Impulse G2 assembly instructions

2ofs.com imagine a place® 800.521.5381 Assembly instructions
Impulse G2 assembly instructions
Part #: 1101589
Top, end and back attachment
Top to top/end to back connection:
Modular end to modular back connection:
Modular end/back to modular top connection:
Modular support panel connection:. Support
panel
To p
End panel Back/modesty
End panel Back
Back
End panel
To p
To p
A
B
12"
1. Detail A- attach clamp plates to desk/credenza using
(2) #8 x ⅝" screws per plate. Position the return
on top of clamp plates and attach with (2) #8 x ⅝"
screws and flat bracket.
2. Detail B- connect the end panel and back panel with
(4) #8 x ⅝" screws and flat plate.
1. Attach end to back using (1) 27 ¾" L-bracket and (10)
#8 x ⅝" screws while keeping outside face of end
and edge of back flush.
1. Attach end to top using (3) 2 ½" L-bracket evenly
spaced and attach back to top using (2) ½"
L-brackets every 12" in spacing. Use (4) #8 x ⅝"
screws per bracket. Keep back edge of top and back
face of modular back flush. Also keep outside face
edge of end flush with edge of top.
1. Attach edge of support panel to inside face of back
using (2) 27 ¾" L-brackets (one per side) using (10)
#8 x ⅝" screws per brackets.
2. Attach support panel to top using (4) 2 ½" L-brack-
ets (two per side) using (4) #8 x ⅝" screws per
bracket.

3ofs.com imagine a place® 800.521.5381 Assembly instructions
Impulse G2 assembly instructions
Part #: 1571835
Wall mounted storage installation
1. Determine desired location of unit. Be sure to
leave enough space below unit for computer
monitors or other equipment that may be placed
under the cabinet.
Measure from the floor to where the top of the
cabinet will be and lightly draw a level, horizontal
line (Line A) using a carpenter's level.
2. Draw another line (Line B) 6.25" below line A. This
is where the mounting rail will be fastened to
the wall.
3. Drill holes for appropriate wall fasteners through
mounting rail.
Align bottom edge of mounting rail on Line B and
mark location of mounting holes.
Fasten mounting rail to wall.
4. Hang cabinet on mounting rail.
The mounting rail attached to the back of the
cabinet will rest on the wall mounted rail.
Secure unit to wall by screwing # 8 x 1 ¼" pan
head screw(s) (HK-100) into back panel.
Line A
Line B
6.25"
Desired
height
4"
Side view
