BROSA Kaneko Extendable Dining Table User manual

ASSEMBLY GUIDE
Kaneko Extendable Dining Table
v1.0

Components
Upon unpacking your table from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new table.
A x 4
(Cross Dowel)
B x 8
(Threaded Rod)
C x 8
(Flat Washer)
D x 8
(Lock Washer)
E x 8
(Hex Nut)
F x 1
(Spanner)
Hardware
What you need
Leg x 4Table top x 1 Extension Leaf x 1

Step 1 Insert the cross dowel (A) into the top hole of the leg
so that the mark faces the bolt hole. Repeat for all
four legs.
Step 2 Screw two threaded rod (B) into the corner holes.
Repeat for all four legs.
A x 4
B x 8
A
B
B

Step 3 Place the table top on a at surface with underside
facing up. Fit a leg into a corner with the rod pro-
truding from the metal connector. Fit a washer (C), a
lock washer (D) then a hex nut (E) to the threaded
rod and tighten with the spanner (F). Repeat to
secure the second rod. Repeat for the remaining legs.
Lock the extension slides up by turning the rubber
switch up.
C x 8
D x 8
E x 8
F x 1
CD
EF

Step 4 Gently ip the table the right way up.
Step 5 To extend the table, take the extension leaf out of the
storage bag.

Step 6 Unlock the rubber switch under the table top and
slide two halves apart.
Step 7 Insert the extension leaf into the formed space.
Make sure the dowels are aligned correctly. Fit the
extension leaf to one side rstly.

Step 8 Push the two halves of the table top panel to make
all dowels t into corresponding holes. Lock the
rubber switch again.
Step 9 To switch back to the compact table again unlock
the switch underneath the table top and slide the
two halves apart. Take the separated extension leaf
out.

Step 10 Place the extension leaf back into the storage bag
and close it.
Step 11 Hide the bag under the table top and close it.

Step 12 Enjoy your new extendable table!
