SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
CONTENTS
CODE: 00ZMXLCX2/S1E
[1] PRODUCT OUTLINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
[2] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
[3] UNPACKING AND INSTALLATION
* For unpacking and installation, refer to the installation manual( [2] ).
[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES . . . . . . . . . . . . . . 4-1
[5] OPERATIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
[6] DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
[7] MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
[8] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
[9] SIMULATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
[10] SELF DIAG MESSAGE AND TROUBLE CODE . . . . . . . . . . . . . . . . . 10-1
[11] ELECTRICAL SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
DIGITAL FULL COLOR
MULTIFUNCTIONAL SYSTEM OPTION
LARGE CAPACITY TRAY
MX-LCX2
MODEL

CONTENTS
[1] PRODUCT OUTLINE . . . . . . . . . . . . . . . . . . . . . . . . 1-1
[2] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
[3] UNPACKING AND INSTALLATION
* For unpacking and installation, refer to the installation
manual( [2] ).
[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Motor, clutch, solenoid . . . . . . . . . . . . . . . . . . . . 4-1
2. PWB, sensor, switch, heater . . . . . . . . . . . . . . . . 4-2
[5] OPERATIONAL DESCRIPTION
1. Lift operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
2. Paper feed operation. . . . . . . . . . . . . . . . . . . . . . 5-1
3. Paper empty detection . . . . . . . . . . . . . . . . . . . . 5-2
[6] DISASSEMBLY AND ASSEMBLY
1.
Maintenance parts replacement procedures . . . . . 6-1
2. Each unit removal . . . . . . . . . . . . . . . . . . . . . . . . 6-1
3. Major parts removal . . . . . . . . . . . . . . . . . . . . . . 6-2
[7] MAINTENANCE
1. Maintenance system table . . . . . . . . . . . . . . . . . 7-1
[8] ADJUSTMENTS
1. List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
2. Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
[9] SIMULATION
1. List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
2. Details of trouble code . . . . . . . . . . . . . . . . . . . . 9-1
[10] SELF DIAG MESSAGE AND TROUBLE CODE
1. Self diag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
2. Trouble code list . . . . . . . . . . . . . . . . . . . . . . . . 10-2
3. Trouble code details . . . . . . . . . . . . . . . . . . . . . 10-2
[11] ELECTRICAL SECTION
1.
Electronic/mechanical parts relationship diagram . . . . 11-1
2. Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
3. Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

MX-LCX2 PRODUCT OUTLINE 1 – 1
MX-LCX2 Service Manual
[1] PRODUCT OUTLINE
This model is a large capacity paper feed tray installed to the main unit.
It stores 3,500 sheets, eliminating troublesome paper supply.
MX-LCX2

MX-LCX2 SPECIFICATIONS 2 – 1
MX-LCX2 Service Manual
[2] SPECIFICATIONS
Model Large capacity tray
Transport reference Center reference
Heat reserving heater Domestic: Heater kit support
Overseas: Service parts support
Paper capacity
Domestic Normal paper
(64g/m2,17 lbs bond) 4000 sheets
Overseas Normal paper
(80g/m2,21 lbs bond) 3500 sheets
Paper size/type/weight Refer to Table 1
Paper size detection Not provided (Manually setting from the control panel of the main unit)
Paper type setting Refer to Table 2
Paper size change system
Changeover by user No
Changeover by service man
(Adjustment of guide and entry of size) Yes
Factory setting of paper size
Domestic A4
Overseas, Inch series 8.5x11
Overseas, AB series A4
Remaining paper detection Paper empty and 6 steps
(100% ,83.3% ,66.7% ,50% ,33.3% ,16.7% ,Paper empty)
Tray lift time Up max. 15 sec.
Down max. 5sec.
Troubleshooting of paper jam Can be corrected without separating the unit.
Reliability MCBJ:Conforms to the main unit
MCBF:Conforms to the main unit
Life Conforms to the main unit
Power source Supplied from the main unit
Power consumption Normal operation: 26.4W
Lift up:40.8W
Dimensions(WxDxH) 370 x 550 x 525mm
14 9/16x21 41/64x20 21/32 inch
Occupying area(WxD) 370x550mm
14 9/16x21 21/32 inch
Weight Approx. 28kg, 61.7lbs
Installation/Maintenance Implemented by service man
Maintenance parts Paper feed roller
Optional detection Automatic detection
Bundled item Parts for installation
Table 1 : Paper size, type, weight
Paper size
A3W No
A3 No
B4 No
A4 Yes
A4R No
B5 Yes*1
B5R No
A5R No
12 No
11×17 No
8.5×14 No
8.5×13 No
8.5×11 Yes
8.5×11R No
7.25×10.5R No
5.5×8.5R No
8K No
16K No
16KR No
Postcard No
Envelope No
Special No
Kind/weight of
applicable
paper
Thin paper 55-59g/m2
15-16- lbs bond No
Normal paper 60-105g/m2
16-28 lbs bond Yes
Cardboard 1
(including gloss paper)
106-209g/m2
28+-56- lbs bond Yes
Cardboard 2 210-256g/m2
56-68 lbs bond No
Envelope 75-90g/m2
20-24 lbs bond No
OHP paper No
Label paper No
Tab paper No
*1)Setting of paper in B5 size is enabled in only Japan and overseas AB
series size paper is available.
Table2 : Paper type setting
Paper type
Normal paper Yes
Printed paper Yes
Recycled paper Yes
Letter head Yes
Perforated paper Yes
Color paper Yes
Cardboard 1 Yes
Cardboard 2 No
Thin paper No
Label paper No
OHP No
Tab paper No
Envelope No
Use type 1 to 7 Yes

