Keypad KCIEN - KCIEN SBP - KCIEN IRC

EN EN
KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
2cdvigroup.com
Construction: Stainless steel
Self-contained
Surface mount
Capacity of 100 user codes
of 4 to 6 digits
Stored in EEPROM memory
Buzzer audible signal
Backlit keys
Available versions:
- KCIEN Request to enter button
- KCIEN/SBP Standard version
- KCIEN/IRC IRC-feature
2 dry contact relay outputs
Adjustable time output:
1 to 99 seconds and toggle mode
Operating voltage:
12-24Vac and 12-48Vdc
Consumption: 40 to 100mA
Mounting with Torx®screws
Dimensions (L x W x D): 140 x 85 x 20 mm
 Usermodicationofcodes
Recommended power supplies.
- ADC335 (230V input), BS60 (230V input).
-Separatepowersupplyforthecontrolelements.
Wiring reminder
Make sure to insulate any unused wires.
Mounting recommendations
Mountthekeypadonaatsurfacetoavoid
any vandalism and to insure the best mounting.
Security advice
Forsecurityadvicereasons,changethefactory
defaultmastercode.Whenselectingamastercode
and user code avoid simple codes
(example : 3 4 5 6 7).
Back EMF protection
Tosecurethesystemfrombackelectromagnetic
eldsdonotforgettomountthevaristor
in parallel on the lock.
2]2] NOTES & RECOMMENDATIONS
1] GENERAL INFORMATIONGENERAL INFORMATION
IP64
-25°C to +70°C
HIGH RESISTANCE TO
VANDALISM
140
20
85

EN EN KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
3cdvigroup.com
1 2
43
3] MOUNTING KIT3] MOUNTING KIT
Place the back plate of the
KCIEN-KCIENSBP on the
wall then mark with a pen
the hole location then drill
the 2 mounting holes (drill
bit Ø5mm and 35MM hole
depth) and the hole wiring
access.
Insert the 2 plastic
anchors in the holes.
Mount the back plate with
the M4x30 screws.
4] MOUNTING INSTRUCTIONS
Once you have made sure that the mounting kit is complete and that you prepared the cables
oftheKCIEN/KCIENSBPkeypadthenyoucanproceedandmounttheproduct.Makesurethat
you have all the appropriate tools (drill, screw drivers and a meter tape...) and follow the
mountinginstructionsoffortheKCIEN/KCIENSBPkeypad.
Fasten the KCIEN-KCIENSBP
keypad to the back plate
with the M5x8 TORX®
screw and the T20 TORX®
spanner hardware.
Insert the cable in the
hole access area of the
back plate.Then mount
the keypad on the
back plate, placing rst
the top in the hook and
then the bottom.
Varistor
Torx®screw
(M5x8)
T20 Torx®
Spanner
(M4x30)
mounting
screws
Plastic anchors
S5
KCIEN
KCIENSBP
KCIENIRC
11122

EN EN
KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
4cdvigroup.com
PinkGrey
Magnetic lock
Strike
This product is supplied with a varistor.
Itshouldbemountedontheterminalofelectricrelease(electromagneticlock,solenoidbolt,etc...)controlled
bythedevice.Ifthisdevicecontrolsmorethanoneelectronicrelease,theneachlockshouldbetted
withavaristor.Thevaristorcontrolstheoverloadproducedbythestrikecoil-backemf.Itisrecommended
to use a separate power supply when using a Shear Lock Magnet.
Outputs Description
Black Input voltage 12V to 24V ac or 12V to 48V dc
Red Input voltage 12V to 24V ac or 12V to 48V dc
Pink Relay 1 request to exit input
Purple Common
Dark green Clock switch (H1)
Green White Relay2N/Ccontact
Blue red Relay 2 common
Pink gray Relay2N/Ocontact
Orange Relay1N/Ccontact
Yellow Relay 1 common
Brown Relay1N/Ocontact
Light blue Request-to- enter input
Light green User code change
White Tamper switch output
Grey Tamper switch output
Power supply
12V to 24V ac
or 12V to 48V dc
White
Grey
Yellow
Orange
Brown
Green white
Electric strike
KCIEN
KCIENSBP
Back side
KCIEN
KCIENSBP
Front side Varistor
Blue red
Light green
Light blue
Pink
Purple
Dark green
Red
Black
Power control side
power supply
6] WIRING DIAGRAM
H2
H1
ST3
Resetting
memory

