Rollos Medium Plus Basis User manual

Montage- und
Bedienungsanleitung
assembly and operating instructions
notice de montage et mode d’emploi
subject to technical change
sous réserve de modications techniques
roller blinds – stores enrouleurs
technische Änderungen vorbehalten
8 / 2013
3
Rollos
Mediumrollo
Plus Basis
799 028 303
Entspricht EN 13120
Achtung
attention – attention
Kinder können sich in den Schlin-
gen von Schnüren, Ketten oder Gur-
ten zur Bedienung von Sicht- und
Sonnenschutzeinrichtungen ver-
fangen oder sich Schnüre um den
Hals wickeln und sich unter Umstän-
den dadurch strangulieren. Schnüre,
Ketten und Gurte sind außer Reich-
weite von Kindern zu halten, um Ver-
wicklungen und Strangulierungen
zu vermeiden. Betten, Kinderbetten
und Möbel sind entfernt von Bedie-
nungen für Sicht- und Sonnenschutz-
einrichtungen aufzustellen.
Children can get caught in the loops of cords,
chains or straps that operate window coverings or
they can wrap cords around their necks and stran-
gle thereby. Keep cords, chains and straps out of
reach of children to avoid entanglement and stran-
gulation. Move beds, cots and furniture away from
window covering operations.
roller blind Medium Plus Basis
store enrouleur Medium Plus Basis
Les enfants peuvent se prendre dans cordons, chaî-
nettes ou courroies qui actionnent les stores de
protection solaire et visuelle ou ils peuvent enrou-
ler les cordons autour leur cou et ainsi s’étrangler.
Maintenez les cordons, chaînettes et courroies hors
de portée des enfants pour éviter de s’étrangler ou
de s’emmêler. Placez les lits, berceaux et meubles à
l’écart des manipulations des stores de protection
solaire et visuelle.
according to EN 13120 – selon EN 13120

STANDARD- & DESIGNTRÄGER
Träger befestigen an/in: a Wand; b
Decke; c Fensterrahmen; d Nische
DESIGNTRÄGER
Abdeckung auf Designträger aufsetzen
DESIGNTRÄGER
Schraubenabdeckung aufschieben und
einrasten
Kettengetriebe in Träger setzen (1);
herunterschieben bis es klickt (2)
Gegenlager eindrücken;
auf Träger schieben
12
STANDARD  & DESIGN BRACKET
x the bracket on/in: a wall; b ceiling; c frame; d recess
SUPPORT STANDARD & DESIGN
xer le clip: a au mur; b au plafond; c au cadre; d en
embrasure
DESIGN BRACKET
put the cover onto the design bracket
SUPPORT DESIGN
pousser la cache sur le support design
DESIGN BRACKET
put the screw cover on the bracket and let it click into the
bracket
SUPPORT DESIGN
mettre la cache de vis au support et laisser-la enclecher
put the chain gear into the bracket (1); pull it down until
it clicks (2)
mettre la mécanisme de chainette au support (1); pous-
ser-le en bas jusqu‘à ce qu‘il clique (2)
push the end plug; put it onto the bracket
enfoncer la mécanisme butée, pousser-la sur le support
AMontage
BLeveler
installation – installation
adjuster – ajusteur
a
c
b
2
click
1
click
click
d
Slide the screw cover cap onto the bracket until it
snaps. When using design brackets.
Fix the bracket with the screws provided.
a on face wall b ceiling c on frame c in recess
Place the clutch in the bracket (1) and slide it down
until it clicks (2).
And snap it to the bracket. Slide the end caps onto
the brackets.
Place the tube adapter on the clutch head. Press the
bearing and lift the blind.
Make sure that the opening for the Allen key is
pointing downwards before installing the brackets.
Change the orientation by loosening the 2 screws
(M3 x 6) and turning the leveller 90°. Fix the screws.
Installation Option 1: Leveller (add on)
Place the leveller on the bearing side in the brack-
et. Make sure that the opening for the Allen key is
pointing downwards. Turn the leveller until it clicks.
Option 2: Leveller (integrated)
Insert the end cap into the design bracket. To adjust skewing, put the provided Allen key into
the screw of the leveller and turn it left or right to
move the blind up or down. Support lifting of large
heavy blinds with the palm of your hand.
a
c
b
2
click
1
click
click
d
Slide the screw cover cap onto the bracket until it
snaps. When using design brackets.
