TABLE OF CONTENTS
1 About this operating manual 1
1.1 Diagrams 1
1.1.1 Warnings and signal words 1
1.1.2 Further instructions 1
1.1.3 Instructions 2
1.1.4 Lists 3
1.1.5 Item numbers in figures 3
1.2 Other applicable documents 4
1.3 Your opinion is important 4
2Safety and responsibility 5
2.1 Basic safety instructions 5
2.1.1 Meaning of the operating manual 5
2.1.2 Safe operating organisation 5
2.1.3 Knowing and preventing dangers 10
2.1.4 Safe operation and handling of the
machine 12
2.1.5 Safe maintenance and modification 14
2.2 Safety routines 17
3Intended use 19
4 Product description 20
4.1 Implement overview 20
4.2 Function of the implement 21
4.3 Special equipment 22
4.4 Protective equipment 22
4.4.1 Fertiliser metering drive 22
4.5 Warning symbols 23
4.5.1 Position of the warning symbols 23
4.5.2 Layout of the warning symbols 24
4.5.3 Description of the warning symbols 24
4.6 Rating plate on the implement 24
4.7 Compressed air fan 25
4.8 Grain singling unit 25
4.8.1 Layout and function of the grain
singling unit 25
4.8.2 Singling disc 26
4.9 PreTeC mulch seeding coulter 26
4.9.1 Seeding unit 26
4.9.2 Depth control wheels 27
4.9.3 Furrow former and catch roller 28
4.10 Fertiliser hopper 28
4.11 FerTeC Twin coulter 29
4.12 Filling auger 30
4.13 Micropellet spreader 31
4.14 Lighting 32
4.14.1 Lighting and identification for road
travel 32
4.14.2 Work lights 33
4.14.3 Hopper interior lighting 33
4.15 Electronic monitoring 33
4.15.1 Radar sensor 33
4.15.2 Low level sensors 34
4.15.3 Electronic remote scraper bar
adjustment 34
4.16 Threaded cartridge 35
4.17 Calibration kit 35
4.18 TwinTerminal 35
4.19 Sealing kit 36
5Technical data 37
5.1 Serial number 37
5.2 Dimensions 37
5.3 Permissible total weight 38
5.4 Permissible payload 38
5.5 Metering unit 38
5.5.1 Seed metering unit 38
5.5.2 Fertiliser metering unit 39
5.5.3 Micropellet metering unit 39
5.6 Coulters 40
5.6.1 PreTeC mulch seeding coulter 40
TABLE OF CONTENTS
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE I

5.6.2 FerTeC Twin coulter 40
5.7 Row spacings 41
5.8 Mounting category 41
5.9 Working speed 41
5.10 Performance characteristics of
the tractor 41
5.11 Noise development data 42
5.12 Drivable slope inclination 42
6 Preparing the machine 43
6.1 Calculating the required tractor
characteristics 43
6.2 Coupling the implement 46
6.2.1 Coupling the supply lines to the
front-mounted hopper 46
6.2.2 Coupling the supply lines to the
front hopper 46
6.2.3 Coupling the hydraulic hose lines 46
6.2.4 Coupling the ISOBUS or control
computer 48
6.2.5 Coupling the power supply 49
6.2.6 Coupling the 3-point mounting frame 49
6.2.7 Coupling the QuickLink 49
6.2.8 Operation without front hopper 53
6.3 Preparing the implement for
operation 53
6.3.1 Adjusting the working position sensor 53
6.3.2 Filling the seed hopper 54
6.3.3 Filling the fertiliser hopper 55
6.3.4 Preparing the micropellet spreader
for operation 58
6.3.5 Determining the setting parameters 63
6.3.6 Adjusting the fan speed via the
hydraulic system 64
6.3.7 Setting up the speed sensor on the
implement 66
6.3.8 Using the multi-placement tester 66
6.3.9 Adjusting the grain singling unit 68
6.3.10 Changing the seed spread rate 77
6.3.11 Adjusting the PreTeC mulch
seeding coulter 81
6.3.12 Creating tramlines 95
6.3.13 Calibrating the electrically driven
fertiliser metering unit 95
6.3.14 Changing the application rate for
liquid fertiliser 99
6.3.15 Adjusting the placement depth on
the coupled fertiliser coulter 101
6.3.16 Adjusting the placement depth on
the leaf spring-guided fertiliser coulter101
6.3.17 Adjusting the fertiliser application
point 102
6.3.18 Adjusting the filling auger 103
6.3.19 Using the loading board 104
6.3.20 Adjusting the coulter pressure in the
track 105
6.3.21 Installing a seed row 106
6.3.22 Removing seed rows 113
6.4 Preparing the machine for road
travel 122
6.4.1 Folding the implement 122
6.4.2 Increasing the mechanical coulter
pressure 123
6.4.3 Locking the tractor control units 123
7Using the machine 124
7.1 Using the implement 124
7.2 Turning on the headlands 125
7.3 Checking the placement depth 125
7.4 Using the shifted tramline 125
8Eliminating faults 127
9 Parking the machine 133
9.1 Emptying the fertiliser hopper 133
9.2 Emptying the seed hopper
through the residual quantity flap 133
9.3 Emptying the seed hopper
through the singling disc 134
9.4 Emptying the fertiliser metering
unit 137
9.5 Emptying the micropellet hopper 138
9.6 Relieving the hole covering rollers 140
9.7 Parking the PreTeC coulter 141
9.8 Disconnecting the supply lines
from the front-mounted hopper 142
TABLE OF CONTENTS
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
II

