ACME ASTRO LED-256D User manual

Innovation,Quality,Performance
User Manual
Please read the instrucon carefully before use
LED-256D RGBW II

1C
CONTENTS
1. SafetyInstructions...................................................................................................2
2. TechnicalSpecifications...........................................................................................3
3. HowToSetTheUnit................................................................................................4
3.1ControlPanel.....................................................................................................4
4. HowToControlTheUnit.........................................................................................5
4.1Master/SlaveBuiltInPreprogrammedFunction...............................................5
4.2CA‐8EasyController..........................................................................................6
4.3DMXController..................................................................................................6
5. DMX512Configuration...........................................................................................7
6. DMX512Connection...............................................................................................8
7. Troubleshooting.......................................................................................................9
8. FixtureCleaning.......................................................................................................9
10C
DeclarationofConformity
Wedeclarethatourproducts(lightingequipments)complywiththe
followingspecificationandbearsCEmarkinaccordancewiththe
provisionoftheElectromagneticCompatibility(EMC)Directive
89/336/EEC.
EN55103‐1:2009;EN55103‐2:2009;EN62471:2008;
EN61000‐3‐2:2006+A1:2009+A2:2009;EN61000‐3‐3:2008.
&
HarmonizedStandard
EN60598‐1:2008+All:2009;EN60598‐2‐17:1989+A2:1991;
EN62471:2008;EN62493:2010
Safetyofhouseholdandsimilarelectricalappliances
Part1:Generalrequirements

9C
7. Troubleshooting
Followingareafewcommonproblemsthatcanoccurduringoperation.Herearesome
suggestionsforeasytroubleshooting:
A.Theunitdoesnotwork,nolightandthefandoesnotwork
1. Checktheconnectionofpowerandmainfuse.
B.NotrespondingtoDMXcontroller
1. DMXLEDshouldbeon.Ifnot,checkDMXconnectorsandcablestoseeiflinkedcorrectly.
2. IftheDMXLEDisonbutnoresponsechecktheaddresssettingsandDMXpolarity.
3. IfyouhaveintermittentDMXsignalproblemscheckthecablesandconnectors.
4. TryanotherDMXcontroller.
C.Noresponsetothesound
1. Makesuretheunitissetintothecorrectmode.
2. Checkthemicrophonetoseeifitisgoodbytappingit.
8. FixtureCleaning
Thecleaningmustbecarriedoutperiodicallytooptimizelightoutput.Cleaningfrequency
dependsontheenvironmentinwhichthefixtureoperates:damp,smokyorparticularlydirty
surroundingcancauseagreateraccumulationofdirtontheunit’soptics.
Cleanwithsoftclothusingnormalglasscleaningfluidormildsoapywater.
Alwaysdrythepartscarefully.
Cleantheexternalopticsatleastevery30days.
2C
1. SafetyInstructions
WARNING
PleasekeepthisUserGuideforfutureconsultation.Ifyouselltheunittoanotheruser,besure
thattheyalsoreceivethisinstructionbooklet.
Unpackandcheckcarefullythereisnotransportationdamagebeforeusingtheunit.
Beforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower
requirementsoftheunit.
It’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.
Theunitisforindooruseonly.Useonlyinadrylocation.
Theunitmustbeinstalledinalocationwithadequateventilation,atleast50cmfromadjacent
surfaces.Besurethatnoventilationslotsareblocked.
Disconnectmainpowerbeforereplacementorservicing.
Makesuretherearenoflammablematerialsclosetotheunitwhileoperatingastheyarefire
hazard.
Usesafetycableswhenhangingthisunit.
MaximumambienttemperatureisTa:40degreesC.DONOToperateitwherethetemperature
ishigherthanthis.
Intheeventofaseriousoperatingproblem,stopusingtheunitimmediately.Nevertrytorepair
theunitbyyourself.Repairscarriedoutbyunskilledpeoplecanleadtodamageormalfunction.
Pleasecontactthenearestauthorizedtechnicalassistancecenter.Alwaysusethesametype
spareparts.
DONOTtouchanycablesduringoperationashighvoltagemaycauseelectricshock.
Warning:
Topreventorreducetheriskofelectricalshockorfire,donotexposetheunittorainor
moisture.
Thehousingandlensesmustbereplacediftheyarevisiblydamaged.
Pleasereadcarefullytheinstructionswhichincludimportantinformation
abouttheinstallation,usageandmaintenance.

