Alcatel-Lucent OpenTouch 8018 User manual

OpenTouch™ Suite for MLE
8018 DeskPhone
User Manual
8AL90332ENAAed01-1617

8018 DeskPhone
8AL90332ENAAed01
2 /37
Introduction
Thank you for choosing our DeskPhone. We hope it will give you entire satisfaction.
This model offers enhanced ergonomical features for more effective communication.
This manual describes the services offered by the 8018 DeskPhone connected to an OmniPCX
Enterprise system.
The labels and icons presented in this document are not contractually binding and may be modified
without prior warning.

8018 DeskPhone
8AL90332ENAAed01
3 /37
1.5 CHANGING OR UPDATING THE PHONE LABEL .......................................................................................8
1.6 STATUS ICONS /CALL ICONS..............................................................................................................8
1.7 FEATURES KEYS................................................................................................................................8
1.8 PREPROGRAMMED KEYS....................................................................................................................9
1.9 ALPHABETIC KEYBOARD ....................................................................................................................9
1.10 CALL MANAGEMENT SCREEN..........................................................................................................10
2USING YOUR TELEPHONE ............................................................................................................11
2.1 CONSULTING THE CALL LOG.............................................................................................................11
2.2 MAKING A CALL...............................................................................................................................11
2.3 RECEIVING A CALL...........................................................................................................................12
2.4 USING THE TELEPHONE IN 'HANDS FREE'MODE.................................................................................12
2.5 ACTIVATING THE LOUDSPEAKER DURING A CONVERSATION (HANDSET LIFTED)-LOUDSPEAKER. .........12
2.6 CALLING YOUR CALLER BY NAME (COMPANY DIRECTORY)..................................................................13
2.7 MAKE CALLS VIA YOUR PROGRAMMED CALL KEYS.............................................................................13
2.8 REDIALING ......................................................................................................................................13
2.9 CALL BACK AN UNANSWERED CALL..................................................................................................13
2.10 REQUESTING AUTOMATIC CALLBACK IF INTERNAL NUMBER IS BUSY .................................................14
2.11 RECEIVING INTERCOM CALLS..........................................................................................................14
2.12 SENDING DTMF SIGNALS...............................................................................................................15
2.13 MUTE,SO THAT YOUR CALLER CANNOT HEAR YOU...........................................................................15
3DURING A CONVERSATION...........................................................................................................16
3.1 MAKING A SECOND CALL DURING A CONVERSATION...........................................................................16
3.2 ANSWERING A SECOND CALL DURING A CONVERSATION ....................................................................16
3.3 SWITCHING BETWEEN CALLS (BROKER CALL) ...................................................................................17
3.4 TRANSFERRING A CALL....................................................................................................................17
3.5 THREE-WAY CONFERENCE WITH INTERNAL AND/OR EXTERNAL CALLERS (CONFERENCE) .....................17
3.6 TALK SIMULTANEOUSLY TO MORE THAN 2CALLERS...........................................................................17
3.7 PLACING A CALL ON HOLD (HOLD) ....................................................................................................18
3.8 PLACING AN OUTSIDE CALL ON HOLD (PARKING) ...............................................................................18
3.9 INTRUSION INTO AN INTERNAL CONVERSATION ..................................................................................18
3.10 ADJUST AUDIO VOLUME .................................................................................................................19
3.11 SIGNAL MALICIOUS CALLS..............................................................................................................19