9.9 Disconnecting the supply lines
from the front hopper 143
9.10 Uncoupling the ISOBUS or
control computer 143
9.11 Disconnecting the hydraulic
hose lines 143
9.12 Uncoupling the power supply 144
9.13 Uncoupling the QuickLink 145
9.14 Parking the seeding combination 147
10 Repairing the machine 149
10.1 Maintaining the machine 149
10.1.1 Maintenance schedule 149
10.1.2 Checking and replacing the cutting
discs on the PreTeC mulch seeding
coulter 151
10.1.3 Adjusting the cutting disc distance
on the PreTeC mulch seeding coulter 152
10.1.4 Adjusting the cutting disc drive on
the PreTeC mulch seeding coulter 153
10.1.5 Checking and replacing the closer
discs on the PreTeC mulch seeding
coulter 153
10.1.6 Checking and replacing the rigid
cutting disc on the PreTeC mulch
seeding coulter 154
10.1.7 Checking and replacing the cutting
disc on the FerTeC Twin coulter 154
10.1.8 Adjusting the cutting disc distance
on the FerTeC Twin coulter 155
10.1.9 Checking and replacing the inner
scraper on the FerTeC Twin coulter 156
10.1.10 Checking the tightening torque for
the radar sensor bolts 157
10.1.11 Checking the coulter connection
tightening torque 157
10.1.12 Checking the top link pin and lower
link pin 158
10.1.13 Checking the hydraulic hose lines 158
10.1.14 Cleaning the fan rotor 159
10.1.15 Cleaning the cyclone separator 160
10.1.16 Cleaning the suction basket 160
10.1.17 Cleaning the filling auger 161
10.1.18 Cleaning the fertiliser hopper 162
10.1.19 Cleaning the fertiliser metering unit 164
10.1.20 Cleaning the micropellet metering
unit 165
10.1.21 Adjusting the micropellet metering
unit bottom flap 167
10.1.22 Clean the singling unit 168
10.1.23 Cleaning the opto-sensor 169
10.1.24 Cleaning the distributor head 174
10.2 Lubricating the roller chains 175
10.2.1 Lubricating the roller chain on the
central fertiliser metering drive 175
10.2.2 Lubricating the roller chain on the
electric agitator shaft drive 176
10.3 Cleaning the implement 177
11 Loading the implement 178
11.1 Lifting the implement 178
11.2 Lashing the machine 180
12 Appendix 182
12.1 Bolt tightening torques 182
12.2 Other applicable documents 183
13 Directories 184
13.1 Glossary 184
13.2 Index 185
TABLE OF CONTENTS
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE III

About this operating manual 1
1.1 Diagrams
1.1.1 Warnings and signal words
Warnings are marked with a vertical bar with a
triangular safety symbol and the signal word. The
signal words "DANGER", "WARNING" or "CAUTION"
describe the severity of the potential danger and have
the following meanings:
DANGER
Indicates a direct threat with high risk for
severe physical injury, such as loss of
limbs or death.
WARNING
Indicates a possible threat with moderate
risk for severe physical injury or death.
CAUTION
Indicates a threat with low risk for light or
moderately severe physical injuries.
1.1.2 Further instructions
IMPORTANT
Indicates a risk for damage to the
implement.
CMS-T-00000081-D.1
CMS-T-005676-C.1
CMS-T-00002415-A.1
CMS-T-00002416-A.1
1 | About this operating manual
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 1

