Ofs Staks benching assembly User manual

Staks benching assembly

2ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
Table of contents
Base assembly 3
Organizer installation 4-5
Privacy screen installation 6
Worksurface installation 7
Top strap installation 8-9
Power installation - premium and basic kits 10-11
Power installation - economy kit 12-13
Top strap installation & cable basket assembly 14
Cable basket installation 15

3ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Begin assembly of bench in its permanent location. Once assembled the bench will
be dicult to move.
2. Attach T-nuts to H-bases using M6 x 16mm (Part #: 1416448) screws. Screw
through mount plate from below and into T-nut.
3. Screw into T-nut only two or three turns, DO NOT tighten.
4. Attach toolbar by sliding T-nut into bottom grooved section of toolbar.
5. Align H-bases so they are perpendicular to the toolbars and all toolbars are in
a straight line.
6. Toolbars must be flush to edge of outside bases and centered on the middle base(s).
7. When toolbars are properly located, tighten screws.
Base assembly
9 0˚
Align H-bases
Ships with H-base
Part #: 1552073
T-nut
T-nut
Center base model:
6-42CHBA1
6-30CHBA1
Model numbers:
6-64HBA2
6-48HBA2
“O” leg model
Numbers:
6-64OBA2
6-48OBA2
Longer than end
base T-nut
Part #: 1552074

4ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Attach stanchion to bottom of organizer by screwing #8 x 1" screws through
stanchion into pre-bored pilot holes.
2. Remove extrusions from toolbar.
3. Upper extrusions will not be present if wood privacy panels are to be installed.
4. Take note of holes bored through toolbar.
5. The holes in the bottom of the stanchions will align with the holes in the toolbar.
Organizer installation
Stanchion
Model number: 6-SSS
Upper
extrusion
Lower
extrusion

5ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
6. Determine distances shown above and cut extrusions to match.
7. Extrusions can be cut with a utility knife.
8. Replace extrusions leaving space for stanchions.
9. Drop organizers in place.
10. Make sure the holes in the bottom of the stanchions are aligned with the holes in the toolbar.
11. Attach using screws that are included.
12. Straps are required after worksurfaces are attached. See page 8.
Distance ADistance A
Distance
B

6ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Install privacy screens into tool rails.
2. Use a RUBBER MALLET to work screen all the way in until seated on the bottom extrusion.
Privacy screen installation
3. Loosen T-nut screws and slide back H-base for access to bottom of toolbar.
4. Insert end caps into outside ends of tool rails.
5. Secure in place by threading set screw through the small hole in the end of the toolbar
and into the flange on the inside face of the end cap.
6. Reposition H-base and re-tighten T-nut screws.
7. The toolbar will again be flush to the H-base. The end cap will extend past the H-base.
End caps ship with tool rail kit.
Part #: 1565102

7ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Note: Support rails are used on 22", 30" and 36" deep tops that are wider than 48".
2. Position support rail on bottom side of worksurface 6” from user edge in center
of worksurface.
3. Attach with #10 x /" screws.
Worksurface installation
Equal
Distance
Equal
Distance
6"
1 /"
FLUSH
Straightener rails ship with tool rail kit
Model numbers:
SPTR66
SPTR60
SPTR54
SPTR48
4. Place work surfaces on H-bases with side flush to edge of H-base.
5. Leave 1 /" gap between back edge of work surface and tool bar.
6. Secure work surfaces to H-bases with #12 x 1" screws.

8ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Use M6 x 50mm screw to attach top strap to tool bar and stanchion.
Top strap installation
2. Secure top strap to bottom of
worksurfaces with eight (8) #8 x 1"
screws for each top strap.
Top Strap
Top strap ships with tool rail kit
Part #: 1552075
Part #: 1416448

9ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
3. Insert T-nut, angled face up, inside of grooved bottom of toolrail.
4. Use M6 x 16mm screw to attach top strap to T-nut inside of tool bar.
5. When tightening screw, T-nut should turn inside of groove and grip bottom of toolbar.
DO NOT screw top straps to worksurfaces until
after power blocks have been installed.
T-nut installation
T-nut
Part #: 1512929

10ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
1. Remove faceplates (held on with magnets), and end caps if installing premium
power blocks.
2. Hold power block up to bottom edge of toolbar so tabs are inserted into groove on
bottom of toolbar.
3. Power block should be centered on toolbar or centered in the work area if personal
storage boxes are used.
4. Expand tabs by inserting 5mm Allen wrench into Hex drive and turning clock-wise.
5. Tabs will expand and grip sides of toolbar groove.
Power installation - premium and basic kits
5mm
Allen
wrench

11ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
10. Snap in duplex receptacles according to power requirements (usually determined
by an electrician).
11. Place duplex receptacle inside receptacle block with clip pointing down and slide
sideways into terminal until receptacle clicks in place.
12. On premium power blocks, replace end caps and face plates after duplex
receptacles are installed.
O-ring
6. Plug in one jumper cable between two power blocks.
7. Jumper cable should pass through O-rings.
8. Jumper cable end must be pushed in until it snaps into place.
9. Plug in power in-feed into any receptacle block in the run.

12ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
Power installation - economy kit
3. Engage slotted grooves on top of double block system to flanges on block clips.
4. Slide forward until each receptacle block snaps into place.
T-nuts
Block clip
Part #: 1554819
1. Attach block clip to two T-nuts in toolbar using M6 x 10mm screws.
2. See T-nut installation instructions on page 9.

13ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
5. Plug in one jumper cable between two power blocks.
6. Jumper cable end must be pushed in until it snaps into place.
7. Install duplex receptacles as shown on bottom of page 10.

14ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
2. Assemble basket clamps with two small clamp plates on the top and on large clamp plate
on the bottom.
3. Clamps should be spaced so they are directly below the O-rings on the power block.
4. If the basket is on the end of a bench, the clamps should be shifted, if possible, so the basket
can be mounted towards the center of the bench.
5. Screw clamps together using four (4) M4 x 10mm screws per clamp.
1. Secure top strap to bottom of work surfaces with eight
(8) #8 x 1" screws for each top strap (HK-31).
Top strap installation and cable basket assembly
Clamp

15ofs.com imagine a place® 800.521.5381 Assembly instructions
Staks benching assembly
Power block mounted basket
1. Attach basket to O-rings on power block using
60mm Hex head bolt and 1 /" stando.
Toolbar mounted basket
1. Attach basket to T-nut in tool bar using 6"
Hex head bolt and 5 /" stando.
2. See T-Nut installation instructions on page 9.
Bolt
T-nut
Stand o
Stand o
Part #: 1512614
O-ring
Part #: 1512929
Part #: 1512615
(M6-1.00 x 150mm)
Bolt
Cable basket installation
