BROSA Field Double Open Shelf User manual

Field Double
Open Shelf
ASSEMBLY GUIDE
V1

FOR YOUR SAFETY
Lift, don’t drag. This protects
your floor and product.
Avoid loose screws. Tighten
fixtures every few months.
Assembly requires 2 people.
It's always easier with a
friend.
Contact our support online
or call 1300 027 672.
Check the assembly guide
for required components.
?
Assembling this product on
a soft surface protects its
finish.

Components
Before you get started, check you have all of the pieces below.
If anything’s missing, we’ll sort it out right away. Simply visit:
www.brosa.com.au/pages/product-return-and-parts-request
Hardware
A x 6
(M8 x 20)
C x 1
(M4 x 30 x 107)
B x 16
(M6 x 50)
Shelf x 4
Stand x 2
①
②
Brace x 4
③

Connect both stands ② with the braces ③using
the short bolts A as shown in the diagram below.
Step 1
Ax 6
Cx 1
②
②
③
A
C

Align a shelf ① with the structure formed in Step
1. Make sure the bolt holes overlap. Fit a long bolt
Binto the hole and tighten it with the Allen key C.
Repeat this for the remaining holes to fix the shelf
in place and then repeat the process for the
remaining shelves.
Step 2
Bx 16
Cx 1
①
B C

Flip the completed piece of furniture and place it
upright in its desired location. Enjoy your new
Field Double Open Shelf!
Step 3

It is not mandatory but strongly recommended to install anti-tip kit for
safety.
Anti-Tip Kit Installation
Hardware
Wall Fixings
aa x 2 bb x 1 cc x 2
(M4 x 17)
Wood
If fixing to wood
make sure that it
isn’t chipboard as
screws can easily
pull away from the
core structure.
Brick or Masonry
Use an appropriate
wall plug provided
you are sure your
wall is sound.
Cavity Wall
Special toggle wall
plugs are needed.
Seek expert
advice.
Because of the variety of wall compositions, we can’t provide you with
appropriate wall fixings. Please identify your wall composition and
contact your local hardware store to get the appropriate fixings.

What You Need
Attach the bracket aa securely to the back top of the
product using the short screws cc provided.
Step 1
aa x 1
cc x 2
cc
aa

Determine where the piece is to be placed and mark
locations on the wall for the mounting bracket aa using a
pencil. Move the furniture out of the way so that the
bracket can then be mounted to the wall.
Step 2
aa x 1
aa

Wall fixings are not provided. Attach the mounting
bracket aa to the wall using appropriate fasteners based
on your wall composition.
Step 3