ENVIRONMENTAL INFORMATION
Indicates a risk for environmental damage.
NOTE
Indicates application tips and instructions for
optimal use.
1.1.3 Instructions
Numbered instructions
Actions that have to be performed in a specific
sequence are represented as numbered instructions.
The specified sequence of the actions must be
observed.
Example:
1. Instruction 1
2. Instruction 2
1.1.3.1 Instructions and responses
Reactions to instructions are marked with an arrow.
Example:
1. Instruction 1
Reaction to instruction 1
2. Instruction 2
1.1.3.2 Alternative instructions
Alternative instructions are introduced with the word
"or".
CMS-T-00000473-B.1
CMS-T-005217-B.1
CMS-T-005678-B.1
CMS-T-00000110-B.1
1 | About this operating manual
Diagrams
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
2

Example:
1. Instruction 1
or
Alternative instruction
2. Instruction 2
Instructions with only one action
Instructions with only one action are not numbered,
but rather shown with a arrow.
Example:
Instruction
Instructions without sequence
Instructions that do not require a specific sequence
are shown as a list with arrows.
Example:
Instruction
Instruction
Instruction
1.1.4 Lists
Lists without an essential order are shown as a list
with bullets.
Example:
Point 1
Point 2
1.1.5 Item numbers in figures
A framed number in the text, e.g. a
1
, indicates an
item number in an adjacent figure.
CMS-T-005211-C.1
CMS-T-005214-C.1
CMS-T-000024-A.1
CMS-T-000023-B.1
1 | About this operating manual
Diagrams
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 3

1.2 Other applicable documents
A list of other applicable documents can be found in
the Appendix.
1.3 Your opinion is important
Dear reader, our operating manuals are updated
regularly. Your suggestions for improvement help us
to create ever more user-friendly operating manuals.
Please send us your suggestions by post, fax or
email.
Fax: [phone]
Postfach 51
AMAZONEN-WERKE H. Dreyer SE & Co. KG
Technische Redaktion
D-49202 Hasbergen
E-Mail: [email protected]
CMS-T-00000616-B.1
CMS-T-000059-C.1
1 | About this operating manual
Other applicable documents
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
4

Safety and responsibility 2
2.1 Basic safety instructions
2.1.1 Meaning of the operating manual
Observe the operating manual
The operating manual is an important document and a part of the implement. It is intended for the user and
contains safety-related information. Only the instructions provided in the operating manual are reliable. If
the operating manual is not observed, it can result in serious injury or death.
The safety section must be completely read and observed before initial operation of the implement.
Before starting work, also read and observe each section of the operating manual.
Keep the operating manual in a safe place.
Keep the operating manual available.
Hand over the operating manual to the subsequent user.
2.1.2 Safe operating organisation
2.1.2.1 Personnel qualification
2.1.2.1.1 Requirements for all persons working with the machine
If the machine is used improperly, people can
be injured or killed. To prevent accidents due
to improper use, every person who works with
CMS-T-00007640-B.1
CMS-T-00007641-B.1
CMS-T-00006180-A.1
CMS-T-00002302-C.1
CMS-T-00002306-A.1
CMS-T-00002310-A.1
2 | Safety and responsibility
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 5

the machine must meet the following minimum
requirements:
The person is physically and mentally capable of
controlling the machine.
The person can safely perform work with the
machine within the scope of this operating
manual.
The person understands the functioning of the
machine within the scope of their work and can
recognise and prevent dangers arising during
operation.
The person head understood the operating
manual and can implement the information that is
conveyed in the operating manual.
The person must be familiar with safe driving of
vehicles.
For road travel, the person knows the relevant
road traffic regulations and has the prescribed
driving permit.
2.1.2.1.2 Qualification levels
For working with the machine, the following
qualification levels are provided:
Farmer
Agricultural helper
As a matter of principle, the activities described in this
operating manual can be performed by persons with
the qualification level "Agricultural helper".
2.1.2.1.3 Farmer
Farmers use agricultural implement to cultivate fields.
They decide on the use of an implement for a specific
purpose.
Farmers are basically familiar with working with
agricultural implements and can instruct agricultural
helpers in how to use the implements if necessary.
They can perform odd tasks and simple maintenance
and repair work on agricultural implements
themselves.
CMS-T-00002311-A.1
CMS-T-00002312-A.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
6

