JSI Vision-Wall Mounted Floating Shelf User manual

8/26/2022 Form No. INST-VS0015
Vision-Wall Mounted Floang Shelf
Recommended Tools
Installaon
1. Determine locaon & mounng height of the shelf. Figure A
2. Bore holes for mounng concealed bracket. Figure B
3. Using Ø1/4” bit, bore holes for drywall anchors. Figures B & C
4. Using a level, assure bored holes are horizontal.
5. Insert Drywall Anchors into bored holes. Figure C
6. Aach Concealed Brackets to Drywall Anchors using provided
screws. Figure D
Figure A Figure B
Figure C Figure D

8/26/2022 Form No. INST-VS0015
INST-VS00__
Install Instrucons
Recommended Tools
Installaon
7. Insert shelf onto concealed mounng brackets leaving room for
adjustments. Figure E
8. Adjust Horizontally unl centered. Figure F
9. Using wrench, turn concealed pin to adjust for lt. Figure G
10. When adjustments are complete, ghten locking screw on
boom side of concealed bracket to retain sengs. Figure H
11. Slide shelf against the wall, lock in place with grub screw. Fig. J
Figure E
Figure F
Figure H
Figure G
Figure J
