Allworx 9212 User manual

Allworx
Phone Guide
9212/9212L

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopy, recording, or otherwise without the prior
written permission of Allworx.
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of
their respective owners.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page i
Table of Contents
1GETTING STARTED .................................................................................................................................................... 1
1.1 WHAT IS IN THE BOX?...............................................................................................................................................1
1.2 CONNECTING THE PHONE.........................................................................................................................................1
2ADJUSTING YOUR PHONE ........................................................................................................................................ 3
2.1 BASE ASSEMBLY AND ADJUSTING THE ANGLE OF THE PHONE.....................................................................................3
2.2 CHANGE THE LABELS FOR THE PFKS (PROGRAMMABLE FUNCTION KEYS) ..................................................................3
2.3 VOLUME ..................................................................................................................................................................3
3INTRODUCTION TO YOUR ALLWORX PHONE........................................................................................................ 4
4BUTTON OPERATION.................................................................................................................................................5
4.1 MESSAGES ..............................................................................................................................................................5
4.2 INTERCOM ...............................................................................................................................................................6
4.3 CONFERENCE ..........................................................................................................................................................6
4.4 TRANSFER...............................................................................................................................................................6
4.5 RELEASE.................................................................................................................................................................7
4.6 PARK.......................................................................................................................................................................7
4.7 INFO........................................................................................................................................................................7
4.8 SPEAKER.................................................................................................................................................................7
4.9 MUTE/DND .............................................................................................................................................................7
4.10 HOLD.......................................................................................................................................................................8
5PHONE OPERATION................................................................................................................................................... 9
5.1 PLACING A CALL.......................................................................................................................................................9
5.2 RECEIVING A CALL ...................................................................................................................................................9
5.3 ENDING A CALL........................................................................................................................................................9
5.4 HEADSET.................................................................................................................................................................9
5.5 DIRECTORY DIALING.................................................................................................................................................9
5.6 REDIAL A NUMBER .................................................................................................................................................10
5.7 MISSED CALLS.......................................................................................................................................................10
5.8 PRESENCE SOFT KEY.............................................................................................................................................10
5.9 IGNORE AND SILENCE SOFT KEYS...........................................................................................................................10
5.10 PROGRAMMABLE FUNCTION KEYS...........................................................................................................................10
6SYSTEM FEATURES .................................................................................................................................................12
6.1 OPERATOR ............................................................................................................................................................12
6.2 USER /RESOURCE EXTENSIONS.............................................................................................................................12
6.3 LEAVE A USER A VOICEMAIL ...................................................................................................................................12
6.4 BUSINESS SPEED DIAL...........................................................................................................................................12
6.5 AUTO ATTENDANT..................................................................................................................................................12
6.6 OVERHEAD PAGING................................................................................................................................................12
6.7 ACTIVATE DOOR RELAY..........................................................................................................................................12
6.8 CALL QUEUES........................................................................................................................................................12
6.9 CALL FORWARDING................................................................................................................................................13
6.10 PAGING ZONES ......................................................................................................................................................13
6.11 CONFERENCE CENTER...........................................................................................................................................13
6.12 ALLWORX MESSAGE CENTER .................................................................................................................................13
6.13 ANSWER RINGING PHONE USING ANOTHER HANDSET..............................................................................................14
6.14 PARKING................................................................................................................................................................14
6.15 CALL MONITORS ....................................................................................................................................................15
6.16 BUSY LAMP FIELD (BLF)........................................................................................................................................15
7ADVANCED TOPICS..................................................................................................................................................16
7.1 PHONE CONFIGURATION MENU...............................................................................................................................16
7.2 PERSONAL SPEED DIAL..........................................................................................................................................16
7.3 PREFERENCES.......................................................................................................................................................16
7.4 REBOOT THE PHONE ..............................................................................................................................................17
7.5 CLEAR CALL HISTORY............................................................................................................................................17
7.6 REFRESH DIRECTORY ............................................................................................................................................18
8ADDITIONAL INFORMATION....................................................................................................................................19
9WALL MOUNTING (OPTIONAL) ...............................................................................................................................20
10 REGULATORY NOTICES..........................................................................................................................................21

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page ii
-This page intentionally left blank. -

