Saxby Lighting Tribeca Wall Manual

Commissioning Instruction leaflet
Tribeca Wall
EL-40074
www.saxbylighting.com
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
Recycling advice
Safety information
Saxby Lighting Ltd. LS9 0SE
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
• Refit the product to the fixing bracket. Make sure the
product is correctly oriented as shown in the diagram on
the right.
• Tightenthescrewstosecure.
• Replacefuseorcircuitbreakerandswitchon.Yourlight
is now ready for use.
Iss.2 03092015
• TheLED'sinthisproductarenonreplaceable.
Fitting/replacing bulbs

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeandsatisfactory
operation of this product. Please retain these instructions for future reference.
Warning
This light fitting is Class 1 and must be connected to
an Earth circuit
Please read these instructions carefully before
commencing any work.
Thisunitmustbefittedbyacompetentandqualified
electrician.
Install in accordance with IEE Wiring regulations and
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
before installing or maintaining this fitting. Ensure other
persons cannot restore the electrical supply without
your knowledge. If you are in any doubt, please consult a
qualifiedelectrician.
Thislightfittingshouldbeconnectedtoacircuitwitha
30mARCDfitted.
If replacing an existing fitting, make a careful note of the
connections.
Thissystemcontainsnon-replaceablepartsandcannotbe
serviced. If damage occurs the part should be scrapped.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
ThisproductisratedatIP54.
Thisproductisnotsuitablefordimming.
Thisproductisnotsuitableforlocationinorneara
marine or sea environment.
Specification
Voltage: 240V 50Hz a.c.
Lamp: 9WLED(SMD5630)
IP rating: 54
Layout
Installation
Having correctly identified the wiring from your existing light
fitting, connect to the connection block inside the product in
the following way:
Wiring
Check that...
• Youhavecorrectlyidentifiedthewires.
• Theconnectionsaretight.
• No loose strands have been left out of the connection
block.
• Thelidhasbeenrefittedontotheconnectionblockcase
• Planthedesiredlayoutofthisfittingcarefully,ensuring
the cables will reach the distance between the junction
box and the light fitting
• Avoidlocatinganycablesinpositionsthatwould
cause a hazard. Position cables and junction boxes (not
supplied)awayfromareaswheretheymaybeatrisk
from being cut, trapped or damaged
• Cablesinwallsmustbeprotectedusingsuitable
conduit or plastic trunking.
• Themainssupplycablemusthaveaminimumcross
sectional area of 1.0mm²
•Thisproducthasspecialprotectionagainsttheingress
of moisture and is IP54 rated.
Existing fittings must be completely removed before
installation of a new product. Before removing the existing
fitting, carefully note the position of each set of wires.
• Removethefixingbracket.Useitasatemplate(ina
horizontalposition)tomarkthefixingholes.
• Threadthecablethroughthemiddlehole.
• Fixthebrackettothewallusingthescrewsandplugs
supplied Ensure the wall is capable of holding the
weightoftheproduct.Takecaretoavoiddamagingany
concealedwiringandpipes.Thecorrectfixingsshould
be used for brick or cavity walls.
• Wireasdetailedbelow.
NEUTRAL
EARTH (GREEN/YELLOW)
SWITCHED LIVE
BLUE (N)
GREEN/YELLOW
BROWN (L)
SUPPLY LIGHT FITTING
