Xtool Anyscan A30 User manual

User Manual
Product Name: Auto Diagnostic TOOL
Trade Mark: XTOOL
Model: Anyscan A30
Chapter I About Anyscan A30
1. Appearance
Front View Back View

2. Layout
①LCD display: display the car voltage
②OBD 16pin connector
③Light button
④Power Indicator: It turns green when power is on
⑤Bluetooth Indicator: It turns red when Bluetooth is not connected; it turns blue when Bluetooth is
connected successfully
⑥Vehicle Indicator: When VCI Dongle III is connected with vehicle successfully, it turns green.
3．Technical parameter
Product Information
Brand
XTOOL
Model
Anyscan A30
Color
Hardware blue + plastic black
On-sale date
2018
Hardware support
CPU
STM32
RAM
512KByte
Bluetooth
V3.0+EDR
Display
0.96 inch
Buzzer
Less than 12.2V or more than 15V will trigger the alert
Power dissipation
Normal working voltage
+12V

Working Temperature
Working Temperature
-20~+40℃
Working Humidity
10%-90%
Storage Temperature
-40-+85℃
Others
Overall Dimensions
87.00*50.00*25.00mm
Battery
100mAh
OBD
OBD standard interface
LED
Quantity 4 (power indicator, bluetooth indicator, vehicle
diagnostic indicator, lighting indicator)
Chapter II How to use Anyscan A30
1. App download instructions
1.1 Support iOS and Android system.
OS
Device
Mode
Apple iOS
(Requires iOS4.3 or later)
IPod
touch
iPod Touch 1st generation, 2nd generation,
3rd generation, 4th generation
iPhone
iPhone, iPhone 3, iPhone 3GS, iPhone 4, iPhone4s, iPhone
5, iPhone 6, iPhone 6 Plus, iPhone 6s, iPhone 6s Plus,
iphone 7, iphone 7 plus
iPad
iPad, iPad 2, ipad 3, iPad air, iPad Mini 1, iPad Mini 2,
iPad Pro
Android
(Requires OS2.3 or later)
All android smart phone and tablet
1.2. Download the 【Diagnostic】App from Google play or App store.

2. App activation
2.1. Please activate the App before you use it to test vehicles.
2.2. Input activation code, product serial number (each device will have a serial number and activation
code), user name, email address, cell phone number,workshop name and password, the system will
then save it. Activation is a one time process. The diagnostic application will start after activation.
3. Anyscan A30 Main Interface and Functional Buttons Descriptions
3.1. Main Interface
Tap on Diagnostic application icon, the main interface and sub-menus will beshown as below.▼

3.2. Sub-menus and Function Buttons
4. Precautions Before Use
4.1. The vehicle power supply has to meet the normal voltage limits DC 9-12V
4.2. Users should check the position of the DLC port and ensure the OBD 16 connector and the DLC
port are correctly aligned before attempting to connect.
4.3. When carrying out some special functions tests, users are required to operate the device
according to operating instructions. For some tests the vehicle has to meet certain requirements, for
example: engine temperature 80℃/105℃, turn off loads (such as headlights, air-conditioner, etc.),
put accelerator pedal in released position, etc.
4.4. If users can not find the tested vehicle model or electronic control system in the VCI Dongle III test
menu, they may need to update the software or consult Xtool technical service department.
4.5. Before powering off the unit, please ensure that you cancel or complete the current task or
function and return to the main interface, then power off.
4.6. Do not excessive force to operate the touch screen.
Function Buttons
Descriptions
Opens the Diagnostic application. It can read
diagnostic information, view live data, perform
actuation tests and special functions etc.
By selecting “Settings”, users can access the language
setting and other system related settings.
Click UPDATE after connecting to the internet, you can
then download the latest diagnostic software directly.
Users can view all the diagnostic reports and
diagnostic data generated in the diagnosis process.
More software packages for users to further purchase.
Online Communication Platform for users.
Job sheet.

5. Diagnosis
5.1. Menu Options
5.1.1. After the VCI Dongle III is connected to the vehicle and paired with Diagnostic App via Bluetooth
connection, diagnosis can be performed. The diagnostic interface is as shown below:
5.1.2. Users can choose the relevant menu for the vehicle being tested: selection for Europe will enter
the European cars menu, selection for Asia will enter the Asian cars menu, selection for America will
enter the American cars menu. Users also can input the vehicle model to search.
5.1.3. Besides the usual system diagnostic functions, XTOOL have also developed a series of special
diagnostic functions for certain vehicles.
6. Settings
By selecting Settings users can set the language, unit and other system related options:
Languages: select the language. Please tick the required option from the multi-language options on
the right.

Units: Select unit of measurement. Users can select Metric or British Unit.
CHAPTER III Examples of Diagnostic Link Connector Locations.
1. Diagnostic Link Connectors Locations of Various Vehicle Models
*AUDI A6: the OBD plug is on the lower left side of the dashboard, use SMART OBDII-16 connector.

*VW Bollywood 1.8: the OBD plug is below the console, use SMART OBDII-16 connector.
*Benz S320,220 Chassis: the OBD plug is below the dashboard, use SMART OBDII-16 connector.
*Benz C180: the OBD plug is on the left hand side of the engine bay, use Benz-38 connector.

*Benz 300SEL 140 chassis: the OBD plug is on the left hand side of the engine bay, use Benz-38
connector.
*GM Buick: the OBD plug is below the dashboard, use SMART OBDII-16 connector.
*GM Buick GL8 : the OBD plug is below the dashboard, use SMART OBDII-16 connector.
*VW POLO: the OBD plug is below the dashboard, use SMART OBDII-16 connector.

*BMW 735I: the OBD plug is in the right hands side of the engine bay, use BMW-20 connector.
*VW Passat B5: the OBD plug is behind the gearlever and beside the parking brake lever. Lift the cover
to access it. Use SMART OBDII-16 connector.
2. Location Diagram of Vehicle Diagnostic Link Connectors
Location diagram of pick-up truck diagnostic link connectors:
Location diagram of utility vehicles diagnostic link connectors:

Link diagram of small car diagnostic link connectors:
NOTE: Each vehicle manufacturer may use additional pins to diagnose a variety of systems. Not every
manufacturer uses the same standard. The function on a certain pin will vary from manufacturer to
manufacturer. Verify with the manufacturer.
3. Diagnostic Link Connectors Terminal Definition and Communication Protocols
3.1. Standard OBDII Diagnostic Link Connector:
Pin Definition (Reference material)
Various pin definitions as follows:
1. Manufacturer definition
2. SAE J1850 bus positive
3. Manufacturer definition
4. Bodywork site
5. Signal site
6. ISO 15765-4 defined CAN high
7. ISO9141 and ISO14230 defined K line
8. Manufacturer definition

9. Manufacturer definition
10. SAE J1850 bus negative
11. Manufacturer definition
12. Manufacturer definition
13. ISO 15765-4 defined CAN low
14. ISO9141 and ISO14230 defined L line
15. Permanent positive voltage
[1] 1, 3, 8, 9, 11, 12 and 13 are defined by manufacturer.
[2] 2, 6, 7, 10, 14 and 15 are used for diagnostic communication. Unused definitions can be defined by