8018 DeskPhone
8AL90332ENAAed01
4 /37
4SHARING.........................................................................................................................................20
4.1 ANSWERING THE GENERAL BELL ......................................................................................................20
4.2 MANAGER/ASSISTANT FILTERING .....................................................................................................20
4.3 CALL PICK-UP .................................................................................................................................20
4.4 HUNTING GROUPS............................................................................................................................21
4.5 CALLING AN INTERNAL CALLER ON HIS/HER PAGER ...........................................................................21
4.6 ANSWERING A CALL ON YOUR PAGER ...............................................................................................21
4.7 CALLING A CALLER ON HIS/HER LOUDSPEAKER.................................................................................22
4.8 SENDING A WRITTEN MESSAGE TO AN INTERNAL CONTACT.................................................................22
4.9 SEND A VOICE MESSAGE COPY .........................................................................................................23
4.10 SENDING A RECORDED MESSAGE TO A NUMBER OR A DISTRIBUTION LIST..........................................23
4.11 BROADCASTING A MESSAGE ON THE LOUDSPEAKERS OF A STATION GROUP .....................................23
5KEEP IN TOUCH..............................................................................................................................24
5.1 FORWARDING CALLS TO ANOTHER NUMBER (IMMEDIATE FORWARD)...................................................24
5.2 FORWARDING YOUR CALLS TO YOUR VOICE MESSAGE SERVICE..........................................................24
5.3 WHEN YOU RETURN,CONSULT RECORDED MESSAGES.......................................................................24
5.4 FORWARDING CALLS TO YOUR PAGER ..............................................................................................24
5.5 FORWARDING YOUR CALLS FROM THE RECEIVING TERMINAL ('FOLLOW ME').......................................25
5.6 APPLYING A SELECTIVE FORWARD....................................................................................................25
5.7 CANCELLING ALL FORWARDS...........................................................................................................25
5.8 CANCELLING A SPECIFIC FORWARD ..................................................................................................25
5.9 FORWARDING CALLS .......................................................................................................................25
5.10 DO NOT DISTURB ...........................................................................................................................26
5.11 LEAVING A RECORDED MESSAGE FOR INTERNAL CALLERS ...............................................................26
5.12 CONSULTING WRITTEN MESSAGES..................................................................................................27
6MANAGING YOUR CHARGES........................................................................................................28
6.1 CHARGING YOUR CALLS DIRECTLY TO BUSINESS ACCOUNTS..............................................................28
6.2 FINDING OUT THE COST OF AN OUTSIDE CALL MADE FOR AN INTERNAL USER FROM YOUR TERMINAL ....28

8018 DeskPhone
8AL90332ENAAed01
5 /37
7PROGRAMMING YOUR TELEPHONE............................................................................................29
7.1 INITIALIZING YOUR VOICE MAILBOX ...................................................................................................29
7.2 CUSTOMIZING YOUR VOICE GREETING...............................................................................................29
7.3 MODIFY THE PASSWORD FOR YOUR PHONE SET.................................................................................29
7.4 MODIFY THE PASSWORD FOR YOUR VOICE MAILBOX ..........................................................................30
7.5 ADJUSTING THE AUDIO FUNCTIONS...................................................................................................30
7.6 ADJUSTING THE CONTRAST OF THE DISPLAY .....................................................................................31
7.7 SELECTING THE WELCOME PAGE ......................................................................................................31
7.8 SELECTING LANGUAGE ....................................................................................................................31
7.9 PROGRAM THE KEYS FOR THE PERSO PAGE......................................................................................32
7.10 PROGRAMMING DIRECT CALL KEYS (PROGRAMMED KEYS WITH LEDS AND F1/F2 KEYS) ....................32
7.11 MODIFY THE PROGRAMMED KEY .....................................................................................................32
7.12 DELETE A PROGRAMMED KEY.........................................................................................................33
7.13 PROGRAMMING AN APPOINTMENT REMINDER...................................................................................33
7.14 IDENTIFY THE TERMINAL YOU ARE ON..............................................................................................34
7.15 LOCK /UNLOCK YOUR TELEPHONE .................................................................................................34
7.16 INSTALLING A USB ACCESSORY (HEADSET,HANDSFREE,LOUDSPEAKER).......................................34
7.17 CALL THE ASSOCIATED SET............................................................................................................34
7.18 FORWARD YOUR CALLS TO THE ASSOCIATED NUMBER.....................................................................34
7.19 MODIFY THE ASSOCIATED NUMBER.................................................................................................35
7.20 THE TANDEM CONFIGURATION........................................................................................................35
7.21 CREATE,MODIFY OR CONSULT YOUR INTERCOM LIST (MAX.10 NUMBERS) ........................................35
7.22 CONTACTING YOUR ADMINISTRATOR...............................................................................................35
8GUARANTEE AND CLAUSES.........................................................................................................36
8.1 SAFETY INSTRUCTIONS....................................................................................................................36
8.2 REGULATORY STATEMENTS.............................................................................................................37