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 1
1 Getting Started
1.1 What is in the box?
Check the contents of the box your phone came in. You should have:
•Allworx 9212 phone and base
•Handset with cord
•Phone Functions Reference Card (this card slides between the base and back of phone)
•This guide
Not included but also needed:
•Ethernet cable to connect the phone to the network
•Power supply: 24VDC, 400 mA (or a network connection with Power over Ethernet)
1.2 Connecting the Phone
Follow these steps to connect your phone (see the figure below):
1. Connect the handset to the Handset jack on the back of the phone using the coiled handset cord.
2. Plug one end of the Ethernet cable into the Network jack on the back of the phone. Plug the other end
into your Ethernet jack on the wall.
WARNING: Do not connect to an analog phone line.
3. A computer may be connected to the network through the phone’s Computer jack.
4. If you are using Power over Ethernet (PoE), the power to the phone was supplied when you connected
the Ethernet cable. If this is the case, skip to step 6.
5. If you are not using PoE, obtain a power supply, connect the power cable to the phone, and then plug
the other end into an outlet. It is a good idea to use a surge protector.
6. Thread cables through the strain relief guide.
7. After applying power, the phone will initialize itself. You can watch its progress on the phone’s screen.
A normal sequence would include:
a. Allworx Logo.
b. Starting network.
c. Loading configuration files.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 2
d. Station Init complete.
e. After successful startup, the phone will display date, time, your presence, your name, and
extension.
f. If the phone does not follow this sequence or displays an error, contact your System
Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 3
2 Adjusting Your Phone
2.1 Base Assembly and Adjusting the Angle of the Phone
You can adjust the Allworx 9212 phone on its base so that it is easy to use and easy to read the screen.
1. Lay the phone face down on a soft surface with top of the phone pointed away from you.
2. The base will connect to the back of the phone in one of three positions, thus allowing the phone to be
adjusted at different angles when sitting on a desktop. The nearest set of holes provides the steepest
angle.
3. Notice that the base has both fixed and flexible tabs. Hold the base with the tabs pointed away, fixed
tabs down and flexible tabs up.
4. Place the fixed tabs in the desired holes on the back of the phone.
5. Rotate the base until the flexible tabs click into place.
To remove the base:
1. Press down on the flexible tabs and release them from their holes.
2. Rotate the base until the fixed tabs easily lifted out of their holes.
2.2 Change the Labels for the PFKs (Programmable Function Keys)
To avoid misdialing, update the PFK labels whenever a PFK configuration is changed. To add or change a
label:
1. Remove the paper from beneath the plastic label cover by lifting the bottom edge of the plastic cover to
release it.
2. Add text in the space corresponding to the desired PFK.
3. Place the label onto the phone and snap the cover back in place.
A blank label Microsoft Word™ template can be obtained on the Allworx.com website.
2.3 Volume
The volume of the incoming ring, handset speaker, speakerphone, and the headset is adjustable.
To adjust the Volume:
•Press the Volume bar on the left (decrease) or right (increase) to adjust the incoming ring for desired
audio level. Do not lift the handset or turn on speakerphone.
•To adjust other volumes, pick up the handset, turn on the speakerphone or headset, and press the
Volume bar, as desired.
•The screen shows which device is being adjusted.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 4
3 Introduction to your Allworx Phone
Your new Allworx phone supports two modes of operation: PBX (Private Branch Exchange) Mode and Key
System Mode. Your System Administrator has pre-configured the phone for one of these two modes. Each
programmable button on the phone will function differently depending on the mode of the phone.
Allworx 9212 VoIP Phone

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 5
4 Button Operation
Button
Light
Purpose
KEYPAD None Use the keypad to dial numbers in order to place a call.