EN EN KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
5cdvigroup.com
Default values
- Without codes.
- Illumination time: 10 seconds.
- Relay release time: 1 second.
- Code length: 5-digits.
- Master Code: 1 2 3 4 5.
-Programmingsecuritytime:
120 secondes.
-Codelengthforsubmastercode:
Version 1 relay
(Group 1) = AB,
Version 2 relays
(Group 2) = 13.
- One beep on switching on.
Audible signal:
-Thebuzzerindicatesdifferent
audible signals.
- 1 short beep: Keypad powered.
- 1 long beep: Data computing
in programming or access
granted.
- 2 short beeps: Enter or Exit
  fromprogramming.
- 4 short beeps:
data computing error.
Code length
- The master code and the user
 codescanbeof4to6-digits
in length.
- All the keypad keys can be used
to program a code.
- The master code CAN NOT
be used as a user code.
-TodeleteaspecicUserpinCode
replace it by 0 0 0 0ifcode
 lengthis4-digitsformator
replace it by 0 0 0 0 0ifthe
 codeisin5-digitsformat.or
replace it by 0 0 0 0 0 0ifthe
 codeisin6-digitsformat.
Jumper ST3:
Reset master code and user
codes.
A. Reset master code
and user codes
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
2beepsareemittedtoconrmentry
in programming mode.
2. Press A6 to reset the Master Code
and the User codes.
- One beep is emitted.
  -PressonAand Btoconrmreset
   ofallmemoryofthekeypad.
  -Waitfortwobeeps.   
  -Themastercodeisrestoredtoitsdefault 
value 1 2 3 4 5 and all the user codes
   aredeletedfromthekeypad.
- Once the reset is completed then the keypad
returns to a stand-by operating mode.
OR
1. Cut the power. Place a jumper on ST3.
2. Put the power back.
-Wait approximately 3 seconds.
-Twobeepsareemittedtoconrmreset
   ofthekeypad.
  -RemovejumperfromST3.  
   -Themastercodeisrestoredtoitsdefault
value 1 2 3 4 5 and all the User codes
   aredeletedfromthekeypad.
B. Setting code length
1. Enter the master code twice.
(1 2 3 4 5defaultvaluemastercode). 
   2beepsareemittedtoconrmentry
in programming mode.
2. Press A4 to program the code length.
-One beep is emitted.
  -Press4, 5 or 6forthedigitcode.
  -Onebeepisemittedtoconrm
   programmingofthecodelength.
3. Press A5 to modify the master code.
- One beep is emitted.
- Enter the new 4, 5 or 6-digits master code.
  -Onebeepisemittedtoconrm
   programmingofthenewmastercode.
4. Press B to exit from
programming mode.
2beepsareemittedtoconrmthatthe 
keypad is in stand-by operating mode.
4 beeps indicate a data computing error.

EN EN
KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
6cdvigroup.com
C. Changing the master code
The master code is used only
to enter in programming mode.
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. Press A5 to modify the master code.
-One beep is emitted.
-Enter the new 4, 5 or 6-digits master code.
  -Onebeepisemittedtoconrm
that the master code is programmed.
3. Press B to exit from
the programming mode.
2beepsareemittedtoconrmthatthe
keypad is in stand-by operating mode.
D. Adding, changing or
deleting a user code
User location 00 to 59 is relay 1
User location 60 to 99 is relay 2
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. To add a user code, enter the user
location (from 00 to 99).
Iftheuserlocationisused4beeps 
are emitted, enter the 4, 5 or 6-digits
user code.
3. To Change a User code enter
the user location.
-4 beeps are emitted to indicate that
the user location is already programmed.
- Enter a new 4, 5 or 6-digits code.
  -Abeepisemittedtoconrmthenew 
user code.
4. To delete a User code enter
the user location.
-4 beeps are emitted.
  -Press0 as many times as digits
in the user code.
( ex. 0 0 0 0 0 in 5-digits length code )
  -Abeepisemittedtoconrmtheuser
code has been deleted.
Note:
If the Pin code is already programmed or is
identical to the master code, then 4 beeps are
emitted. Press B to exit from the programming
mode. 2 beeps are emitted to conrm that the
keypad is in stand-by operating mode.
E. Time outputs
This section allows to program
the illumination time and the Relay
activation time.
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. Press A0 to program the key-in
keypad time and the keys lit time.
-1 beep is emitted.
-Enter the time in seconds with 2 digits – 10
for 10 seconds up to 99 for 99 seconds.
   Thebacklightingdimsafter10secondsafter
   thelastkeypressorswitchesoffafter
entering a valid code.
  -Press00forpermanentilluminationkeys.
- One beep is emitted to validate the time.
3. Press A1 to program relay 1
output time (door release time).
(Press A2 for relay 2).
-1 beep is emitted.
- For a latched output enter the time
in seconds using 2 digits – 01 for 1 second
up to 99 for 99 seconds.
  -Press00foratoggledoutput.
- One beep is emitted to validate the time.
4. Press B to exit from
the programming mode.
2beepsareemittedtoconrmthatthe
keypad is in stand-by operating mode.
4 beeps indicate a data computing error.

