JSI CAAV User manual

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
Hardware enclosed
CAAV
BOLSTER INSTALL
STEP 1:
•Turn unit on side you will not be applying the
bolster to. Place on a furniture blanket or foam
•Set bolster on the side of the unit to locate
where straps need to be fall “front-to-back”
(see Fig A)
•Attach the “D”Rings to the bottom of the rail in
the position where the straps will fall with the
screws as shown. (see Fig B)
•When using with sectional pieces locate the
“D”Rings at the edge of the dustcover (black
material on bottom of unit) as shown. Take
care when applying screws thru upholstery.
Use the hand drive only and go very slowly to
prevent pulling threads or damaging the
fabric. (see Fig C)
Bolster comes with
pre-installed straps
for use with modular
units.
“D” Rings – 2 per Bolster
#8 x ½ pan head screws –2 per Bolster
(2)Extension
straps for use
with sectional
units included
Fig A
Fig B
Fig C

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
Hardware enclosed
CAAV
STEP 2:
•Clip the bolsters straps to the “D”Ring as shown for
modular use
•Clip the bolster to the extension straps and then to
the “D”Ring as shown for sectional use.
•Set the bolster on the seat of the unit that it’s
attached to.
STEP 3:
•Slide adjoining unit next to the unit bolster is
attached to.
•Link together using ganging brackets (separate
instructions)
•Installation complete
BOLSTER INSTALL
“D” Rings – 2 per Bolster
#8 x ½ pan head screws –2 per Bolster
