Yealink VC Series User manual

Yealink VC Series Video Conferencing System Quick Start Guide(V10.5)
VC400: Applies to firware version 30.10.0.5 or later
VC120: Applies to firware version 40.10.0.5 or later

Table of Contents
Remote Control and Cable
Ties Installation
Bracket and Camera Installation
Packaging Contents 1
2
3
4
Connections 7
6
10
Troubleshooting
Main Screen
Network Deployment

1
Please use the Yealink-customized DVI cable
Packaging Contents
Quick Start GuidePower Adapter Optional Accessories
CPE80 Expansion
Microphone
Cable Ties 7
+
AAA Batteries 2
+
(2m) (7.5m)
VC400: 3.5mm Audio Cable 1
VC120: None
+
Camera Wall Mount Accessories
+
+
4
+
2
VCC18 Camera VCP40 Video Conferencing Phone VC400/VC120 Codec VCR10 Remote Control
DVI Cable VGA Cable Ethernet Cable Ethernet Cable
++
VC400: HDMI Cable 2
VC120: HDMI Cable 1

Connections
2
Please do connect to Display1 port if you have only one display device
VCC18 Camera
VCP40 Video Conferencing
Phone
VGA Cable HDMI Cable 2m Ethernet Cable Power Adapter
PC Display 2
DVI Cable 7.5m Ethernet Cable
+

Remote Control and Cable Ties Installation
3
Fasten the cables with the cable tie
Install batteries

Bracket and Camera Installation
Please chose the following installation mode when the thinckness of the TV is less than 120mm
Hanging Mode
Make sure that the bracket is completely pasted to the back of the TV
Steps to hang the camera: Lock the Camera Tear the Tape Install the Bracket Adjust the Bracket
1 2 3 4
TV
4
1
3
2

The recommended height for camera positioning is 1.5m-1.8m
Wall Mount Method
Hole diameter: 6mm
Hole depth: 30mm
50mm
100mm 4
5 6
Steps：Punch holes & Insert expansion bolts Lock the bracket with screws Move the setscrews to the left holes,
and then manually tighten the screws
1 2 3
45
6
1
3
2Screw specification: M3 8
+
Screw specification: T4 30
+
Lock the bracket to the wall with screws Connect DVI cable
Lock the camera

Main Screen
6
Time and date Site name Status icon System IP address and
account information

Network Deployment
8
7
In order to ensure that the VC400/VC120 can work properly, please configure it according to the
role it plays in the conference. If it is in the head office, please make sure that it is reachable from
the public network. If it is in the branch office, please use intelligent firewall to deploy it or just
follow the same steps as in the head office
Head Office
At least one static public IP address is required in head office to allow branch offices to connect.
The recommended system configurations are as follows :
. Deploy VCS on public network, you need to assign a static public IP address to VCS.
. Deploy VCS in Intranet, you need to assign a static private IP address behind the firewall to
VCS. At the meantime, do port mapping on firewall for VC400/VC120.
Configure a Static IP
First of all, configure a static IP for the VC400/VC120
For example: you can use the remote control to configure the IP 10.2.18.74 to your VC400/VC120.
.
Menu->Advanced (Admin Password:0000)->LAN Configuration
. Turn off the 【DHCP】
.
Enter the IP Address, Subnet Mask, Gateway, DNS information in corresponding fields.

PortFunction
H.323 signal port
SIP（optional ）
Audio & Video media stream port
Web management port（optional ）
Protocol Type
TCP
5060
443
50000-50499
1720
TCP/UDP
TCP/UDP
TCP
Configure Port Mapping
If the VCS is deployed in Intranet, you need to finish the following port mapping on the firewall:
8
8
. Press 【Save】to save the configuration, then the screen prompts【Reboot now】
. Press 【OK】
to reboot the system.