Farmers can be e.g.:
Farmers with higher education or training from a
technical college
Farmers by experience (e.g. inherited farm,
comprehensive practical knowledge)
Contractors who work by order of farmers
Activity example:
Safety training for agricultural helpers
2.1.2.1.4 Agricultural helpers
Agricultural helpers use agricultural implements by
order of the farmer. They are instructed on the use of
the implement by the farmer, and work independently
according to the work assignment from the farmer.
Agricultural helpers can be e.g.:
Seasonal workers and labourers
Prospective farmers in training
Employees of the farmer (e.g. tractor driver)
Family members of the farmer
Activity examples:
Driving the machine
Adjusting the working depth
2.1.2.2 Workplaces and passengers
Passengers
Passengers can fall, be run over and severely injured or killed due to machine movements. Ejected objects
can hit and injure passengers.
Do not let anybody ride on the machine.
Do not let anybody climb onto the driving machine.
CMS-T-00002313-A.1
CMS-T-00002307-B.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 7

2.1.2.3 Danger for children
Danger for children
Children cannot assess dangerous situations and can behave unpredictably. As a result, children are at a
higher risk.
Keep children away.
When you drive out or actuate machine movements,
make sure that there are no children in the danger area.
2.1.2.4 Operational safety
2.1.2.4.1 Perfect technical condition
Only use properly prepared machines
Without correct preparation according to this operating manual, operational safety of the machine is not
ensured. This can result in accidents and serious personal injury or even death.
Prepare the machine according to this operating manual.
Danger due to damage to the machine
Damage to the machine can impede the operational safety of the machine and cause accidents. This can
result in serious injury or death.
If you suspect or observe damage,
secure the tractor and implement.
Immediately fix any damage that can affect safety.
Fix the damage according to this operating manual.
Any damage that you cannot fix yourself according to this operating manual must be fixed by a qualified
specialist workshop.
Observe the technical limit values
Non-observance of the technical limits values of the machine can result in accidents and serious personal
injury or even death. Moreover, the machine can be damaged. The technical limit values can be found in
the Technical Data.
Comply with the technical limit values.
CMS-T-00002308-A.1
CMS-T-00002309-C.1
CMS-T-00002314-C.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
8

2.1.2.4.2 Personal protective equipment
Personal protective equipment
Wearing personal protective equipment is an important safety element. Missing or unsuitable personal
protective equipment increases the risk of damage to health and personal injury. Personal protective
equipment includes: work gloves, safety shoes, protective clothing, breathing protection, hearing protection,
face protection, and eye protection
Determine the personal protective equipment required for each job and have it ready.
Use only protective equipment that is in proper condition and offers effective protection.
Adjust the personal protective equipment to the person, e.g. the size.
Observe the manufacturer's instructions regarding operating materials, seed, fertiliser, crop protection
products, and cleaning agents.
Wear suitable clothing
Loosely worn clothing increases the risk of getting caught or entangled on rotating parts and getting stuck
on protruding parts. This can result in serious injury or death.
Wear close-fitting, snag-free clothes.
Never wear rings, necklaces and other jewellery.
If you have long hair,
wear a hairnet.
2.1.2.4.3 Warning symbols
Keep warning symbols legible
Warning symbols on the machine warn you of risks in danger areas and are an important element of
the machine's safety equipment. Missing warning symbols increase the risk of serious and lethal personal
injury.
Clean dirty warning symbols.
Immediately replace any damaged and illegible warning symbols.
Put the intended warning symbols on spare parts.
CMS-T-00002316-B.1
CMS-T-00002317-B.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 9

2.1.3 Knowing and preventing dangers
2.1.3.1 Safety hazards on the machine
Liquids under pressure
Escaping high pressure hydraulic fluid can penetrate into the body through the skin and cause serious
personal injuries. A hole the size of a needle can already result in serious personal injuries.
Before you uncouple the hydraulic hose lines or check for damage,
depressurise the hydraulic system.
If you suspect damage on a pressure system,
have the pressure system checked by a qualified specialist workshop.
Never look for leaks with your bare hands.
Keep your body and face away from leaks.
If liquids penetrate the body,
consult a doctor immediately.
CMS-T-00007642-A.1
CMS-T-00002318-D.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
10

2.1.3.2 Danger areas
Dangers areas on the implement
The following basic dangers are encountered in
the danger areas:
The implement and its work tools move during
operation.
Hydraulically raised implement parts can descend
unnoticed and slowly.
The tractor and implement can roll away
unintentionally.
Materials or foreign objects can be ejected out of
or away from the implement.
If the danger area is not observed, it can result in
serious personal injury or death.
Keep people out of the danger area of the
implement.
If people enter the danger area,
immediately switch off the engines and
drives.
Before you work in the danger area of the
implement,
secure the tractor and implement. This also
applies for quick checking work.
CMS-I-00005448
CMS-T-00007643-A.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 11

