Honeywell MaxLED 26m User manual

GB
MaxLED
Dimensional Drawings:
330mm
230mm
336mm
460mm
427mm
700mm
198mm
52mm
304mm
52mm
395mm
52mm
MaxLED 26m MaxLED 47m MaxLED 65m
Honeywell Life Safety AS, Po. Box 3514, N-3007 Drammen, Norway http://www.hls-nordic.com
Installation:
Step 2: To gain access to the battery, lift the inner plastic cover (on top of the luminaire).
Step 1: To dismantle the luminaire, push the lock/unlock button, slide the luminaire to the left and pull it
down.
Step 4: In case you use a module connect it on the PCB.
Step 5: The control of maintained or non maintained operation of the luminary is achieved through Switch
4 of DS1. For maintained operation, switch number 4 must be in ON position. For non-maintained
operation, switch number 4 must be in OFF position.
Two additional labels are included in the package, one for 3 hours duration (180) and one for 8
hours duration (480). Depending on the selected duration, the installer must remove the default 1
hour (60) label and replace it with one that has the required duration.
The user can select one of the 3 available minimum autonomy durations: 1 hour, 3 hours and 8
hours. The selection must be done while the luminaire is disconnected from AC and battery
supplies. The selection is achieved through Switches 2 & 3 of DS1. Switch 1 is not used.
Step 3: Connect the battery cable to its respective connector on the PCB.
ON
1 2 3 4
Switch 4 = ON
Maintained operation
(default position)
ON
1 2 3 4
Switch 4 = OFF
Non-maintained
operation
1 2 3
5
4
ON
1 2 3 4
ON
1 2 3 4
ON
1 2 3 4
1h
(default position)
3h 8h

GB
Honeywell Life Safety AS, Po. Box 3514, N-3007 Drammen, Norway http://www.hls-nordic.com
Step 2: For double sided pictogram, insert the appropriate pictograms to both sides and refit the profile.
For single sided pictogram, there is one blind pictogram in the package.
Step 1: To insert pictograms, first unscrew the two screws holding the side profile and remove the profile.
The product contains bracket for wall mounting and spacers for ceiling mounting.
Step 2: Pass the mains cables through the cable gland. Always use in any
case round mains cable, with a diameter of 5-10mm (H05RN-F
type 2x1mm² or any other type, at least equal to it's mechanical and
electrical properties). ATTENTION!! The cable must not be
deformed in any way (This requirement is important to ensure the
IP rating). Connect the mains to terminal blocks: L for live wire, N for
neutral and PE for ground. The C1 and C2 terminals are used for
elBus communication (optional) or voltage free contact (optional).
Note: In case of battery replacement, this must be replaced with parts of the same type and characteristics. The
replacement must be performed by the manufacturer or a competent person.
Step 1: Fasten the mounting part (with screws from within) to either wall bracket (supplied), ceiling (with or without
supplied spacers). If mounted close to a wall make sure, that the unlock button is facing outwards.
Note: In case of mains power disconnection for a period of more than two months, the battery must be
disconnected.
Note: If the supply cable of the luminaire is damaged, it shall exclusively be replaced by a competent person in order
to avoid hazard.
Step 4: Slide the luminaire into the socket. The lock/unlock button appears
indicating that the luminaire is securely installed.
Important notice when installing luminaires within the same area!!!
Step 3: Tighten the cable tie around the cables.
To avoid that luminaires perform their battery test at the same day, connect the battery packs with more than
1,5 minutes inbetween.
Pictogram Installation:
Mouting Methods:
PRESS HERE
TO UNLOCK
PRESS HERE
TO UNLOCK
Power
cable Power
cable
Metal Wall Bracket
Spacers
Wall Mounting
Ceiling Mounting
At the end of their useful life the packaging, product and
batteries should be disposed of via a suitable recycling centre.
Do not dispose of with your normal household waste. Do not
burn.

GB
Honeywell Life Safety AS, Po. Box 3514, N-3007 Drammen, Norway http://www.hls-nordic.com
Technical description
Part no.:
Battery (NiMH):
Battery Protection:
Min./Max. Charge Current: 40 / 160mA
Overcharge protection / Deep discharge protection
o
5 to 40 C
Up to 95%
16 hours
Produced in accordance with:
Ambient Temperature Range:
Maximum Power Consumption:
Operation Voltage:
Relative Humidity:
Charging Time:
Technical lifetime (light source):
Lumen output, normal:
> 100000 hours
280lm 550lm 900lm
MaxLED 26m MaxLED 65mMaxLED 47m
4.2W / 4.4VA 7.2W / 7.6VA 9.8W / 10.2VA
220-240V AC, 50-60 Hz
138254 138255138009
3.6V / 1.2Ah 4.8V / 1.2Ah
IP40
1h / 3h / 8h manually selected (default 1h)
Degress of cover protection:
Emergency Mode Duration:
EN 60598-1, EN 60598-2-22, EN 55015
EN 61547, EN 61000-3-2, EN 61000-3-3
Charge Voltage Range: 4 - 6V
Lumen output, emergency (1h/3h/8h): 280/110/40lm 425/170/60lm 425/170/60lm
Weight:
Expected Battery Lifetime:
Controlgear classification in accordance with IEC 62034: with automatic test function
1068 gr 1591 gr 2355 gr
4 years
It can be configured as maintained or non-maintained.
Every 15 days the luminaire will perform an emergency
operation test. This will light the exit sign for approximately 3
seconds. The red indicator LED will flash during this test
sequence.
Note: When using DALI or Wireless communication, the
frequencies and schedules for tests will instead be determined
by the connected PC software.
Every 6 months the luminaire will perform a battery condition
test. The test will last for the stated duration. The exit sign will be
lit and the yellow indicator LED will flash during this test
sequence.
Selftest functions
The MaxLED is a self-contained LED exit sign with selftest
function.
Indicator LEDs
LED Status explanation
Description
GREEN
YELLOW
RED
Normal
Charging (battery test not possible while charging
Mains off, battery not connected or charger fault
Battery fault
Battery test
Light source test
Light source fault
Battery fault and light source fault
Off On Flashing
Manual test functions
Manual tests can only be performed if both mains and battery are connected.
By pressing the test button briefly (less than 5 seconds) an emergency operation test is performed. The exit sign will be lit
for approximately 3 seconds, the red indicator LED will flash during this test sequence.
By pressing the test button for a time space between 5 and 10 seconds, a battery condition test is performed. This test will
last for the stated duration and can only be performed when the battery is fully charged (steady green indicator LED). The
exit sign will be lit and the yellow indicator LED will flash during this test sequence.
Resetting errors
Push the test button for a time space between 10 and 15 seconds to delete all indicated errors. Then the luminaire enters
regular operation mode.