MESSAGES Solid red if new
messages are present. Access the Message Center.
INTERCOM Solid green when in
use. Use the phone as an intercom.
CONF
(Conference) Blinking green while
making connections
Solid red when in use.
Talk to two parties at a time using the 3-Way Conference
functionality.
Will indicate when Call Assistant - Call Recording is in progress.
TRANSFER Solid red until the call
is transferred. Transfer a call to another extension using a Blind or an Attended Transfer.
RELEASE None Disconnect the call you are on currently.
PARK None Parks a call (PBX behavior) or system-wide hold (key system
behavior)
INFO Solid green when in
use. View functionality of all the buttons on the phone: Feature Keys, Programmable Function Keys (PFK), Scroll Keys, Selection Keys,
and Keypad.
SPEAKER Solid green when in
use. Use the phone as a speakerphone or activate a headset.
MUTE/DND Solid red when Mute. Turn off the microphone in handset, speakerphone, or headset.
Solid amber in Do not
Disturb mode. Prevent incoming calls (Do Not Disturb).
Flashing amber. Indicate Presence other than “In Office”
HOLD Solid red if the call is
on hold. Place a call on hold.
Navigation None Use the up arrow to move up on the LCD screen. Use the down
arrow to move down. Use the button in the center to Select and Save
settings.
Soft Key
Selection None Use the buttons below the display to select a soft key.
4.1 Messages
If the MESSAGES button is red, you have a new message in your voicemail inbox. The number of new
messages appears on the screen. To listen to your voicemail, press the MESSAGES button. You will be
required to enter your password to access your messages.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 6
4.2 Intercom
1. Press the INTERCOM button and dial the extension of the person you would like to talk to.
2. The call is connected when the LCD screen displays Active Call.
3. Start talking. The person you called will hear you over their speaker.
4. Press the INTERCOM or SPEAKER button to end the call.
5. To deny an incoming Intercom request, press the IGNORE soft key.
4.3 Conference
After connecting to the first person you want on the conference call, follow these steps:
1. Press the CONF button.
2. Select another Call Appearance PFK and dial the number of the second person you want on the
conference call.
3. Press the CONF button.
4. Press the Call Appearance PFK where the first person is on hold.
5. All three callers are now able to conference. The CONF button will be illuminated solid red.
6. One party may exit the conference by hanging up; the remaining two parties will continue to be
connected.
7. If you desire to have a private conversation with one of the parties, you may split the conference using
the following steps:
a. Use the Up / Down navigation arrows, to select the Call Appearance PFK of the person you
wish to put on hold and then press the HOLD button. (The display will show the two parties
involved in the conference).
b. You may now talk to the remaining party.
c. The Call Appearance PFK for the person on hold will be flashing. To have the person re-join the
conference, press CONF, then select the flashing Call Appearance PFK. The three-way
conference is then re-established.
8. End the conference by hanging up.
4.4 Transfer
Unannounced (Blind) Transfer
1. Press the TRANSFER button. The current call is placed on hold.
2. At the dial tone, dial the extension to where you want to transfer the call.
3. The call will automatically be transferred. If the recipient does not answer, the call will follow the
recipient’s call route.
Announced (Attended) Transfer
To talk to the person to whom you are transferring the call to before the transfer goes through.
1. Press the TRANSFER button.
2. Select a second Call Appearance PFK.
3. Dial the extension to where you want to transfer the call.
4. Talk to the new recipient.
5. Press the TRANSFER button again. The two parties will now be connected.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 7
6. If you want to cancel the transfer, press the RELEASE button. To return to the original caller, press the
Call Appearance PFK where the call is currently being held.
4.5 Release
The RELEASE button is used to hang up an active call or to abort a new call setup, such as the middle of a
transfer operation.
4.6 Park
PBX Behavior on a call appearance
•To park an active call, press the PARK button.
•The phone briefly displays the parking orbit1
Key System Behavior on an outside line extension on which the call is parked.