MX-LCX2 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4 – 1
MX-LCX2 Service Manual
[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Motor, clutch, solenoid
No. Parts MODEL NOTE
Code Signal name Name Type Function/Operation Active condition
1 LPFM LPFM Transport motor Brushless motor Drives the paper feed, and the
paper transport section.
When paper feed is started,
"H" level.
2 LLM LLM Lift motor Brush motor Lifts the paper feed table.
When the lower limit sensor is
ON, "H" level. When the upper
limit sensor is ON, "L" level.
3 LTRC LTRC Transport clutch Controls ON/OFF of the
transport roller.
4 LPFC LPFC Paper feed clutch Controls ON/OFF of the paper
feed roller.
When paper feed is started,
"H" level. After starring
transport (pickup OFF), it is
turned OFF by the timer.
5LPFS LPFS Paper feed
solenoid
Presses the paper pickup
roller onto paper.
Turned OFF after starting
transport. Turned ON by the
timer.
* Lift-up - When paper empty
detection is made: ON
3
5
4
1
2

MX-LCX2 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4 – 2
2. PWB, sensor, switch, heater
No. Parts MODEL NOTE
Code Signal name Name Type Function/Operation Active condition
7 MAIN PWB - LCC main
PWB Controls and drives the LCC.
8LDD LDD Lower limit
sensor
The lower limit of the tray is
detected.
When the tray is at the lower
limit, "H" level.
9LRE LRE Lift motor
encoder
The lift motor rotation is
detected. Pulse signal
10 LCSW LCSW Cassette
detection The tray insertion is detected. When inserted, "H" level.
11 LTOD LTOD
The main unit
connection
sensor
Detects connection to the main
unit. When connected, "L" level.
12 LPFD LPFD Transport
sensor Detects paper transport. L level at paper remaining detection.
13 LUD LUD Upper limit
sensor
Detects the paper upper limit
position.
When "H" level (ON), the lift-up
motor stops.
14 LPED LPED
Paper
presence/
empty sensor
Detects paper presence/empty
on the paper tray.
When paper is detected, "L".
* When lifting up, if "L" with
LRE 800 pulse, the paper
feed solenoid is ON.
15 LLSW LLSW Upper limit
switch
Protects the paper feed unit
from breakage due to lifting the
tray too much.
16 LDSW LDSW Upper open/
close switch
Detects open/close of the upper
door.
17 DH DH Thermal
heater
Keeps temperature in the LCC
tray.
Japan
only
7
8
9
10
11
14
13
15 16
17
12

