Ofs Slate collaborative User manual

Slate collaborative assembly

2ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Table of contents
Tools required and parts 3-4
Step 1: Position lower credenza unit 5
Step 2: Attach upper credenza unit 6
Step 3: Attach slide-out markerboards 7
Step 4a: Attach end storage cabinets 8
Step 4b: Attach end panels 9
Step 5a: Attach overlay assemblies 10
Step 5b: Attach overlay assemblies 11
Step 6: Attach drawer storage unit 12
Step 7: Attach extension worksurface 13-14
Step 8: Attach end caps 15

3ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
1. Drill
2. Tape measure
3. Level
Tools required
Parts
1. NOTE: Not all parts listed below will be included with your selection. Some features are
optional and will only be present if selected with your Slate set-up.
1 2 3
End storage cabinet
(optional)
Lower
credenza unit
End panel

4ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Upper
credenza unit
(shown with optional
markerboard attachment)
Drawer
storage unit (optional)
End cap
Overlay assembly
(shown with optional drawer
or worksurface attachment)
Markerboard
(optional)
Parts continued

5ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 1: Position lower credenza unit
1. Place the lower credenza unit into it’s permanent location. The workspace assembly will be too
heavy to move once it is fully assembled. Ensure that the credenza unit is level at this time.

6ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 2: Attach upper credenza unit
1. Place the upper credenza unit onto the lower credenza unit. Position both units such that all
outside surfaces are flush with one another. Also, make sure the cord management hole in the
center of the units are aligned with each other.
2. With both units in their proper position, fasten together by inserting the supplied screws from
the HK-48 kit through the upper credenza and into the lower credenza.
(8) #8 x 1 /"

7ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 3: attach slide-out markerboards
1. NOTE: The markerboards are an optional feature. Disregard this step if it is not part of
your selection.
2. Begin by identifying all parts of the drawer slide. The inner track is attached to the
markerboard, the outer track and slide are mounted to the upper credenza.
3. Attach markerboard by inserting inner track onto slide. Making sure both parts are aligned
into each other’s groove, slide markerboard in completely until it reaches the slide stop.
4. Slide markerboard in and out to check for correct, smooth operation and to make sure the
inner track is locked into place and does not slide out when fully extended.
Slide stop
Outer track
Inner track
Slide
Slide
Inner track
Outer track

8ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 4a: Attach end storage cabinets
1. Note: This step is instructed for units with end
storage cabinets. If end panels are part of your
selection, see step 4b.
2. Position the end storage cabinet next to the
credenza assembly. Level storage cabinet and
make sure all surfaces are aligned and flush with
one another.
3. Slide markerboard out to gain access to the
mounting holes for the end storage cabinets.
4. Attach cabinet by fastening the supplied screws
from the HK-48 kit through the credenza
assembly and into the storage cabinet as shown
above. Repeat for remaining end storage cabinet.
(10) #8 x 1 /"
Note: views shown without markerboards for
clarity purposes.

9ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 4b: Attach end panels
1. Note: This step is instructed for units with end
panels. If end storage cabinets are part of your
selection, see step 4a.
2. Position the end panel next to the credenza
assembly. Level panel and make sure all surfaces
are aligned and flush with one another.
3. Attach panel by fastening the supplied screws
from the HK-48 kit through the credenza
assembly and into the panel as shown above.
Repeat for remaining end panel.
(10) #8 x 1 /"

10ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
1. NOTE: The overlay assembly size will vary depending on your selection. The instructions
detailed below are for all sizes that will have a drawer storage unit or extension worksurface
attached to it.
2. If the markerboards are extended, slide them completely back in.
3. Take note of the notched support rail on the top of the credenza assembly and the support
rail and cleats on the underside of the overlay assembly.
4. Lift overlay assembly up and onto the credenza assembly, lining up the cleats with the
notches on the support rail as shown above. Gently tap on the overlay assembly so that the
mitered sections of the support rails will be fully seated.
5. Repeat for remaining overlay. Make sure the top sections of the overlay assemblies are flush
as well as the side surfaces. With both overlays in their proper position, fasten down using
the supplied #8 x 2 /" wood screws as shown.
Step 5a: Attach overlay assemblies
Panel shown transparent
for clarity purposes

11ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
1. Note: The overlay assembly size will vary depending on your selection. The instructions
detailed below are for all sizes that are plain and will have nothing attached to it.
2. Take note of the notched support rail on the top of the credenza assembly and the support
rail and cleats on the underside of the overlay assembly.
3. Lift overlay assembly up and onto the credenza assembly, lining up the cleats with the
notches on the support rail as shown above. Gently tap on the overlay assembly so that the
mitered sections of the support rails will be fully seated.
4. Repeat for remaining overlay. Make sure the top sections of the overlay assemblies are flush
as well as the side surfaces.
Step 5b: Attach overlay assemblies
Panel shown transparent
for clarity purposes

12ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
Step 6: Attach drawer storage unit
1. Note: The drawer storage unit is an optional feature. Disregard this step if it is not part of
your selection.
2. Begin by removing the drawer boxes from the storage unit. Drawer boxes can be removed
by pulling box slightly out and locating the plastic lock clips on the side of the inner tracks of
the drawer slide. Next, press down on one of the lock clips while lifting up on the other lock
clip and pull box out completely from the drawer slide.
3. Position storage unit up against the overlay assembly. Making sure the storage unit is flush
against the edges, fasten the supplied screws from the HK-55 kit through the storage unit
and into the overlay assembly as shown above.

13ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
1. NOTE: The extension worksurface is an optional feature. Disregard this step if it is not part of
your selection.
2. Attach the apron rails to the table base using the supplied screws from the HK-10 kit at the
spacing specified above. Slide table base and rail assembly directly against the credenza
assembly. Making sure the table base and apron rails are level and square, fasten to the
credenza assembly using the remaining screws from the HK-10 kit.
Step 7: Attach extension work surface
Apron rail
3.25" 3.25"

14ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
3. Place the worksurface onto the table base assembly and slide directly against the
overlay assembly. Center the worksurface with the table base and attach to the overlay
by fastening the supplied screws from the HK-55 kit through the worksurface and into
the overlay.
4. Fasten the table base to the worksurface by inserting the supplied screws from the
HK-15 kit through the base and into the underside of the worksurface. With the top
secured, attach the apron rails to the underside of the worksurface using the supplied
screws from the HK-67 kit.
#10 x 1 /"
#8 x 1 /"
#10 x /"
#8 x 2 /"

15ofs.com imagine a place® 800.521.5381 Assembly instructions
Slate collaborative assembly
1. Place end cap on top of workspace and carefully press inward until the end cap has reached
the support rails on the overlay assemblies.
2. Repeat for remaining end cap. Assembly is now complete.
Step 8: Attach end caps