8018 DeskPhone
8AL90332ENAAed01
6 /37
1 Getting to know your telephone
1.1 8018 DeskPhone
Your phone has 4 programmable keys with led and paper label. These keys are use to program a direct
call. You can use the paper to describe the key.
1.2 Description of the connectors
10/100/1000 Gigabit Ethernet connector (LAN).
10/100/1000 Gigabit Ethernet connector (PC).
DC power jack for an external power adaptor.
RJ9 connector for a corded handset.
Add-on module connector.
USB connector for headset.
Handset
Loudspeaker
LED
Flashing green: Arrival of a new call /
Appointment alarm.
3 preprogrammed keys with
Led and paper icon: Alpha-
numeric key, F1, F2.
4 programmable keys with Led
and paper label.
Permanent feature keys: quick
access to the phone's main features.
Stable foot
Monochrome graphical screen
with backlit (128x64 pixels).
6 dedicated functions keys.
Navigation
USB connector for headset.

8018 DeskPhone
8AL90332ENAAed01
7 /37
1.3 Welcome screens
You can access all of your phone's features from these screens. The default display has three pages
that you can access by selecting the corresponding tab at the top of the screen with the navigation keys.
The selected page is highlighted.
oMenu.
oPerso.
oInfo.
Menu page:
Contains all features and applications, which are accessed by pressing the key corresponding to
the desired feature or application. From this page, it is possible to adjust the ringer volume,
program the time of an appointment, lock the terminal, define the default page displayed,
configure voice mail, and access telephone functions such as calling back one of the last
numbers or intercepting calls.
Perso page:
Contains call line keys (allowing supervision of calls) and programmable call keys.
Info page:
Contains information on the telephone and the status of its functions: name, telephone number,
number of messages, activation of transfer function, appointment reminder, etc.
Transfer icon:
Press the key next to this icon allows you to program or change the transfer function.
Press the key in front of the label to select the corresponding feature.
1.4 Navigation
OK key:
Use to validate your choices and options while
programming or configuring.
Use to validate an edited text.
Use to switch off/on the screen when the phone is in idle
mode.
Left-right navigator:
Use to move from one page to another and display
information about current calls (call in progress, calls on
hold, incoming call).
Use to navigate into a text box.
Up-down navigator:
Use to scroll through the content of a page.
Back/Exit/Backspace key
Use this key to go back to the previous step.
Use this key to go back to the homepage (long press).
Use this key to delete one number or character at a time.

8018 DeskPhone
8AL90332ENAAed01
8 /37
1.5 Changing or updating the phone label
Removing the phone label
Lift the protective cover at the notch and slide it up to take it out of its
housing.
Remove the phone label in the same way.
Update or replace the phone label.
Inserting the phone label
Insert the phone label from the top end, making sure it is placed
correctly behind the notches.
Put the protective cover back in the same way.
1.6 Status icons / Call icons
Icons giving information about some specific configurations of the phone or about call status are
displayed in the top bar of the screen.
Headset connected.
Telephone locked.
Appointment programmed.
Incoming call icon.
Call in progress icon.
Call holding icon.
1.7 Features keys
Mute and intercom key.
During a call, press this key to stop your contact from hearing you. When idle, press this
key to switch the phone to intercom mode. When you receive a call, the phone hooks off
automatically and you go straight into handsfree mode. This key lights up blue when
activated.
Turn down the volume / Lower the contrast.
Turn up the volume / Increase the contrast.
Pressing this key answers an incoming call in handsfree mode (the key is blue). When a
call is in progress, pressing this key switches from handsfree mode to headset or handset
mode.
Messaging key to access various mail services. This key flashes when you have a new
voicemail, text message or callback request.
Access the call log.
The redial key is associated with the off hook key when the phone is in idle state.
Last number redial (short press).
Call back one of the last 8 numbers dialed (long press).
2
1