•To place an active call in a “system-wide hold”, press the PARK button. Any phone with a PFK for this
outside line will be able to retrieve the call.
4.7 Info
The INFO button is used to get information regarding the other buttons on your phone. For example, you can
use the INFO button to determine the numbers that have been programmed for each speed-dial button.
To use this feature:
1. Press the INFO button.
2. Press any of the other buttons on the phone.
3. The screen will display a brief description of the selected button.
4. Press the INFO button a second time or let the screen time out to exit the description screen.
4.8 Speaker
Press the SPEAKER button for hands-free use of the phone.
If you are already using the handset, you can press the SPEAKER button and then place the handset on hook.
Take the handset off the hook to continue using it again. When you are finished with the call, press the
SPEAKER button to hang up.
Note: If you are using a headset, use the SPEAKER button to activate it. You will not be able to use the
speakerphone while using a headset (Section 5.4).
4.9 Mute/DND
Mute a Call
During a call, you can press the MUTE/DND button to turn off the microphone in the handset, speakerphone,
or headset. The light on the MUTE/DND button is red when the phone is muted.
Prevent Incoming Calls using Do Not Disturb (DND)
1. When not on a call, press the MUTE/DND button.
2. The light on the MUTE/DND button will appear amber.
3. With Do Not Disturb enabled, your phone will not ring. All calls will follow the next step in your active
call route.
†Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 8
4. Press MUTE/DND to turn Do Not Disturb off your phone. The light on the MUTE/DND button will turn
off.
4.10 Hold
To place a call on hold:
•Press the HOLD button.
oThe HOLD button will blink red once.
•Place the handset on the hook.
oThe Call Appearance PFK for the call that is on hold will blink green until the call is picked up
again.
To take the call off hold:
•Pick up the handset.
oIf more than one call is on hold, the most recent call is connected.
•Press the SPEAKER button (for hands-free).
•The caller ID of the call picked up will appear on the display.
To pick up a different call on hold:
•Press the flashing PFK for that call or use the Up / Down navigation arrows to display the call on the
screen, and then pick up the handset.
If you have a call on hold and a new call comes in, the new call will be answered when the handset is lifted.
If Music on Hold is enabled for your company’s system, callers on hold will hear music.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 9
5 Phone Operation
5.1 Placing a Call
•Outbound calls can be placed by pressing the following PFKs:
oCall Appearance
o
: can be used to place extension-to-extension calls or to obtain an outside line
(must dial 9†first).
Line Appearance: seizes the outside line without dialing 9†2
ofirst. Speed Dial
: automatically dials the programmed number
5.2 Receiving a Call
•Inbound calls can be answered with the following PFKs (when flashing):
oCall Appearance
o
: can receive either an extension-to-extension call or an outside line directed to
an extension assigned to the phone.
Line Appearance
o: can receive inbound calls from an outside line.
oCall Monitor
Note: Unless configured otherwise, incoming calls to your phone will ring the audible indicator and flash one
of the Call Appearance or Line Appearance PFKs.
Call Queue
5.3 Ending a Call
Release a call by using one of the following:
•Place receiver back on hook. If using the speakerphone or headset press the SPEAKER button.
•Press another PFK.
oIf a second call is coming in on another PFK, pressing that PFK will end the current call and
answer the incoming call (unless auto on hold is enabled).
•Press the RELEASE button to end a call and start a new call.
5.4 Headset
1. Plug the cable for the headset into the headset jack on the back side of the phone.
2. Press the SPEAKER button. (You cannot use the speakerphone and headset at the same time).
3. When finished with the call, press the SPEAKER button to disconnect.
A PFK can be created to activate the headset instead of using the SPEAKER button. The PFK has to be setup
by the System Administrator.
5.5 Directory Dialing
1. Press the Up / Down navigation arrows to view a list of all User Extensions, System Extensions, and
Speed Dial numbers by Name or Description. Additionally, when the phone is “off-hook”, the rightmost
soft key changes to the directory listing option: PHONEBK. Press the PHONEBK soft key to initiate the
directory listing.
