Xtool A30 Pro User manual

Quick Guide
Xtool A30 Pro Intelligent Diagnostic Unit
Efficient Smart Portable
Please read the instruction carefully book before usage

STATEMENT
I
Statement
Brand
Shenzhen Xtooltech Co.,Ltd（Herein after to be
referred as“Xtool”）, Xtool announces that its Brand,
service mark, domain name, icon and company name
still own the ownership rights in unregistered country.
Other products and company name brand referred by
this introduction book are still belong to original
registered company. Anybody can’t use Xtool or other
company brand, service mark, domain name, icon and
company name without the written permission of
owner.
Shenzhen Xtooltech Co.,Ltd has registered brand, it’s
brand is

STATEMENT
II
Copyright
This introduction is designed for Xtool A30 Pro
intelligent diagnostic unit and only apply to it. Any
company or person can’t copy and backup this
introduction book in any form (Electronic, mechanical,
photocopy, record or other form) without written
permission of Xtool. This introduction book is via the
product existing configuration and function to compile,
if the product add new configuration and function, this
introduction book change accordingly, without prior
notice. The right of final interpretation of this
introduction book is belong to Xtool.
Disclaimer
This electronic control system diagnostic unit is
provided for vehicle repairing professionals, this

STATEMENT
III
product has higher reliability, but not exclude the loss
and damage caused by customers technical matter,
vehicle problem or other reason, Xtool assume no
liability or responsibility for those.
To know more about related products information, you
can visit Shenzhen Xtooltech Co.,Ltd official website：
http://www.xtooltech.com
Safety instruction
Keep ventilation：When the engine is
running, please keep repair zone good
ventilation or connect exhaust system of
engine and building carefully.
Caution:
⚫Always keep safe condition to diagnose vehicle

STATEMENT
IV
⚫Wear the goggles accord with ANSI standard
⚫Keep clothes, hair hand, tool, tester etc away from
running or calorific engine
⚫Before start engine, you should confirm parking
braking is working, put barrier in front wheels, and
put gear shift lever in neutral gear or ppark, to
avoid hurting people on the spot when start
engine, vehicle speeds up suddenly
⚫Be extremely careful when working around the
ignition coil, distributor cap, ignition circuit and
ignition plug. The voltage generated by these
components when the engine is running is very
dangerous.
⚫Equipped with special fire extinguishers for
gasoline, chemical, electrical fires etc in the
working area.
⚫When the ignition switch is turned on or the

STATEMENT
V
engine is running, don’t connect or disconnect the
diagnostic equipment.
⚫Keep the diagnostic device dry and clean, away
from gasoline, water and grease. If necessary, use
a clean cloth coated with a mild detergent to clean
the surface of the device.
⚫Don’t operate the diagnostic equipment while
driving the vehicle to avoid distractions and cause
accidents.
⚫Please refer to the repair manual when servicing
the vehicle and strictly follow the diagnostic
procedures and precautions. Otherwise it may
cause personal injury or damage to the diagnostic
device
⚫To avoid damaging the diagnostic device or
generating incorrect data, please ensure that the
vehicle battery is sufficiently charged and the

STATEMENT
VI
connection of the vehicle diagnostic socket is
clean and safe.
⚫Don’t put the diagnostic device on the vehicle
distributor. Strong electromagnetic interference
will cause damage to the device.

QUICK GUIDE
III
Quick Guide
Product overview Page 1
In this part, you can know about the basic features of the product
Connector/Button definition Page 5
In this part, you can know about the buttons of the product
Product interface introduction Page 10
In this part, you can know about the function interface of the
product
Connection and Diagnosis Page 26
In this part, you can know about the vehicle diagnosis of the
product