MX-LCX2 OPERATIONAL DESCRIPTION 5 – 1
MX-LCX2 Service Manual
[5] OPERATIONAL DESCRIPTION
1. Lift operation
When the main unit is turned ON, if the tray is at the lower limit
position (lower limit sensor: LDD ON position), the lift motor is
turned ON to lift the tray.
When the paper presence/empty sensor (LPED) is turned ON
within 800 pulses of the encoder signal from start of lifting up the
tray, the lift motor is turned OFF to stop the tray, and the paper feed
solenoid is turned ON to move down the pickup roller. After that,
the lift motor is turned ON to lift the tray. The tray is stopped when
the upper limit sensor (LUD) is turned ON.
If the paper presence/empty sensor (LPED) is not turned on within
800 pulses, the paper feed solenoid is turned ON with the lift motor
ON to move down the pickup roller. The lift motor is stopped at the
upper limit sensor (LUD) ON position, and the paper feed solenoid
is turned OFF.
When the machine power is turned on, if the tray is on the paper
feed position, lifting is not performed.
When the tray is pulled out, it moves down by its own weight.
Lifting up operation (When LPED is turned ON within 800 pulses of encoder.) Lifting up operation (When LPED is not turned ON within 800 pulses of encoder.)
2. Paper feed operation
When the tray is stationary at the paper feed position (upper limit
sensor: LUD ON position) and there is paper on the tray, paper
feed operation can be performed.
Paper feed operation is performed by the transport motor (LPFM),
the transport clutch (LTRC), the paper feed clutch (LPFC), and the
paper feed solenoid (LPFS) at the following timing.
When the transport clutch (LTRC) is turned ON with the transport
motor (LRFM) ON (rotating), the transport roller rotates. When the
paper feed clutch (LPFC) is turned on under this state, the paper
feed roller and the take-up roller rotate. When the paper feed sole-
noid (LPFS) is turned ON, the take-up roller is pushed down to
press paper.
LCC paper feed time chart
LLM
(Lift motor output)
LLD
(Lower limit sensor)
LUD
(Upper limit sensor)
LPED
(Paper empty detection)
LPFS
(Solenoid) Within 800 pulses
200 msec
LRE
(Encoder signal)
LLM
(Lift motor output)
LLD
(Lower limit sensor)
LUD
(Upper limit sensor)
LPED
(Paper empty detection)
LPFS
(Solenoid)
LRE
(Encoder signal)
Within 800 pulses
LPFM
(Transport motor)
LPFD
(Transport sensor)
TRC
(Main unit
synchronous signal)
LTRC
(Transport clutch)
LPFC
(Paper feed clutch)
LPFS
(Paper feed solenoid)
Paper feed start
Clearance-between-
papers control timer
PIC drop timer PIC drop timer PIC drop timer PIC drop timer
Clearance-between-
papers control timer
Clearance-between-
papers control timer
Clearance-between-
papers control timer
Resist stop
Resist stop Resist stop Resist stop
Paper feed clutch
OFF timer
Paper feed clutch
OFF timer
Paper feed clutch
OFF timer
Paper feed clutch
OFF timer
Paper feed clutch
OFF timer
Preliminary
paper feed start
First sheet
Preliminary
paper feed start
Second sheet
Preliminary
paper feed start
Third sheet
Preliminary
paper feed start
Fourth sheet
Preliminary
paper feed start
Fifth sheet
Preliminary paper
feed complete
Paper feed start
Preliminary paper
feed complete
Paper feed start
Preliminary paper
feed complete
Paper feed start
Preliminary paper
feed complete
Preliminary paper
feed complete

MX-LCX2 OPERATIONAL DESCRIPTION 5 – 2
3. Paper empty detection
When the tray lifts and stops at the paper feed position and during
paper feed operation, paper presence/empty is detected by the
paper presence/empty sensor (LPED).
When paper empty is detected in the tray during paper feeding,
paper feeding is stopped.
1 Paper feed roller clutch
2 Take-up roller
3 Paper feed roller
4 Paper feed solenoid
5 Transport clutch
6 Transport motor
7 Lift-up motor
3
4
51
2
6
7

MX-LCX2 DISASSEMBLY AND ASSEMBLY 6 – 1
MX-LCX2 Service Manual
[6] DISASSEMBLY AND
ASSEMBLY
1. Maintenance parts replacement
procedures
A. Paper feed roller
1) Pull the lever, and open the upper cover.
2) Remove the screw, and remove the sheet.
3) Remove the pawl, and remove the take-up roller and the paper
feed roller.
4) Remove the screw, and remove the paper guide block.
5) Remove the pawl, and remove the reverse roller.
2. Each unit removal
A. Paper feed unit
1) Pull out the tray.
2) Open the upper cover, and remove three screws.
3) Remove the upper cabinet.
4) Disconnect the connectors (2 positions).
5) Remove the screw, and remove the paper feed unit.

