JSI Flux User manual

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 1 of 10
Adjustable U-Unit Assembly
Recommended Tools
Hardware Used
#2 Phillips Head Bit
#2 Phillips Screw Driver
Screw Gun
Tape Measure
Level
Hex Wrench
#8 x 3/4”Flat Head Wood Screws#8 x 1 1/4”Flat Head Wood Screws
#8 x 1 1/2”Flat Head Wood Screws
Package Contents
Bridge Top
Assembly
End Panel
Lateral File
Credenza
Desk Top
Assembly
Fixed Modesty
Panel
Optional Modesty
Panel
End Panel

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 2 of 10
Adjustable U-Unit Assembly
(continued)
Step 1
Position and Level all Units
• Position adjustable desk panel base and adjustable
return panel base in desired location. The length of
desk will determine the spacing of the two bases.
• Level all units front-to-back and side-to-side
by rotating adjustable glides.
• Units that share same worksurface are to
be adjusted to same height. (Dim. “A”)
Modesty Panel
Desk Base
TOP VIEW
Return Base
Length of
Modesty Panel
Length of
Modesty Panel
“A”
“A” Desk Base
Return Base

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 3 of 10
Adjustable U-Unit Assembly
(continued)
Step 2
Attach Fixed Modesty Panel
Position and Level all Units
• Position adjustable desk panel base
and adjustable return panel base in desired
location. The length of desk will determine
the spacing of the two bases.
• Check that unit is level
front to back and side to side;
adjusting leveling guides according
• Align all four
fastening brackets
• Engage interlocking bracket
componets and lower panel
for tight secure fit

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 4 of 10
Adjustable U-Unit Assembly
(continued)
Step 3
Attach Worksurfaces
• Carefully lower Desk
Top Assembly
into place
Fasten understucture to adjustment columns
using eight (8) #6 X 12mm socket head bolts,
four (4) per side.
Note: Hand tighten only. Do NOT secure
firmly at this point.
Fasten understucture to adjustment column using
four (4) #6 X 12mm socket head bolts.
Note: Hand tighten only. Do NOT secure firmly at
this point.
• Carefully lower Bridge Top
Assembly into place
• Flip bridge upsidedown and lay on a flat smooth
surface. Fasten flat brackets to underside of
bridge using four (4) #8 X 7/8”flat head
screws per bracket.

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 5 of 10
Adjustable U-Unit Assembly
(continued)
Step 4
Connect Electrical Wiring
• Carefully lower Desk
Top Assembly into place
TOP VIEW
Dongle
To height control switch
Spin height control
switch into place
To any of the three
adjustable columns
To Power
Outlet
To any of the
adjustable columns
To any of the
adjustable columns
Plug power cord into
nearest power outlet
Column 2
Column 1
Column 3

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 6 of 10
Adjustable U-Unit Assembly
(continued)
Step 5
Secure Worksurfaces To
Adjustable Height Columns
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Raise worksurface for easier
access to understructure
Using hex wrench, tighten all machine
bolts firmly to the three columns

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 7 of 10
Adjustable U-Unit Assembly
(continued)
Step 6
Fasten Bridge To
Main Worksurface
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
• Push worksurfaces together so
all surfaces and edges are tight
and flush to one another
• While worksurfaces are being held
firmly together, fasten brackets to under
side to adjustment column using four
(4) #8 X 7/8”flat head screws per bracket.
Leave 1/8”gap between
front panels and modesty
panel. Using a 1/8” spacer
is recommended.
Step 7
Attach Modesty Panel
(Optional) • Fasten Modesty Panel to
Worksurface using #8 X 7/8”
flat head screws

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 8 of 10
Adjustable U-Unit Assembly
(continued)
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Step 8
Attach Wire Manager
(Optional)
2 1/4”
approx.
Fasten flat bracket
to inside of unit.
3 1/2”
approx.4”
2 1/4”
Attach wire manager
to underside of surface
and route wire accordingly
Fasten wire manager to
bottom of worksurface
Attach wire manager
to underside of surface
and route wire accordingly

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 9 of 10
Adjustable U-Unit Assembly
(continued)
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Step 9
Route Power Cord
Through Wire Manager
Route power cord
through wire manager
Attach magnet on
wire manager to
the flat bracket
Replace door and
lower worksurface
to desired height.

Installation Instructions
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL001
5/7/18
Page 10 of 10
Adjustable U-Unit Assembly
(continued)
Step 10
Attach Credenza
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Fasten credenza to unit using
L-brackets and #8 x 5/8”flat
head screws
Adjust height of unit to be flushLevel unit front-to-back
and side-to-side
by rota ting adjustable glides.
