AT-530 Quick Start Guide
Installation and access.......................................................................................................................2
Configure AT-530 to make VoIP calls...............................................................................................3
WAN Config .....................................................................................................................................3
SIP Config.........................................................................................................................................4
IAXConfig ........................................................................................................................................5
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

Installation and access
Installation:
Set up AT-530 as below:
When the AT-530 is connecting to your network.
You can use the “Sysinfo” button to obtainAT-530 WAN port IP.
Modify your computer’s IP address to the same network as AT-530
Key in AT-530’s IP address in the web browser and press enter, then you can access AT-530’s web
manage interface. Remember the account is admin/admin for administrator and guest/guest for
user.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

Configure AT-530 to make VoIP calls
WAN Config
Enter Network
Æ WAN Config to set the WAN setting:
AT-530 supports three different IP types: Static IP, Dynamic obtain IP (DHCP) and PPPoE. You
can use either of these IP types to connect the internet.
Use Static IP:
----Select “Static”;
----Enter the AT-530’s IP address in the “IP address” field.
----Set the “Netmask”, default 255.255.255.0
----Enter the AT-530’s upper gateway IP address(for example:Router) in the “Gateway” field
----Key in the DNS information in the “Primary DNS” and “Alter DNS” fields.
Use DHCP:
----Select DHCP
If you have a DHCP server in your network, AT-530 will automatically obtain the network
information from your DHCP server.
Use PPPoE:
----Select PPPoE
----Type your PPPoE dialup information in the PPPoE setting fields:PPPoE server(option),
Username and password.
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

Then the AT-530 will connect to the internet through PPPoE , and automatically obtain the IP
address , Netmask, Gateway, Primary DNS and Alter DNS information.
SIP Config
Enter VoIP
Æ SIP Config setting page and set the sip information
----Register ServerAddr : sip server address;
----Register Server Port : sip serverre register port;
----Register Username : username of your sip account;
----Register Password : password of your sip account;
----Register Number : Phone number of your sip account; the same as username if none
----check Enable Register；
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

IAXConfig
-----IAX Server Addr: IAX server address;
-----IAX Server Port: IAX server register port;
-----Account Name: username of your IAX account;
-----Account Password: Password of your IAX account.
-----Local port: Signal port of local,default port is 4569
-----Phone Number: Phone number of your IAX account; the same as username if none
-----Enable Register: enable or disable register
-----IAX(Default Protocol): If you want to use IAX account to call ,please select
IAX(Default Protocol), if not the system will choose SIP as default
Then you can make VoIP calls if the WAN and SIP config is correct.
Notice: Please go to the “Config Manage” and save the config, otherwise you will lose the setting
after device reboot.