MX-LCX2 DISASSEMBLY AND ASSEMBLY 6 – 2
B. Paper feed tray
1) Pull out the tray.
2) Looser the stopper fixing screw (1) on the lower right side of
the paper tray, evacuate the stopper not to function.
3) Remove the screws from the left and right rail sections.
4) Remove the tray unit from the rail.
C. Drive unit
1) Remove the screw, and remove the rear cover.
2) Remove the connectors (2 positions).
3) Remove the screw, and remove the drive unit.
3. Major parts removal
A. Motor (Main)
1) Remove the screw, and remove the rear cover.
2) Disconnect the connector.
3) Remove the screw, and remove the motor.

MX-LCX2 DISASSEMBLY AND ASSEMBLY 6 – 3
B. Lift motor
1) Remove the drive unit.
2) Remove the E-ring, and remove the parts.
3) Remove the screw, and remove the cover.
4) Remove the screw, and remove the lift motor.
5) Remove the ring, and remove the pulley.
C. Clutch
1) Remove the paper feed unit. (Refer to "3. Each unit removal.")
2) Remove the screw, and remove the cover.
3) Remove the E-ring, and remove the parts.
4) Disconnect the connector, and remove the screw.
5) Remove the frame.

MX-LCX2 DISASSEMBLY AND ASSEMBLY 6 – 4
6) Remove the connector, and the E-ring, and remove the paper
feed, transport clutch, respectively.
D. Paper feed solenoid
1) Remove the paper feed unit.
2) Remove the cover.
3) Remove the screw, and remove the unit.
4) Disconnect the connector.
5) Remove the screw, and remove the solenoid.
E. Torque limiter
1) Remove the paper feed unit.
2) Remove the cover.
3) Remove the E-ring and the screw, and remove the parts.
4) Lift the shaft, and remove the torque limiter.

MX-LCX2 DISASSEMBLY AND ASSEMBLY 6 – 5
F. Transport roller
1) Remove the paper feed unit.
2) Remove the cover.
3) Remove the spring, and remove the screw.
4) Remove the plate cover, and remove the lever.
5) Remove the clutch.
6) Remove the screw and the E-ring, and remove the parts.
7) Remove the transport roller.

MX-LCX2 MAINTENANCE 7 – 1
MX-LCX2 Service Manual
[7] MAINTENANCE
1. Maintenance system table
✕: Checking (clean, replace or adjust as required) {: Cleaning ▲: Replace ∆: Adjust ✩: Lubricate : Position shift
No. Part name When
calling
Main unit
maintenance cycle Remarks
1 Pick-up roller/each paper feed roller ✕{
As a rough guide, these rollers should be replaced when the LCC paper feed
counter reaches a value of 100K (Sim22-9) or when one year has elapsed
since the start of use.
2 Torque limiter ✕✕
As a rough guide, the torque limiter should be replaced when the LCC paper
feed counter reaches a value of 800K (Sim22-9).
3 Each transport rollers ✕{
4 Each transport paper guides {{
5 Each gears ✕✕
6 Each belts ✕
7 Each sensors ✕✕