QUICK GUIDE
1
Chapter 1 Product overview
Xtool A30 Pro intelligent diagnostic unit is a
professional vehicle repair diagnostic unit, this series of
product consists of an A30 Pro mainframe and some
related parts.
It supports the detection and simulation test of the car's
drive, chassis and body. It has the functions of reading
fault codes, clearing fault codes, reading data streams,
freezing frames, and action tests, as well as battery
management, exhaust gas post-processing, and tire
pressure reset, Headlight adjustment, maintenance light
reset, EPB electronic brake, ABS automatic exhaust,
fuel injector code, airbag repair, throttle matching,
electronic steering matching, gearbox matching and
other 12 special functions, powerful function. Xtool
A30 Pro series of products are small and flexible in

QUICK GUIDE
2
appearance and powerful in function, which can quickly
and accurately help repair personnel locate faults and
improve repair efficiency.
If you want to know about relevant information of A30
Pro intelligent diagnostic unit, you can visit Shenzhen
Xtooltech Co.,Ltd official website：
http://www.xtooltech.com .

SPECIFICATION
3
Chapter 2 Product specification
2.1 Product appearance
Xtool A30 Pro series intelligent diagnostic unit, The
design with blue and black color is simple and terse; the
body adopts a streamlined design and a large curvature
frame for better grip; the back of the product adopts a
protruding design that is more non-slip and safer；A30
Pro products are equipped with VCI as standard, and the
host and VCI are connected via Bluetooth, which is
convenient for connection.

SPECIFICATION
4
VCI Front view
Front view Back view

SPECIFICATION
5
2.2 Product interface and button definition

SPECIFICATION
6
1
Charge
Lamp
Display state of charge
2
LCD display
Display function menu of product
3
Back
Cancel selection （Or operation ）or
return to previous menu
4
Direction
key
Via direction key to move choosing
appoint menu
5
Vehicle
diagnosis
Open/switch vehicle diagnosis function
6
DB15
connector
Reserved interface
7
Speedy guide
Open/switch introduction book
8
OK
Confirm selection
9
USB
interface
Connect device to PC to update
software or battery charging, a Type-c
10
Power switch
Long press can power on/Power off,
Short press can turn on/turn off screen

SPECIFICATION
7
2.3 Product parameter
PS：1. Because of system reasons, there will be some differences between
RAM and storage, please refer to the actual situation
2. The working temperature and storage temperature are verified in
a laboratory environment, which are for reference only, and the
specifics are based on actual conditions.
CPU
ARM Cortex A7 Quad-Core，Basic
frequency 1.2GHz
GPU
Mali-400 MP2 GPU
RAM
DDR3 1GB
Storage
EMMC 32GB
Display screen
4 inch 320x480 Color touch display
screen
Working voltage
9~18V
Battery
3000mAh built-in lithium battery
Working temperature
-20℃-60℃
Storage temperature
-30℃-70℃

SPECIFICATION
8
2.4 OBD detection
主测试线
Vehicle
VCI
A30 Pro Host
Main test line

SPECIFICATION
9
Connection steps:
1. First open the A30 Pro host;
2. Connect the host and VCI via Bluetooth;
3. Connect the VCI to the car with the main test line;
4. Start the test.
Chapter 3 Product usage
introduction
3.1 Product activation
First use Xtool A30 Pro need activate device
Steps：Connect WI-FI first, enter activation page, via
hints to input cell phone number to verify, after
receiving message authentication code, input the code
and finish the verification.
Caution：1. Only need activate system one time

INTRODUCTION
10
2. In order to improve Xtool A30 Pro,we will
updates the software for a period of time,
when the diagnosis interface popups tooltip,
click upgrade option.
3.2 Product interface introduction
After booting, main interface and submenu as shown
below.

INTRODUCTION
11
Main interface and submenu function keys
specification
【Function key】
【Function specification】

INTRODUCTION
12
3.3 Settings
Select the "Settings" menu to open the setting interface.
You can set the language, unit and system-related
Via connect to the vehicle's
electronic control system, you can
read diagnostic information, view
data flow parameters, and perform
action tests.
Upgrade Xtool the newly
developed diagnostic software for
each vehicle model.
You can set the language, unit and
system related settings on this
interface, etc.
Xtool A30 Pro quick guide
