JSI Reef User manual

Installation Instructions
Wall Dependent Layered Table
with Bookshelf
Recommended Tools
Page 1 of 3Reef
Package Contents Hardware Used
1/4 x 1”Machine Bolts
#8 x 5/8 ”Flat Head Wood Screws
#8 x 5/8 ”Pan Head Wood Screws
1/4 - 20 x 3/4 ” Socket Head Cap Screws
(Used with Foot Rail option)
Top
End Panels
Stretcher Rail
Shelf
Step 1
Attach Stretcher Rail to End Panels
• Stand End Panels upright and attach Stretcher Rail
using 1/4 ”bolts. Tighten bolts firmly.
Note: Two people are recommended for assembly.
1/4 x 1”Bolts
#2 Phillips Head Bit
#2 Phillips Screw Driver
Screw Gun
Level
Socket
Wrench
7/16 ”
Socket
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-RE007
5/1/16

Installation Instructions
Page 2 of 3
Wall Dependent Layered Table
with Bookshelf (continued)
Reef
Step 2
Attach Worksurface to Frame
• Place worksurface onto frame. Align edges accordingly.
• Fasten top to frame using all under surface brackets.
Use #8 x 5/8 ” flat head screws on triangle brackets
and #8 x 5/8 ” pan head screws on L-brackets.
Step 4
Level Table
• Position table against wall in desired
location. Level front-to-back and
side-to-side by rotating adjustable
glides.
Step 3
Attach Shelf
• With shoulder bolts facing down and bracket
cutouts towards the back, slide shelf into
place under worksurface.
• Align shoulder bolts in bottom of shelf into
slotted cutouts. Push shelf forward to engage
shoulder bolts into Mod-eez brackets.
• Fasten shelf to L-brackets using #8 x 5/8 ”
pan head screws. Shoulder
Bolt
Mod-eez
Bracket
#8 x 5/8 ”
Flat Head Screws
#8 x 5/8 ”
Pan Head Screws
#8 x 5/8 ”
Pan Head Screws
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-RE007
5/1/16

Installation Instructions
Table Options
Page 3 of 3Reef
Coat Hook
Attach Coat Hooks to End Panels
• Pilot holes have been factory pre-drilled for the two
coat hook locations. Use these holes and #8 x 5/8 ”
flat head screws to attach hooks to end panels.
Wall Dependent Layered Table
with Bookshelf (Options)
Coat Hook
Foot Rail
Foot Rail
Attach Foot Rail to End Panels
• Locate foot rail holes towards the bottom of end panels.
• Carefully slide foot rail into place between end panels.
Note: Bottom of end panel may need to pulled out slightly as
not to scratch/mar inside surfaces.
• Fasten using 1/4 - 20 x 3/4 ” Socket Head Cap Screws.
Pilot Holes
#8 x 5/8 ”
Flat Head Screws
Threaded
Metal Inserts
Slightly pull bottom of end panel
outward in order to slide foot rail
into place without marring surfaces
Flange points
down & inward
towards center
of table
Coat Hooks
3/16 ”
Hex Wrench
1/4 - 20 x 3/4 ”
Socket Head
Cap Screw
Coat Hook
Foot Rail
#8 x 5/8 ”
Flat Head
Wood Screws
1/4 - 20 x 3/4 ”
Socket Head
Cap Screws