2.1.4 Safe operation and handling of the machine
2.1.4.1 Coupling implements
Coupling the implement on the tractor
Incorrectly coupling of the implement to the tractor results in hazards that can cause serious accidents.
There are crushing and shear points in the area of the coupling points between the tractor and the
implement.
If you couple or uncouple the implement to or from the tractor,
be very careful.
Use only suitable tractors for coupling and transporting the implement.
When the implement is coupled onto the tractor,
make sure that the tractor's connecting device meets the implement requirements.
Couple the implement properly to the tractor.
2.1.4.2 Driving safety
Risk when driving on roads and fields
Any mounted or towed implement as well as front or rear ballast weights on the tractor influence the driving
behaviour and the steering and braking power of the tractor. The driving characteristics also depend on
the operating condition, the fill level of the load, and on the ground. If the driver does not take account of
changing driving characteristics, he can cause accidents.
Always ensure that the tractor's steering and braking systems are operating correctly.
The tractor must provide the required brake lag for the tractor and mounted implement.
Check the function of the brakes before moving off.
The tractor front axle must always be loaded with at least 20 % of the empty tractor weight to
ensure  steering power.
Use front ballast weights if necessary.
Always attach the front or rear ballast weights properly on the specified fixing points.
Calculate and observe the permitted payload for the mounted or towed implement.
Observe the permissible axle loads and drawbar loads of the tractor.
Observe the permissible drawbar load of the hitch device and drawbar.
Drive in such a way that you always have full control over the tractor with the mounted or towed
implement. In so doing, take your personal abilities into account, as well as the road, traffic, visibility
and weather conditions, the driving characteristics of the tractor, and the influence of the mounted
implement.
CMS-T-00002304-I.1
CMS-T-00002320-D.1
CMS-T-00002321-E.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
12

When driving on roads, risk of accident caused by uncontrolled lateral motions of the implement
Lock the tractor lower links for road travel.
Preparing the machine for road travel
If the machine is not properly prepared for road travel, it can result in serious traffic accidents.
Check the lighting and identification for road travel for proper function.
Remove coarse dirt from the implement.
Follow the instructions in the section "Preparing the implement for road travel".
Parking the implement
The parked machine can tip over. People can be crushed and killed.
Only park the machine on stable and even ground.
Before you perform setting or maintenance work,
make sure that the implement is in a stable position. In case of doubt, support the implement.
Follow the instructions in the section "Parking the implement".
Unsupervised parking
Parked tractors with coupled implements that are insufficiently secured and unsupervised represent danger
for people and playing children.
Before you leave the machine,
shutdown the tractor and the implement.
Secure the tractor and machine.
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE 13

2.1.5 Safe maintenance and modification
2.1.5.1 Changes on the implement
Only authorised design changes
Design changes and extensions can impede the functioning and operational safety of the machine. This
can result in serious injury or death.
Have any design changes and extensions performed only by a qualified specialist workshop.
To ensure that the operating permit remains valid in accordance with national and international
regulations,
ensure that the specialist workshop only uses conversion parts, spare parts and special equipment
approved by AMAZONE.
2.1.5.2 Work on the machine
Only work on the machine when it is at a standstill
If the machine is not standing still, part can move unintentionally or the machine can be set in motion. This
can result in serious injury or death.
Before performing any work on the machine, shutdown and secure the machine.
To immobilise the machine,
perform the following tasks
If necessary, secure the machine against rolling away with wheel chocks.
Lower lifted loads down to the ground.
Relieve the pressure in the hydraulic hose lines.
If you have to work on or under raised loads,
lower the loads or secure raised machine parts with a hydraulic or mechanical locking device.
Switch off all drives.
Actuate the parking brake.
Particularly on slopes, additionally secure the machine against rolling away with wheel chocks.
Remove the ignition key and carry it with you.
Remove the key from the battery circuit breaker.
Wait until all parts that are still running come to a stop and that hot parts cool down.
CMS-T-00002305-D.1
CMS-T-00002322-B.1
CMS-T-00002323-C.1
2 | Safety and responsibility
Basic safety instructions
MG6659-EN-GB | F.1 | 25.10.2022 | © AMAZONE
14