MX-LCX2 ADJUSTMENTS 8 – 1
MX-LCX2 Service Manual
[8] ADJUSTMENTS
Each adjustment item in the adjustment item list is indicated with its JOB number. Perform the adjustment procedures in the sequence of Job
numbers from the smallest to the greatest.
However, there is no need to perform all the adjustment items. Perform only the necessary adjustments according to the need.
Unnecessary adjustments can be omitted. Even in this case, however, the sequence from the smallest to the greatest JOB number must be
observed.
If the above precaution should be neglected, the adjustment would not complete normally or a trouble may occur.
1. List
2. Details
ADJ 1 Print off-center adjustment
1) Execute SIM.50-10 by the key operation of the machine. Then,
the displays shown on the right side appear.
2) The print off-center adjustment value can be set for each tray.
3) Press the [↓] key on the touch panel to select “G:50:LCC”.
4) Then, enter your desired adjustment value with the [10] key.
(Default: 50 Adjustment range: from 1 to 99)
* If the adjustment value is decreased by 1, the main scanning
print position is shifted to the front side by 0.1mm.
* If the adjustment value is increased by 1, the main scanning
print position is shifted to the rear side by 0.1mm.
5) When the [EXECUTE] button is pressed, the [EXECUTE] but-
ton is highlighted, currently set value is saved into the
EEPROM and the RAM, and printing for adjustment pattern
image is started. After printing is finished, the [EXECUTE] but-
ton returns to the normal display status.
6) Check the adjustment pattern image position.
Measure the dimensions of the void area in the adjustment
pattern front and rear frame directions, and ensure that they
satisfy the conditions shown below.
If condition of A - B = 0±3.0mm is satisfied, no adjustment is
necessary.
If it does not satisfy the condition above, execute the proce-
dures shown below.
7) Change the adjustment value. Repeat the steps from 4) to 6)
until the condition described in the step 6) is satisfied.
8) After the adjustment is finished, escape from the simulation
mode with the reset key.
Job No. Adjustment item list Simulation to
be used
ADJ 1 Print off-center adjustment 50-10
ADJ 2 Resist amount adjustment ADJ 2A Change in the resist amount adjustment/deflection amount correction value 51-02
ADJ 2B Adjustment of the print lead edge adjustment 50-05
A-B = 0 3.0mm
+
-
B
A
EXECUTE
Printing is finished
EXECUTE
10 Key
A㧦100 㧧BK-MAG
B㧦50 㧧 MFT
C㧦50 㧧 CS1
D㧦50 㧧 CS2
0
G
:
PAPER CENTER OFFSET SETUP
50
㨇㨉
OK
TEST CLOSE
E㧦50 㧧 CS3
F㧦50 㧧 CS4
G㧦50 㧧 LCC
H㧦50 㧧 ADU
I㧦1㧧 MULTICOUNT
J㧦2㧧 PAPER㧦CS1
K㧦1㧧 DUPLEX㧦NO
EXECUTE
A㧦100 㧧 BK-MAG
B㧦50 㧧 MFT
C㧦50 㧧 CS1
D㧦50 㧧 CS2
0
G
:
PAPER CENTER OFFSET SETUP
60
㨇㨉
OK
TEST CLOSE
E㧦50 㧧 CS3
F㧦50 㧧 CS4
G㧦50 㧧 LCC
H㧦50 㧧 ADU
I㧦1㧧 MULTICOUNT
J㧦2㧧 PAPER㧦CS1
K㧦1㧧 DUPLEX㧦NO
EXECUTE
[Switching of screen]
SIMULATION NO50-10
SIMULATION NO50-10

