BROSA Romulus Extendable Dining Table User manual

ASSEMBLY GUIDE
Romulus Extendable Dining Table
v1.0

Components
Hardware
A x 6
Spec: 5/16 x 35
B x 6
Spec: Ø8 x Ø14
D x 4 F x 1
Spec: Ø10 x 40
E x 4
Spec: M8
G x 1
Spec: 10g
I x 1
Spec: 5#
J x 2
Spec: 14#
C x 2
Spec: M8 x 95
H x 4
Spec: Ø38
Leg x 2
What you need
2
2
1
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit
www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it
out right away.

Step 1
Step 1.1
D x 4
E x 4
C x 2
1.1 Insert the wooden dowel (F) into the middle hole
of a leg (2) as shown in the diagram. Insert the
threaded rods (C) into each of the outer holes. Align
the two legs (2) to each other and rmly press them
together. Fit a half-lunar washer (D) to one end of the
threaded rod followed by a nut (E). Repeat this for the
other end of the rod (C) and then repeat this for the
other rod.
1.2 Tighten the nuts on both sides at the same time
using the spanners (J).
1.3 Cover the holes with the caps (H).
F x 1
F
D
C
GE
H x 4
G x 1
J x 2
Step 1.2
Step 1.3
* It is optional to
apply glue (G) to the
wooden dowel. Glue
could strengthen the
joints but also leave
the joints non-de-
tachable. JJ
H
2
2

Step 2 Align the leg structure formed in Step 1 to the under-
side of the table top (1) so that all of the screw holes
overlap. Fit a washer (B) to a bolt (A) and screw into
each hole and use the Allen key (I) to tighten all in
place.
Gently lift the table and place it upright on a level
surface.
B x 6
I x 1
A x 6
A
B
I
1

Step 3 To extend the table:
3.1 Under the table unlock the slides by lifting the
rubber locks on both sides.
3.2 Release both of the metal locks by lifting the
latch and unhooking the loop.
Warning: before moving the table (anytime), ensure
that all of the locks and slides are locked.
Step 4 Pull the two halves of the table top until they are
fully extended. Flip and unfold the extension leaf to
be level with the top surface of the table.
x 2
x 2
Step 3.1
Step 3.2

Step 5 Push either side of the two halves and rmly press
the two halves and the leaf together. Under the table
relock all of the metal locks by hooking the loop and
pulling down the latch. Lock the slides on both sides
by pressing down the rubber locks. Now the extend-
ed table is ready for use. Reverse the process to
switch the table to the compact form.
x 2
x 2

Step 6 Enjoy your new extendable dining table!