3C
Installation:
Theunitshouldbemountedviaitsscrewholesonthebracket.Alwaysensurethattheunitis
firmlyfixedtoavoidvibrationandslippingwhileoperating.Makesurethatthestructuretowhich
youareattachingtheunitissecureandisabletosupportaweightof10timesoftheunit’s
weight.Alsoalwaysuseasafetycablethatcanhold12timesoftheweightoftheunitwhen
installingthefixture.
Theequipmentmustbeinstalledbyprofessionals.Itmustbeinstalledinaplacewhereisoutof
thereachofpeopleandnoonecanpassbyorunderit.
2. TechnicalSpecifications
3DMXchannels:Dimmer/Strobe,Color,Rotation;
Built‐inprogramsinMaster/Slavemodetriggeredbymusic;
3operationmodes:DMX,Master/Slave,SoundActive;
Rotationspeedandstrobespeedadjustableviadipswitches;
RGBWcolourmixingtechnologywithcreativedesign;
Lowheat,lowpowerconsumption,nodutycycle,runsallnight;
Idealforclubs,bars,discos,partiesandmobileDJs
◇PowerVoltage: AC100V~240V,50/60Hz
◇PowerConsumption: 27W
◇LEDSource: 1×10WCREEQuad‐ColorLED
◇Weight: 1.8Kgs
◇Dimension: 220×214×180mm
8C
6. DMX512Connection
1. ThelastunitsDMXhastobeterminated.Usea120ohm1/4 W resistorbetweenpin2(DMX‐)
andpin3(DMX+)ofa3‐pinXLR‐plugandplugitintheDMXoutputofthelastunit.
2. Connecttheunitstogetherina`daisychain`withanXLRcablefromtheoutputoftheunitto
theinputofthenextunit.Thecablecannotbranchedorsplittoa`Y`cable.
3. TheDMXoutputandinputconnectorsarepass‐throughtypetomaintaintheDMXcircuiteven
whenoneoftheunits’powerisdisconnected.
4. Eachunitunitneedstohaveanaddresssettoreceivethedatasentbythecontroller.The
addressnumberisbetween0‐512(usually0&1areequalto1).
5. DMXcablingconfigurationisasfollows:
3pinXLR:Pin1:GND,Pin2:Negativesignal(‐),Pin3:Positivesignal(+)
Pin4/ P i n 5:Notused.

7C
3‐CHmode:(Dipswitch10OFF)
Channel1:dip/on:#1(=1)
Channel4:dip/on:#3(=4)
Channel7:dip/on:#1,#2,#3(1+2+4=7)
Channel10:dip/on:#2,#4(2+8=10)
5. DMX512Configuration
1/3 ChannelsMode:
4C
3. HowToSetTheUnit
3.1ControlPanel
1. DMXIN:DMX512link,usea3‐pinXLRcabletolinktheunittotheDMXcontroller;
2. DMXOUT:DMX512link,usea3‐pinXLRcabletolinktothenextunit;
3. ONLYFORREMOTECONTROL:ConnectswiththeoptionalCA‐8tocontroltheunit;
4. MICROPHONE:Receivesmusicsignalsforsoundactivemode;

5C
5. MAINSIN:Connectstopowersupply.
6. FUSE(T2A):Protectstheunitfromover‐voltageorshortcircuit
4. HowToControlTheUnit
Youcanoperatetheunitinthreeways:
1. Master/slavebuilt‐inpreprogramfunction
2. Easycontroller(optionalCA‐8)
3. UniversalDMXcontroller
4.1Master/SlaveBuiltInPreprogrammedFunction
Theunitcanbelinkedtogetherinadaisychainwithasmanyunitsasyouneedinmaster/slave
modetoperformgreatbuilt‐inpre‐programmedlightingshowstriggeredbythemusic.
InMaster/SlavemoderefertotheDMXsettingsbelow:
Masterunit:DMXstartaddressMUSTbesetto001.(FirstDIPswitch=ON,allotherareOFF)
Slaveunits:DMXstartaddressmayhaveanyvaluebutNOT001(example:setthefirst3DIP
switchestoON)
﹡Dipswitch2“OFF”hasfunctions:
Performsthebuilt‐inpre‐programstothemusic.
﹡Dipswitch2“ON”hasfunctions:
Automode:EightChases(inthismodeselectingdipswitch3willchangethedirectionofrotation，
selectdipswitch4,5,6tochangethespeed)
﹡2‐lightshow
Dipswitch10”off”meanstheunitworksnormallyand“on”meansinversion.Inordertocreatea
greatlightshow,youcansetdipswitch10”on”onanyunitthatislinkedtothemasterunittoget
contrastmovementtothemasterunit,evenifyouonlyhavetwounits.Dipswitch10onthefirst
(Master)unitisnouseforthe2‐lightshowasitisthemasterunitthatoperatesthelightshow.
6C
4.2CA‐8EasyController
TheCA‐8remotecontrolisusedonlyinmaster/slavemode.Byconnectingtothe1/4 ” 
jacksockettothefirstunityouwillfindthattheremotecontrolwillcontrolallthe
otherunitsforStandby,FunctionandModeselection.
4.3DMXController
WhenusingauniversalDMXcontrollertocontrolthechainofunitsyouhavetosetaDMXaddress
withDipswitches1to9.Dipswitch10isusedtoselectchannelmode,ONmeans1channelmode
andOFFmeans3channelmode.PleaserefertothefollowingdiagramtoaddressyourDMX512
systemusingbinarycode.
DMX512AddressChart:
Dip‐switches#1#2#3 #4#5#6#7#8#9#10
Value1248163264128 256 CHmode
•Examples:
1‐CHmode:(Dipswitch10ON)
Channel1:dip/on:#1(=1)
Channel2:dip/on:#2(=2)
Channel3:dip/on:#1,#2(1+2=3)
Channel4:dip/on:#3(=4)
StandbyBlackouttheunit
Function
1. SynchronousStrobe
2. TwolightStrobe
3. SoundStrobe
RotationSpeed
1‐8
ModeStrobe(LEDOFF)Rotation(LEDON)