EN EN KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
7cdvigroup.com
F. Reset master code
On stand-by operating mode,
place a jumper on ST3.
-Wait 1 second and then remove the jumper.
- One beep is emitted.
 -Themastercodeisrestoredtoitsdefault 
value 1 2 3 4 5 in 5-digits code and 1 2 3 4
in 4-digits code.
G. Changing the code by a user
To authorize a user to modify its own
user code connect together the light green
and purple wires.
1. Enter the old user code.
The relay is activated and a beep is emitted.
2. Enter the 2-digits sub master code
(default sub master code AB).
Abeepisemittedtoauthorizemodication.
3. Enter the new user code.
2beepsareemittedtoconrm
the new code.
4. Check the new user code to be sure
   ofthemodication.
H. Setting a sub master code
The Sub Master code allows the user
to change its own code without entering
in programming mode. For security
reasons the code need to be changed
periodically. This feature makes it easier
and faster to change its code.
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. Press A7 to program a sub master
code for the user individual Pin
   codemodication.
-One beep is emitted.
- Enter the new 2-digits sub master code.
  -Onebeepisemittedtoconrm
   programmingofthesubmastercode.
3. Press B to exit from
the programming mode.
2beepsareemittedtoconrmthatthe
keypad is in stand-by operating mode.
I. Audible Feedback
The audible signal is enabled in programming
mode and when the relay is energised
after a valid code. To enable the audible
feedback on a key press:
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. Press AA.
-One beep is emitted.
  -Press0to disable the audible signal
during a keypress.
  -Press1to enable the audible signal
during a keypress.
  -Onebeepconrmsthenewsetting.
3. Press B to exit from
the programming mode.
2beepsareemittedtoconrmthatthe
keypad is in stand-by operating mode.
J. J. Programming KCIEN/IRC
All the programming is the same as
KCIEN-KCIEN SBP. To activate the
IRC-feature, connect together the
lightblue and purple wires.
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
   2beepsareemittedtoconrmentry
in programming mode.
2. Press AB.
- One beep is emitted.
- Choose IRC-channel by pressing 1 to 7 or 9
to choose all channels.
  -Press0to disable the channel.
  -Press1to enable the channel.
  -Onebeepconrmsthenewsetting.
3. Press B to exit from
the programming mode.
2beepsareemittedtoconrmthatthe
keypad is in stand-by operating mode.
K. Activate IRC-transmitter
 -Pressthetransmitteroncetotransmittthe
code.
 -2beepsareemittedtoconrmthecode.
- Press the transmitter once to activate the
relay output of the keypad.

EN EN
KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
8cdvigroup.com
Enter Master code
twice
Illumination
duration
10-99 sec
00 =
permanent
10 = default
Time relay 1
01-99 sec.
00 = toggled
01 = default
Time relay 2
01-99 sec.
00 = toggled
01 = default
Code length
4’ 5’or 6’ digits
5 = default
Master code
Change
master code
12345 =
default
2 x beeps
1 x beep = OK
4 beeps = ERROR
A0
1 x beep = OK
4 beeps = ERROR
A1
1 x beep = OK
4 beeps = ERROR
A2
1 x beep = OK
4 beeps = ERROR
A4
1 x beep = OK
4 beeps = ERROR
A5
1 x beep = OK
1 x beep = OK
1 x beep = OK
1 x beep = OK
1 x beep = OK

EN EN KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
9cdvigroup.com
2 x beeps
0 = buzzer
disabled
1 = buzzer
enabled
Buzzer (audible
feedback)
Press A then B
Reset
2 digits
AB = default
Sub master
code 1
2 digits
13 = default
Sub master
code 2 User codes
4, 5 or 6 digit code
4 beeps =
user location: “used”
1 beep =
user location: “free”
1 x beep = OK
Press B to exit from
programming
AAA6
1 x beep = OK
4 beeps = ERROR
A7
1 x beep = OK
4 beeps = ERROR
A8
1 x beep = OK
00-99
1 x beep = OK
4 beeps = ERROR
2 x beeps = OK
1 x beep = OK
1 x beep = OK
1 x beep = OK

EN EN
KCIEN - KCIEN SBP - KCIEN IRC
Keypad KCIEN
10 cdvigroup.com
This spread sheet will help you keep track of the user codes programmed in the keypad
Reminder
User
location Code Name
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
User
location Code Name
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
User
location Code Name
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
Relay 1
From user location 00 to 59.
Relay 2
From user location 60 to 99.