Fix the bracket with the screws provided.
a on face wall b ceiling c on frame c in recess
Place the clutch in the bracket (1) and slide it down
until it clicks (2).
And snap it to the bracket. Slide the end caps onto
the brackets.
Place the tube adapter on the clutch head. Press the
bearing and lift the blind.
Make sure that the opening for the Allen key is
pointing downwards before installing the brackets.
Change the orientation by loosening the 2 screws
(M3 x 6) and turning the leveller 90°. Fix the screws.
Installation Option 1: Leveller (add on)
Place the leveller on the bearing side in the brack-
et. Make sure that the opening for the Allen key is
pointing downwards. Turn the leveller until it clicks.
Option 2: Leveller (integrated)
Insert the end cap into the design bracket. To adjust skewing, put the provided Allen key into
the screw of the leveller and turn it left or right to
move the blind up or down. Support lifting of large
heavy blinds with the palm of your hand.
a
c
b
2
click
1
click
click
d
Slide the screw cover cap onto the bracket until it
snaps. When using design brackets.
Fix the bracket with the screws provided.
a on face wall b ceiling c on frame c in recess
Place the clutch in the bracket (1) and slide it down
until it clicks (2).
And snap it to the bracket. Slide the end caps onto
the brackets.
Place the tube adapter on the clutch head. Press the
bearing and lift the blind.
Make sure that the opening for the Allen key is
pointing downwards before installing the brackets.
Change the orientation by loosening the 2 screws
(M3 x 6) and turning the leveller 90°. Fix the screws.
Installation Option 1: Leveller (add on)
Place the leveller on the bearing side in the brack-
et. Make sure that the opening for the Allen key is
pointing downwards. Turn the leveller until it clicks.
Option 2: Leveller (integrated)
Insert the end cap into the design bracket. To adjust skewing, put the provided Allen key into
the screw of the leveller and turn it left or right to
move the blind up or down. Support lifting of large
heavy blinds with the palm of your hand.
1
6
2
3
4
Sechskantstiftschlüssel drehen um Rollo
nach oben oder unten zu bewegen
turn the hexagon key to move the roller blind up or down
tourner le clé imbus pour déplacer le store enrouleur en
haut ou en bas
a
b
click
2
1
X
.HHSWKHcliSX PPIURPWKHViGH)RUaZiGHU
blind divide the width between provided clips into
eTXal sections
)i[ the clip with the screws provided
a ceiling b wall
7Xrn the blind aboXt 
3ress the PoXnting pro¿le against the clip Xntil it
snaps
3lace the PoXnting pro¿le bottoP side on the clip
7Xrn it leIt or right to Pove the blind Xp or down
6Xpport liIting oI large heav\ blinds with the palP
oI \oXr hand
Installation
Option 2: Leveller (integrated)
7o adMXst skewing pXt the provided $llen ke\ into
the screw oI the leveller
Option 1: Leveller (add on)
7o adMXst skewing pXt the provided $llen ke\ into
the screw oI the leveller
Rollo in Halterung einrasten lassen, End-
kappe auf Träger drücken
click the roller blind into the bracket; put the end cap on
the bracket
enclecher le store enrouleur au support; pousser la cache
sur le support
a
c
b
2
click
1
click
click
d
Slide the screw cover cap onto the bracket until it
snaps. When using design brackets.
Fix the bracket with the screws provided.
a on face wall b ceiling c on frame c in recess
Place the clutch in the bracket (1) and slide it down
until it clicks (2).
And snap it to the bracket. Slide the end caps onto
the brackets.
Place the tube adapter on the clutch head. Press the
bearing and lift the blind.
Make sure that the opening for the Allen key is
pointing downwards before installing the brackets.
Change the orientation by loosening the 2 screws
(M3 x 6) and turning the leveller 90°. Fix the screws.
Installation Option 1: Leveller (add on)
Place the leveller on the bearing side in the brack-
et. Make sure that the opening for the Allen key is
pointing downwards. Turn the leveller until it clicks.
Option 2: Leveller (integrated)
Insert the end cap into the design bracket. To adjust skewing, put the provided Allen key into
the screw of the leveller and turn it left or right to
move the blind up or down. Support lifting of large
heavy blinds with the palm of your hand.
5
