PROAIM P-WV-2 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
7' Wave-2 Video Jib Crane (P-WV-2)
Assembly Manua l
Video Crane Jib
Weight Shank 75 mm Bowl Allen key
Storage Bag

2
Camera Jib Setup
 Insert central fork of Jib arm into bowl of tripod stand, then aach boom clamp to it for secure
connecon.
NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That means
perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib. Also you may need
the assistance of a grip stand to hold the camera end of the arm during installaon prevenng it from
falling as it will be front heavy at this point. You may also need the grip stand or assistance at the rear of
the jib when mounng the camera.
 Now to extend the rear secon of jib, loosen the Allen bolts with provided Allen key and then, loosen
the knob as shown in the picture.
 Provided are the jib panning control knobs (as
shown in the picture). Loosen the knobs for smooth
pan movement of jib and ghten these knobs to
lock pan movement of jib.
 Then, loosen the knob provided at lower telescopic
secon of jib arm as shown in the picture to extend
front secon of telescopic jib accordingly to the rear
secon.

3
 Camera head mount is provided with a knob to
control 90° lt movement of camera. Loosen knob
for free lt movement of camera and ghten it to
lock movement.
 Aach weight shanks at rear end of jib secon by
screwing it in and then add weights to it.
NOTE: Make sure the opposite end of the jib arm is secured so that the addion of the weights does not
cause the arm to rise violently.
 Mount your uid head onto the bowl plate in order to aach the camera. And then nally, secure your
camera properly on the uid Head.

4
YOUR PROAIM 7’WAVE-2 VIDEO JIB CRANE
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
