Ballard Designs Tuscan MO227 User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 6-13-2019 Page 1 of 4
PRODUCT NAME: Tuscan File Console
ITEM NUMBER: MO227
ASSEMBLED DIMENSIONS : 30”H x 36”W x 17 1/4”D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
IMPORTED

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 4
Ltr.
A 4
B1
Qty. Hardware Included
Ltr.
1
Qty. Components
C
TOOLS NEEDED:
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
File Rod
Anti-Tip Kit - Part B
Hardware Pack and File Rods
Located on underside of Cabinet
NOTE
HARDWARE

Page 3 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 1: Locate and remove File Rods (A) from underside of console and insert in notches on
inside drawer edge as shown.
If necessary, Console may be leveled by adjusting Rotary Levelers located under each
corner. Turn clockwise/counterclocwise until level.
STEP 2:
(A)

Page 4 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Attach 2 Brackets (C) to the back of the Console with the Small Screws (A) through the
smaller holes. Screw the remaining Brackets (C) into a wall stud with the Large Screws (B)
2 inches below the Brackets attached to the furniture. Align the Brackets vertically and
string in the Retention Belts (D). Confirm Straps are securely laced and locked.
Ltr.
A
(B)
(A)
(C)
(C)
(D)
2 Small Screw
Retention Belt
Qty. Hardware Included
ANTI-TIP KIT INSTALLATION (PART B):
B2 Large Screw
C4 Bracket
D2
Cleaning & Care:
DO NOT use alcohol based products or spray polisher as finish damage may result.
Dust with a soft cloth.
NOTE: To prevent accidental tipping of the Console, both drawers are equipped
with safety locks which permit only one drawer to be open at a time.
Console
WARNING
Tip-Over Hazard
WALL BRACKET MUST BE ATTACHED TO WALL STUD
Prevent tipping accidents. Anchor your furniture.
WALL STUD