MX-LCX2 ADJUSTMENTS 8 – 2
<<Description of items>>
ADJ 2 Resist amount adjustment
2-A Changing resist amount adjustment/
deflection amount correction value
1) Execute SIM.51-2 by the key operation of the machine. Then,
the displays shown on the right side appear.
2) Select the [ENGIN] button.
3) Press the [↓] key on the touch panel to select “U:50:A4LCC”.
4) Then, enter your desired adjustment value with the [10] key.
(Default: 50 Ajustment range: from 1 to 99)
* As the adjustment value is increased, the deflection amount
is also increased. As the adjustment value is decreased, the
deflection amount is also decreased.
(If the adjustment value is changed by “1”, the stop timing is
changed by 0.1mm (1.0msec).)
5) After the adjustment value is entered, press the [OK] key on
the touch panel to save the set value.
6) After the adjustment is finished, escape from the simulation
mode with the reset key.
Item Display item and details Descriptions Setting range Default Writing
ABK-MAG Main scanning print magnification BK 60 to 140 100 Yes
BMFT Print off-center adjustment value (manual) 1 to 99 50 Yes
CCS1
Print off-center adjustment value
(cassette 1) 1 to 99 50 Yes
DCS2 Print off-center adjustment value (cassette 2) 1 to 99 50 Yes
ECS3 Print off-center adjustment value (cassette 3) 1 to 99 50 Yes
FCS4 Print off-center adjustment value (cassette 4) 1 to 99 50 Yes
G LCC Print off-center adjustment value (LCC) 1 to 99 50 Yes
HADU Print off-center adjustment value (ADU) 1 to 99 50 Yes
IMULTI COUNT Number of printed sheets 1 to 999 1No
JPAPER MFT Cassette selection Manual 1 to 6 1 2
(CS1)
No
CS1 Cassette 1 2
CS2 Cassette 2 3
CS3 Cassette 3 4
CS4 Cassette 4 5
LCC LCC 6
KDUPLEX YES Double sided print selection Select 0 to 1 01(NO) No
NO Not select 1
[Switching of screen]
SIMULATION NO51-02
SIMULATION NO51-02
OK
㪈㪇 Key
0
U:
REGIST ROLLER ADJUSTMENT
50
㨇㨉
O
K
TEST CLOSE
REGI1  REGI2 ENGIN
0
U:
REGIST ROLLER ADJUSTMENT
60
㨇㨉
O
K
TEST CLOSE
REGI1  REGI2 ENGIN
N: 50 ; MANUAL HEAVY PAPER1(L)
O: 50 ; MANUAL OHP1
P: 50 ; MANUAL ENV
Q: 50 ; ADU PLAIN PAPER(S)
R: 50 ; ADU PLAIN PAPER(L)
S: 50 ; ADU HEAVY PAPER1(S)
T: 50 ; ADU HEAVY PAPER1(L)
U: 50 ; A4LCC
V: 50 ; A3LCC(S)
W: 50 ; A3LCC(L)
X: 50 ; A3LCC HEAVY PAPER‚P(S)
Y: 50 ; A3LCC HEAVY PAPER‚P(L)
N: 50 ; MANUAL HEAVY PAPER1(L)
O: 50 ; MANUAL OHP1
P: 50 ; MANUAL ENV
Q: 50 ; ADU PLAIN PAPER(S)
R: 50 ; ADU PLAIN PAPER(L)
S: 50 ; ADU HEAVY PAPER1(S)
T: 50 ; ADU HEAVY PAPER1(L)
U: 60 ; A4LCC
V: 50 ; A3LCC(S)
W: 50 ; A3LCC(L)
X: 50 ; A3LCC HEAVY PAPER‚P(S)
Y: 50 ; A3LCC HEAVY PAPER‚P(L)