8018 DeskPhone
8AL90332ENAAed01
9 /37
1.8 Preprogrammed keys
The 8018 DeskPhone uses 3 preprogrammed keys to access some features. In this
case, the icon of the feature is printed on the paper. Use the feature by pressing the
corresponding key. When activated, the LED corresponding to the key remains lit up.
Press the corresponding key to deactivate it.
123<>abc Alpha-numerical keypad.
Use this key to switch between alphabetic keyboard and numeric keyboard.
Programmable keys (F1 and F2 keys). A service or a direct call can be associated to these
keys.
1.9 Alphabetic keyboard
Your phone is equipped with alphanumeric keyboard. You can switch between
numeric keyboard to dial number, and alphabetic keyboard to enter text by pressing
the corresponding programmed key (usually the first programmed key).
123<>abc Switch the keyboard to the alphabetic mode by selecting the associated programmed
key. When activated, the LED corresponding to the key remains lit up.
Enter alphabetic characters.
The number pad keys have letters that you can display by successive presses. The number is
the last character in the series. Some special characters can be displayed by successively
pressing the key:
o: % $ / ~ & ( ) [ ] = *
o: @ #
o: space - _ 1
o: + . , ; : / \ ? ! 0
Use navigation keys to move the cursor into the text.
delete the last entered character. The alphabetic mode remains activated.
123<>abc Select the lit programmed key to return to the numeric mode.

8018 DeskPhone
8AL90332ENAAed01
10 /37
1.10Call management screen
Incoming call icon, Call in
progress, Call on hold, …
Incoming call and
conversation presentation
screen
Soft keys: actions available
depending on the call status
Each tab corresponds to a call, the status of which is symbolized by its icon
(in progress, call on hold, arrival of new call). When a call is in progress, use
the left-right navigator to look at held or incoming calls.
All features are accessible while the call is displayed on the screen. Use the
Up and Down arrows to move up or down a page. These functions (transfer,
conference, etc.) are directly related to the status of the call consulted. For
example, the transfer function will not be available between a call in progress
or a call on hold and an incoming call.
Used to switch from a telephone screen to an application screen. For
example, it can be used while a call is in progress to search a number,
program an appointment reminder, etc.
Calls can also be managed from the Perso page.
While the call is in progress, press the Back/Exit key and display the Perso page. Calls in progress or
waiting calls are displayed on the different line keys. It is then possible to converse with the caller of
your choice by pressing the key associated to the caller.

8018 DeskPhone
8AL90332ENAAed01
11 /37
2 Using your telephone
2.1 Consulting the call log
At any time, you can consult all answered and unanswered incoming and outgoing calls.

Press the softkey associated with the call log feature.
Consulting all calls
All calls are displayed with an icon giving information on the type of call.
Answered outgoing calls
Answered incoming calls
Unanswered outgoing calls
Unanswered incoming calls
Using the up and down navigation key to scroll through the log.
Display the contact information by pressing the key in front of the name.
Information such as the name, phone number, date and time are displayed on the screen.
You can choose to call the contact or clear the log.
Delete all call logs:
Use one of the following:
oPress the key associated with the icon: .
oDisplay the contact information by pressing the key in front of the name.
Delete all
Press or select OK to confirm.
All call logs are deleted.
2.2 Making a call
Use one of the following:
Dial directly the number for your call.
Lift the receiver Enter the destination number.
Hands free Dial the destination number.
Programmed line key.
123<>abc Search by name (access the search by name feature by selecting the alphabetic
mode).
Redialing from the call log.
Redial last number
To make an external call, dial the outside line access code before dialing your contact number.

8018 DeskPhone
8AL90332ENAAed01
12 /37
If the internal or outside number does not reply:
LS announce Broadcast a message on the loudspeaker of the free terminal.
Call back Request callback to a busy terminal.
Text mail Send a written message.
Voice mail Store number to call again.
2.3 Receiving a call
Use one of the following:
Lift the receiver.
Hands free.
Take call.
Select the 'incoming call' icon .
2.4 Using the telephone in 'Hands free' mode
Terminal idle:
Press and release You are in hands free mode.
Terminate your call.
Call in progress:
During a conversation
Press and release You are in hands free mode.
During a conversation, you can lift the receiver without terminating the call.
2.5 Activating the loudspeaker during a conversation (handset lifted) -
Loudspeaker.
During a conversation.
Activate loudspeaker The key lights up.
Adjust volume (9 levels).
Deactivate loudspeaker The key is no longer lit.
Press and release the loudspeaker key to switch to hands free mode (light steady).

