BVL V-LOAD Shear User manual

ENGLISH
Operating manual
V-LOAD Shear
Top 160, 180
Mega 180
Rev. 3 /02.17 Art. no. 94207
Printed in Germany –translation of the original operating
manual
www.bvl-group.de

2
Unloading Technology V-LOAD Shear Top + Mega
Dear Customer,
This shear grab is a top quality product manufactured by Maschinenfabrik Bernard van Lengerich
GmbH & Co. KG.
In order to fully utilize the many advantages of your newly acquired shear grab, please read this
operating manual carefully before commissioning this accessory equipment.
Please also ensure that every person involved in the operation of the machine has read this operating
manual before commissioning the shear grab.
Maschinenfabrik Bernard van Lengerich GmbH & Co.
Manufacturer's address
Bernard van Lengerich
Maschinenfabrik GmbH & Co. KG
Operations: Grenzstrasse 16 • 48488 Emsbüren, Germany
Post address: Postfach 1154• 48488 Emsbüren, Germany
Tel : [phone]
Fax : [phone] (Administration)
[phone] (Spare parts / Service)
Internet: http://www.bvl-group.de
E-mail: info @ bvl-group.de
EC Declaration of Conformity
According to EC Directives
2006/42/EC (MD)
Bernard van Lengerich Maschinenfabrik GmbH & Co. KG Grenzstr.16, 48488 Emsbüren,
Germany,
declares under sole responsibility that the product
Series: V-LOAD Shear
Type: Top 160, Top 180, Mega 180
Year of manufacture: ………………………….
Machine number: ...................................
to which this directive refers is in conformity with all basic occupational health and safety regulations
stipulated in EC Directive 2006/42/EC.
To effect correct application of the safety and health requirements stated in the EC Directive, the
following standards and/or technical specifications have been consulted:
DIN EN ISO 12100; DIN EN 13857;
DIN EN 349; DIN EN ISO 4413; DIN EN 4254-1; DIN EN 703
........................................................................................................................................................................................
(Name and / or number of the standard(s) and / or technical specification(s))
Emsbüren, on February , 2017
…………………………………….
Bernard van Lengerich
Managing Director

Identification data
Unloading Technology V-LOAD Shear Top + Mega
3
Identification data
Enter the identification data of the accessory equipment here.
The identification data is specified on the type plate.
Machine number:
Type:
Year of manufacture:
Manufacturer's address
Bernard van Lengerich
Maschinenfabrik GmbH & Co. KG
Operations:
Post address:
D-48488
Tel.:
Fax.:
Internet:
E-mail:
Grenzstrasse 16
Postfach 1154
Emsbüren
+ 49 (0) 5903 951-0
+ 49 (0) 5903 951-34
http://www.bvl-group.de
[email protected]
Spare part orders / Service
For the address, see the manufacturer's address
Tel.:
Fax.:
Mobile:
Internet:
E-mail:
+ 49 (0) 5903 951-48
+ 49 (0) 5903 951-37
+ 49 (0) 172 281 63 22
http://www.bvl-group.de
[email protected]
When ordering spare parts, always provide the series, type,
accessory equipment number and the year of manufacture of the
accessory equipment.
Formal information about this operating manual
Document number:
94207
Date created:
2/18/2017
Copyright
Bernard van Lengerich
Maschinenfabrik GmbH & Co. KG, 2012
All rights reserved.
Reprints, even in excerpts, only with the written permission of Bernard
van Lengerich Maschinenfabrik GmbH & Co. KG.

Preface
4
Unloading Technology V-LOAD Shear Top + Mega
Preface
Dear Customer,
You selected a quality product from the extensive product range of
Bernard van Lengerich Maschinenfabrik GmbH & Co. KG. We would
like to thank you for putting your trust in us.
After receiving your accessory equipment, verify that no transport
damage has occurred and that all parts are present! Use the delivery
note to check if the shipment of your accessory equipment is
complete and also includes the special equipment you ordered.
Claims for damages cannot be accepted unless submitted without
delay!
Read and observe this operating manual and, in particular, the safety
instructions before putting your equipment into operation. After
reading this information carefully, you can immediately start enjoying
all the benefits of your recently purchased accessory equipment.
Make sure that all personnel operating the accessory equipment have
read this operating manual before putting the accessory equipment
into operation.
Special equipment is available for all accessory equipment. When
customizing your accessory equipment, you may find that not all
descriptions contained in this operating manual apply to your specific
accessory equipment. Special equipment is identified in this operating
manual.
If you have any questions on how to handle your accessory
equipment or regarding this operating manual, please contact us.
Regular maintenance and the timely exchange of worn or damaged
parts will increase the service life of your accessory equipment.
User evaluation
Dear reader,
our operating manuals are revised on a regular basis. You help us
increase the user friendliness of our operating manuals by sending us
your tips and recommendations on how we can improve them. Please
submit your suggestions by fax.
Bernard van Lengerich
Maschinenfabrik GmbH & Co. KG
Operations:
Post address:
D-48488
Tel.:
Fax.:
E-mail:
Grenzstrasse 16
Postfach 1154
Emsbüren
+ 49 (0) 5903 951-0
+ 49 (0) 5903 951-34
[email protected]