MX-LCX2 ADJUSTMENTS 8 – 3
<<Setting range and defaults of set values>>
Item Button Item to be displayed Descriptions (Mode, original, paper feeed speed) Feed direction Setup
range Default
ATRAY1(S) Host machine tray 1, deflection adjustment value (small size) Not more than LT size 1 to 99 50
BTRAY2(S) Host machine tray 2, deflection adjustment value (small size) Not more than LT size 1 to 99 50
CTRAY3 PLAIN PAPER
(S)
Host machine tray 3, deflection adjustment value
(normal paper, small size) Not more than LT size 1 to 99 50
DTRAY3 PLAIN PAPER
(L)
Host machine tray 3, deflection adjustment value
(normal paper, large size) Not less than LT size 1 to 99 50
ETRAY3 HEAVY
PAPER1 (S)
Host machine tray 3, deflection adjustment value
(Cardboard 1, small size) Not more than LT size 1 to 99 50
FTRAY3 HEAVY
PAPER1 (L)
Host machine tray 3, deflection adjustment value
(Cardboard 1, large size) Not less than LT size 1 to 99 50
GTRAY4 PLAIN PAPER
(S)
Host machine tray 4, deflection adjustment value
(Normal paper, small size) Not more than LT size 1 to 99 50
HTRAY4 PLAIN PAPER
(L)
Host machine tray 4, deflection adjustment value
(Normal paper, large size) Not less than LT size 1 to 99 50
ITRAY4 HEAVY
PAPER1 (S)
Host machine tray 4, deflection adjustment value
(Cardboard 1, small size) Not more than LT size 1 to 99 50
JTRAY4 HEAVY
PAPER1 (L)
Host machine tray 4, deflection adjustment value
(Cardboard 1, large size) Not less than LT size 1 to 99 50
KMANUAL PLAIN
PAPER (S) Manual tray, deflection adjustment value (Normal paper, small size) Not more than LT size 1 to 99 50
LMANUAL PLAIN
PAPER (L) Manual tray, deflection adjustment value (Normal paper, large size) Not less than LT size 1 to 99 50
MMANUAL HEAVY
PAPER1 (S) Manual tray, deflection adjustment value (Cardboard1, small size) Not more than LT size 1 to 99 50
NMANUAL HEAVY
PAPER1 (L) Manual tray, deflection adjustment value (Cardboard1, large size) Not less than LT size 1 to 99 50
OMANUAL OHP1 Manual tray, deflection adjustment value (OHP1) 1 to 99 50
PMANUAL ENV Manual tray, deflection adjustment value (Envelope) 1 to 99 50
QADU PLAIN PAPER (S) ADU, deflection adjustment value (normal paper, small size) Not more than LT size 1 to 99 50
RADU PLAIN PAPER (L) ADU, deflection adjustment value (normal paper, large size) Not less than LT size 1 to 99 50
SADU HEAVY PAPER1
(S) ADU, deflection adjustment value (Cardboard1, small size) Not more than LT size 1 to 99 50
TADU HEAVY PAPER1
(L) ADU, deflection adjustment value (Cardboard1, large size) Not less than LT size 1 to 99 50
U ENGIN A4LCC A4LCC, deflection adjustment value 1 to 99 50
VA3LCC (S) A3LCC deflection adjustment value (Normal paper, small size) Not more than LT size 1 to 99 50
WA3LCC (L) A3LCC deflection adjustment value (Normal paper, large size) Not less than LT size 1 to 99 50
XA3LCC HEAVY
PAPER1 (S) A3LCC deflection adjustment value (Cardboard, small size) Not more than LT size 1 to 99 50
YA3LCC HEAVY
PAPER1 (L) A3LCC deflection adjustment value (Cardboard, large size) Not more than LT size 1 to 99 50

MX-LCX2 ADJUSTMENTS 8 – 4
2-B Print lead edge adjustment
1) Execute SIM.50-5 by the key operation of the machine. Then,
the displays shown on the right side appear.
2) Press the [↓] key on the touch panel to select “E:PAPER”.
3) Then, enter the adjustment value 6 with the [10] key, and press
the [OK] button.
(Adjustment value 6: LCC)
4) When the [EXECUTE] button is pressed, the [EXECUTE] but-
ton is highlighted, and printing for adjustment pattern image is
started with the currently set value. After printing is finished,
the [EXECUTE] button returns to the normal display status.
5) Check the adjustment pattern image position.
Measure the dimensions of the void area in the adjustment
pattern right and left frame directions, and ensure that they sat-
isfy the conditions shown below.
If condition of A=4.0±2.0mm, B=4.0±2.0mm is satisfied, no
adjustment is necessary.
If it does not satisfy the condition above, execute the proce-
dures shown below.
6) Change the adjustment values of the adjustment items
A(DEN-C) and B(DEN-B).
* As the adjustment value of the item A(DEN-C) is decreased
by 1, the print start position is moved to the lead edge side of
paper against the paper feed direction by 0.1mm.
* As the adjustment value of the item B(DEN-B) is decreased
by 1, the print range is increased to the trailing edge side of
paper against the paper feed direction by 0.1mm.
7) Repeat the steps from 4) to 6) until the condition shown in the
step 5) is satisfied.
8) After the adjustment is finished, escape from the simulation
mode with the reset key.
A = 4.0 2.0mm
+
-
B = 4.0 2.0mm
+
-
B
A
[Switching of screen]
EXECUTE
Printing is finished
EXECUTE
A㧦30 㧧DEN-C
B㧦20 㧧 DEN-B
C㧦20 㧧 FRONT/REAR
D㧦1㧧 MULTI COUNT
0
A
:
SIMULATION NO50-05
SIMULATION NO50-05
LEAD EDGE ADJUSTMENT VALUE(PRINTER)
LEAD EDGE ADJUSTMENT VALUE(PRINTER)
30
O
K
TEST CLOSE
E㧦2㧧PAPER : CS1
F㧦1㧧DUPLEX : NO
DEN-C
DEN-B
FRONT/REAR
MULTI COUNT
PAPER : CS1
DUPLEX : NO
EXECUTE
A㧦40 㧧
B㧦20 㧧
C㧦20 㧧
D㧦1㧧
0
A
:40
㨇 1㨪99㨉
O
K
TEST CLOSE
E㧦2㧧
F㧦1㧧
EXECUTE
[1㨪99 ]