2. Use the Up / Down navigation arrows to highlight the name (or description) and extension. You may
also press an alphabetic key on the keypad to jump to the desired section of the directory.
3. Press the Select button to dial the number.
†Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 10
5.6 Redial a Number
•You can automatically dial the last number called by selecting the REDIAL soft key on the phone’s
display screen.
•Select the CALLS soft key. Us the Up / Down navigation arrows to highlight the desired call. Press the
Select button .
•A PFK can be programmed by your System Administrator to redial the last number called.
5.7 Missed Calls
If a call is missed, a message will appear on the phone’s display. Use the following steps to see details of the
missed calls:
1. Select the CALLS soft key.
2. Use the Up / Down navigation arrows to view your missed calls.
3. Select the DETAIL soft key to view the date and time of the missed calls.
4. Press the Select button to call the number.
5.8 Presence Soft Key
Change your Presence setting directly from the phone. The Presence states are: ‘In Office’, ‘At a Meeting’, ‘On
Vacation’, ‘On Business Trip’, ‘At Home’, ‘Away’, and ‘Busy’.
1. Select the PRESNCE (presence) soft key.
2. Use the Up / Down navigation arrows to view the presence states.
3. Press the Select button to change your presence. All inbound calls will follow the call route for this
presence state.
5.9 Ignore and Silence Soft Keys
•While a call is ringing, the SILENCE and IGNORE soft key options appear.
•Pressing the IGNORE soft key stops the audible ringing. However, the PFK that the call is coming in on
will continue to flash until the call is answered or the caller hangs up.
•Pressing the SILENCE soft key stops the audible ringing. However, the information on the incoming call
will still be displayed and the PFK that the call is coming in on will continue to flash until the call is
answered or the caller hangs up.
5.10 Programmable Function Keys
The following features can be programmed by your System Administrator into any of the 12 PFKs on the
Allworx 9212.
•ACD Appearance
•Busy Lamp Field (BLF)
•Call Appearance
•Call Monitor
•Call Supervision
•Emergency Alert
•Centrex Flash
•Headset
•Info

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 11
•Park
•Personal Speed Dial
•Redial
•Hot Desk
•Line Appearance
•Messages
•Parking Orbit
•Queue Alarm
•Queue Appearance
•Schedule
•Speed Dial

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 12
6 System Features
6.1 Operator
Dialing (or transferring to) 0†from any phone will initiate a call to the company operator.
6.2 User / Resource Extensions
Dialing (or transferring to) any extension between the range of 100 – 299†3
(3 digit mode) or 1000 – 2999†(4
digit mode) will connect a call to another user or to a call route (set up by the System Administrator) assigned
to the extension.
6.3 Leave a User a Voicemail
Dialing (or transferring to) any 3†+ user extension will connect a call to a particular user’s voicemail.
Note: 3†+ a resource extension only works if the extension routes directly to a user’s voicemail.
6.4 Business Speed Dial
The System Administrator can specify extensions 350 – 399†or 34000 – 34999†to ring particular numbers.
The System Administrator can program the extensions to a phone’s PFK.
6.5 Auto Attendant
Dialing (or transferring) to extension 400†or 431†from any phone will go to the default Auto Attendant.
Dialing (or transferring) to extension 431†- 439†from any phone will go to a specific Auto Attendant set up by
the System Administrator.
6.6 Overhead Paging
If the system is configured and connected to an Overhead Paging system, dialing extension 402†activates
paging. Once activated, users can use their phone to make an announcement that is transmitted through each
handset’s intercom or to the overhead paging system.
Note: An overhead paging system is a 3rd party product attached to the Allworx system.
6.7 Activate Door Relay
If the system is configured and connected to a Door Relay, dialing extension 403†activates the relay.