8018 DeskPhone
8AL90332ENAAed01
13 /37
2.6 Calling your caller by name (company directory)
123<>abc Switch the keyboard to the alphabetic mode by selecting the associated programmed
key. When activated, the LED corresponding to the key remains lit up.
Enter the name or initials or the surname and first name of your caller.
Select the type of search you want (last name, last name and first name or initials) Display of
all the callers meeting the search criteria.
Use one of the following:
oDisplay the previous and next names.
oSelect the name of the person you wish to call.
oModify the search.
*Name must be entered in format name / space / first name.
2.7 Make calls via your programmed call keys
Access the 'Perso' page.
Find the caller you want to call from the programmed call keys.
Select the caller .
2.8 Redialing
Redialing the last number dialed (redial)
(short press) Last number redial.
Call back one of the last 8 numbers dialed
(long press).
Select the number to redial from the last 8 dialed number.
Other method
Reach the 'Menu' page.
Redial list
Select the number to redial from the last 8 dialed number.
2.9 Call back an unanswered call
Callback requests
The message key flashes when you have a callback request.
Callback / xx Callbacks
Select a name or a number.
Recall
If there is only one callback request, it is displayed directly.
Call back the last caller
Reach the 'Menu' page.
Events
Last caller: Call back the last caller.

8018 DeskPhone
8AL90332ENAAed01
14 /37
List of unanswered calls
Use one of the following:
o
oReach the 'Menu' page.
Events
Select the type of call:
oUnanswered int call / xx Unanswered int calls
oUnanswered ext call / xx Unanswerd ext calls
Select a name or a number.
Recall
To delete the selected item.
Delete
Delete the list of unanswered calls
Use one of the following:
o
oReach the 'Menu' page.
Events
Select the type of call:
oUnanswered int call / xx Unanswered int calls
oUnanswered ext call / xx Unanswerd ext calls
Delete all (or use icon: ).
2.10Requesting automatic callback if internal number is busy
Internal number busy.
Call back Callback request acknowledged.

2.11Receiving intercom calls
You can answer a call without lifting the receiver. When you receive a call, you are automatically
connected in hands-free mode. The identity of the caller is displayed on the screen.
To activate - Terminal idle:
Corresponding LED lights up.
When your caller hangs up, interphony mode remains active.
To deactivate - Terminal idle:
The corresponding LED goes out.

8018 DeskPhone
8AL90332ENAAed01
15 /37
2.12Sending DTMF signals
During a conversation you sometimes have to send DTMF signals, such as with a voice server, an
automated attendant or a remotely consulted answering machine.
During a conversation.
Use one of the following:
oSend DTMF
oPress the star key (if allowed by system configuration).
Enter DTMF code.
The function is automatically cancelled when you hang up.
2.13Mute, so that your caller cannot hear you
You can hear your caller but he/she cannot hear you:
From the set
During a conversation.
Disable microphone The key lights up .
Resume the conversation The key is no longer lit .

8018 DeskPhone
8AL90332ENAAed01
16 /37
3 During a conversation
3.1 Making a second call during a conversation
During a conversation.
New call
Number of second caller The first call is on hold.
Other methods for calling a second caller
Dial directly the number for your call.
Name of second caller.
Select the 'Redial' function.
Programmed line key.
To cancel your second call and recover the first:
You are in conversation with the second caller and the first one is on hold.
Use one of the following:
oEnquiry off
oHang up.
You are on the line with your first contact.
If you make an error, hang up: your telephone will ring and you will recover your first call.
3.2 Answering a second call during a conversation
During a conversation, another person is trying to call you Name or no. of the caller displayed
for 3 seconds.
Use one of the following methods to answer the displayed call (Multiline set).
oLine key for which icon is flashing .
oTake call
The first call is on hold.
To return to your first caller and end the conversation in progress.
The second call is ended.
To return to the first contact, use one of the following
oSelect the 'incoming call' icon .
o
oLift the receiver.