MX-LCX2 ADJUSTMENTS 8 – 5
<Description of items>
* The item name for the items J and K is detailed display.
Example: PAPER: CS1
Item Display items and
details Descriptions Setup range Default Writing Remarks
A DEN-C Print lead edge adjustment 1 to 99 30 Yes
Adjustment value for matching to the print lead
edge for printer.
As the adjustment value of this item is decreased
by 1, the print start position against the paper
feeding direction is moved to the leading edge side
by 0.1mm.
BDEN-B Sub scanning direction print area
adjustment 1 to 99 20 Yes
Amount of void to be created at the trailing edge of
paper. As the adjustment value of the item B(DEN-
B) is decreased by 1, the sub scanning print range
adjustment value is decreased by 0.1mm.
C FRONT/REAR FRONT/REAR void amount
adjustment 1 to 99 20 Yes
Amount of void to be created at the right and left
edges of paper. As the value is increased, the void
amount is increased.
D MULTI COUNT Number of printed sheets 1 to 999 1 No
E PAPER
MFT
Cassette selection
Manual 1
1 to 6
1
2
(CS1) No
CS1 Cassette 1 2
CS2 Cassette 2 3
CS3 Cassette 3 4
CS4 Cassette 4 5
LCC LCC 6
F DUPLEX YES Double-sided print
selection
Selected 0 to 1 01
(NO) No
NO Not selected 1

MX-LCX2 SIMULATION 9 – 1
MX-LCX2 Service Manual
[9] SIMULATION
1. List
2. Details of trouble code
4
4-2
Purpose Operation test/Check
Function (Purpose) Used to check the operations of the sen-
sors and detectors in the large capacity tray
(LCC) and the control circuit.
Section Large capacity tray (LCC)
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
Sensors and detectors which are turned on are highlighted.
4-3
Purpose Operation test/Check
Function (Purpose) Used to check the operations of the loads
in the large capacity tray (LCC) and the
control circuit.
Section Large capacity tray (LCC)
Operation/Procedure
1) Select a target of the operation check with the touch panel.
2) Press [EXECUTE] key.
The selected load is operated.
When [EXECUTE] is pressed, the operation is stopped.
Code Function (purpose) Purpose Section
Main Sub
4
2Used to check the operations of the sensors and detectors in the large capacity tray
(LCC) and the control circuit. Operation test/Check Large capacity tray (LCC)
3Used to check the operations of the loads in the large capacity tray (LCC) and the
control circuit. Operation test/Check Large capacity tray
(LCC)
5 Used to check the operations of the clutch (LTRC) in the LCC and the monitor. Operation test/Check Large capacity tray
(LCC)
15 - Used to cancel the self-diag "U6-09 (large capacity paper feed tray)" trouble. Clear/cancel (Trouble
etc.) LCC
<MX-LCX2>
LPFD LCC transport sensor
LUD LCC tray upper limit detection
LDD LCC tray lower limit detection
LPED LCC tray paper empty detection
LCD LCC tray insertion detection
LDSW LCC upper open/close detection SW
LRE LCC lift motor encoder detection
L24VM LCC 24V power monitor
LLSW LCC upper limit SW
LTOD LCC main unit connection detection
LCC SENSOR CHECK
CLOSE
SIMULATION NO.04-02
TEST
1/1
LPFD LUD LDD LPED
LCD LDSW LRE L24VM
LLSW LTOD
<MX-LCX2>
LPFM LCC transport motor
LLM LCC lift motor
LPFC LCC paper feed clutch
LPFS LCC paper feed solenoid
LTRC LCC transport clutch
SIMULATION NO.04-03
TEST
LCC LOAD CHECK
EXECUTE
1/1
CLOSE
LPFM LLM LPFC LPFS
LTRC