6.8 Call Queues
Logging in/out of a Queue
To log into a Queue:
1. Press and hold the Queue PFK on your phone corresponding to the Queue to be logged into.
2. The button will change color from red to either off (no calls in queue) or flashing green (if a call is
waiting in the Queue).
Note: By default, the phone will automatically be logged into the Queue.
To log out of a Queue:
1. Press and hold the Queue PFK on your phone corresponding to the Queue to be logged out of.
2. The button color change to solid red (logged out of Queue).
Placing a Call in a Queue4
†Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 13
Calls can be put in a Queue either by dialing an extension routed to a Queue from an Auto Attendant or by
the following steps:
To place a call in a Queue:
1. Press the TRANSFER button.
2. Dial 440#†(# representing Queues 0 through 9) or an extension that is routed to a Queue.
Retrieving a Call from a Queue
Call Queues are created and programmed by your System Administrator. There are two ways to retrieve a
call from a Queue:
•Dial extension 441#†(# representing Queues 0 through 9).
•The System Administrator can define the PFKs on your Allworx phone as Queue Appearances for one
or more Call Queues:
The Queue PFK may be in one of several states:
oRed means you are currently logged out of the Queue.
oOff (not lit) means you are logged into the Queue but there are no calls waiting in the Queue.
oFlashing green means there is at least one call in the Queue and will flash on all phones that are
logged in.
When the Queue PFK light is flashing, you will be able to pick up the call by pressing the PFK or
SPEAKER button for hands-free mode, or by using your handset or headset and pressing the PFK.
If Music on Hold is enabled for your company’s system, queued callers will hear music.
6.9 Call Forwarding
Dialing 45†+ an extension will forward all calls that come into the phone to that extension.
To disable Call Forwarding for the phone, dial extension 450†.
6.10 Paging Zones
Dialing 46#†(# representing a Paging Zones 0 through 9) on the phone will broadcast audio to any other
phones that are members of the Paging Zone, which is set up by the System Administrator.
6.11 Conference Center
The Conference Center is an optional feature. Dial 408†to access the Conference Center. For details on using
conference center refer to the Allworx User’s Guide found on the website at www.allworx.com.
6.12 Allworx Message Center
There are two different menus for accessing your voicemail:
•Visual Message Center - Displays your messages list on your phone and uses softkeys for actions
•Audio Message Center - Calls the Message Center and uses audio menus
Pressing the Messages button on your phone starts the process for viewing your messages on your phone.
The login screen is displayed. If you wish to use the audio menus, press the Messages button again.
Note: Your System Administrator may have changed the function of the Messages button so that pressing it
immediately calls the Audio Message Center. If so, the Visual Message Center operation is not available.
†Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 14
You can also reach your mailbox by dialing 6†+ your extension from any office phone or from the company
Auto Attendant.
The Message Center allows the user to:
•Listen to new and saved voicemails.
•Send a message to another user.
•Change presence setting.
•Change name recording.
•Manage message greetings.
•Change password.
Note: For more information refer to the Allworx User’s Guide found on the Allworx.com website.
6.13 Answer Ringing Phone Using another Handset
A user can answer another user’s ringing phone from their own handset by dialing 7†5
+ the alternate phone’s
extension.
6.14 Parking
A call can be parked by pressing the PARK button. The maximum wait time a caller is parked and the
subsequent routing is defined by the system administrator.
Park a Call using a Line Appearance PFK
Parking a call on a Line Appearance PFK will act as a “system-wide hold” in that any phone with a Line
Appearance PFK assigned to the same outside line will be able to retrieve the call by pressing the Line
Appearance PFK. This would typically be used in systems configured for Key System Behavior.
Parking a Call from the Hold Screen
The currently displayed call on hold can be parked by pressing the PARK button. The call is parked without
retrieving it from Hold.
Retrieving a Parked Call
Parked calls can be answered by dialing the parking extension from any handset.