8018 DeskPhone
8AL90332ENAAed01
17 /37
3.3 Switching between calls (Broker call)
During a conversation, a second call is on hold.
Select the contact on hold You are in conversation with the second caller and the first one
is on hold.
3.4 Transferring a call
To transfer your call to another number:
During a conversation.
Calling a second person during a conversation The first call is on hold.
You can transfer the call immediately or wait for your contact to answer before transferring the
call.
Transfer
Transfer between two outside calls is not generally possible (depends on country concerned and system
configuration).
3.5 Three-way conference with internal and/or external callers (conference)
During a conversation, a second call is on hold.
Conference You are in conference mode.
Cancel conference and return to first caller (If conference is active)
End of conference.
Hang up on all caller (If conference is active)
Hang up.
After the conference, to leave your two callers talking together:
Transfer
Hang up.
3.6 Talk simultaneously to more than 2 callers
You are in a conference call with 2 callers. To add another caller to the conference:
Add
Dial the number of your caller (dial, directories, last numbers dialed...).
Your caller answers.
Insert You are on the line with the additional contact.
During a 3-way conference, you can add up to three additional participants.

8018 DeskPhone
8AL90332ENAAed01
18 /37
3.7 Placing a call on hold (hold)
Exclusive hold:
During a conversation, you wish to place the call on hold and recover it later, on the same telephone.
During a conversation.
Put on hold Your call is placed on hold .
Recover the call on hold:
Select the call on hold .
Common hold:
To recover your call on any telephone in your system.
During a conversation.
Hold Your call is placed on hold .
Recover the call on hold from any telephone:
Select the call on hold .
3.8 Placing an outside call on hold (parking)
You can place an outside call on hold and recover the call on another telephone:
During a conversation.
Park the call
A parking announcement message is displayed on the screen of the parking destination set.
To recover the parked call:
To automatically take the parked call, pick up the handset of the parking destination set.
Reach the 'Menu' page.
Settings My services Consult Call pick up services Park/retrieve
If the parked call is not recovered within a preset time (default value 1 min 30), it is transferred to the
operator.
3.9 Intrusion into an internal conversation
Your caller's line is busy. If the number is not 'protected' and if authorised, you can intrude into the call:
Intrusion
Same key to exit (Intrusion).
Protection against intrusion:
Press programmed key (The programmed key has to be configured by the system).
Enter caller's number.
Protection is cancelled when you hang up.

8018 DeskPhone
8AL90332ENAAed01
19 /37
3.10Adjust audio volume
During a call, to adjust the volume level of the loudspeaker or receiver:
During a conversation.
Adjust audio volume.
3.11Signal malicious calls
This key lets you signal a malicious call. If this call has an internal source, it is signalled to the system by
a special message.
You receive a malicious call.
Malicious

8018 DeskPhone
8AL90332ENAAed01
20 /37
4 Sharing
4.1 Answering the general bell
When the operator is absent, outside calls to the operator are indicated by a general bell. To answer:
Reach the 'Menu' page.
Settings My services Consult Call pick up services Night service call pick up
4.2 Manager/Assistant filtering
System configuration allows 'Manager/Assistant' groups to be formed, so that the manager's calls can be
directed to one or more assistants.
The programmed key has to be configured by the system.
From the manager or assistant telephone:
Press programmed key Incoming calls are filtered by a chosen person (assistant, etc.).
Same key to cancel.
Filtering is indicated on the manager's telephone by the icon corresponding to the 'screening'
programmed key.
4.3 Call pick-up
You hear a telephone ringing in an office where no-one can answer. If authorised, you can answer the
call on your own telephone.
If the telephone ringing is in your own pick-up group:
Reach the 'Menu' page.
Settings My services Consult Call pick up services Group call pick up
If the telephone ringing is not in your pick-up group:
Reach the 'Menu' page.
Settings My services Consult Call pick up services Individual call pick up
Number of telephone ringing.
The system can be configured to prevent call pick-up on certain telephones.
