Dark amber
145 - 149
Chrome orange
150 - 154
Orange
155 - 159
Golden amber
160 - 164
Daughter
165 - 169
Dark golden amber
170 - 174
Flame red
175 - 179
turn on
180 - 201
Clockwise, fast® slow
202 - 207
stop
208 - 229
Counterclockwise, slow ® fast
230 - 234
turn on
235 - 239
Random and fast
240 - 244
Random medium speed
245 - 249
Random slow
250 - 255
turn on
23
Backlight red
0 - 255
Red 0-100%
24
Backlight green
0 - 255
Green 0-100%
25
Backlight blue
0 - 255
Blue 0-100%

13
6.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X
p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
7.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