Your System Administrator can define one of the PFKs on your Allworx phone as a Parking Orbit PFK for
one or more of the parking extensions. Your System Administrator can also set a reminder to ring the
handset when the call has been parked beyond a specified period of time.
The Parking Orbit PFK may be in one of several states:
•Off (not lit) means the Parking Orbit is idle, no parked call.
•Amber PFK means a call has been parked by that particular handset within the last five seconds. After
five seconds, the button will turn to slow flashing green.
•Slow flashing green means a call has been parked using this handset for more than five seconds.
•Slow flashing red means a call has been parked on this Parking Orbit, but not
When the Parking Orbit PFK light is flashing, you will be able to pick up a call in the Parking Orbit by
pressing the PFK or SPEAKER button for hands-free mode, or by using your handset or headset and then
pressing the PFK.
by this handset.
If Music on Hold is enabled for your company’s system, the parked caller will hear music.6
5 †Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.
†Digits may vary per system. Please check phone functions tab of the My Allworx Manager page or consult with your Administrator.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 15
6.15 Call Monitors
Call Monitors are created and programmed by your System Administrator. The System Administrator can
define the PFKs on your Allworx phone for one or more Call Monitors.
The Call Monitor PFK may be in one of several states:
•Off (not lit) means the Call Monitor is idle, no incoming call.
•Fast flashing green means there is an incoming call (with the handset set to ring).
•Green means there is an active call on this handset.
•Fast flashing red means there is an incoming call (with the handset set not
•Slow flashing green means an active call is on hold by this handset.
to ring).
When the Monitor PFK light is flashing, you can pick up the call by using your handset or speakerphone
and pressing the PFK.
6.16 Busy Lamp Field (BLF)
Another user’s phone can be linked to a PFK on your phone. The PFK will automatically dial the user’s
extension when pressed. The BLF PFK will flash red when the user has an incoming call and it will be solid
red when the user is on the phone.

Phone Guide – 9212/9212L
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2011 Allworx Corp. All rights reserved. All other names may be trademarks or registered trademarks of their respective owners.
Revised: December 1, 2011
Page 16
7 Advanced Topics
7.1 Phone Configuration Menu
The following can be viewed or changed by selecting the CONFIG soft key:
•Personal Speed Dial
•Preferences
•Reboot Phone
•Hot Desk Login
•Clear Call History
•Refresh Directory
Caution: Check with your System Administrator before making any changes.
7.2 Personal Speed Dial
You can program your frequently called numbers and dial them with the touch of a button.
Setting up a Personal Speed Dial
1. Press the CONFIG soft key.
2. A menu will appear. The first option will be Personal Speed Dial. Press the Select button .
3. Use the Up / Down navigation arrows to choose a desired speed dial number, press the Select button.
4. Use the keypad to enter the phone number or extension, press the Select button.
5. Use the keypad to enter a name for the speed dial, press the Select button.
Note: The ‘#’ key puts a space between characters. The Down navigation arrow acts as a backspace.
Using a Personal Speed Dial
1. Pick up a line.
2. Press the SPDIAL soft key.
3. Choose the desired speed dial number on the keypad.
7.3 Preferences
1. Press the CONFIG soft key button.
2. Press the Down arrow button to select Preferences. Press the Select button .
3. Select from the following list using the Up / Down navigation arrows to make the changes:
a. LCD Settings
b.
– Controls the LCD display settings. Use the Volume bar or Up / Down navigation
arrows to adjust.
Call History Size
c.
– Number of calls kept in History. 0 – 99 (Default: 99).
Clock Mode
d. – Time Display for LCD Screen. Hold Reminder Mode
e.
– How the hold reminder behaves.
Redial Memory
f. – To have the last number dialed stored in the phone. Audible Dialing
g.
– Tones are heard when a key is pressed.
Call Timer Display
h. – Displays the length of time during a call. Intercom Auto Answer – When a call is placed to a phone using the INTERCOM button, the phone
receiving the call will automatically answer using Intercom/Speakerphone.
