2 DynamicArm 12K100N

1 Foreword English
INFORMATION
Date of last update: 2019-10-15
►Please read this document carefully before using the product.
►Instruct the user in the proper and safe use of the product.
►Report all serious incidents that have occurred in connection with the product, both to the manufacturer (see
rear cover for contact information) and to the relevant authority in your country.
►Please contact the manufacturer if you have questions about the product (e.g.regarding the start-up, use,
maintenance, unexpected operating behaviour or circumstances). Contact information can be found on the
back page.
►Please keep this document in a safe place.
The product “12K100N=* DynamicArm” is referred to simply as the product/elbow joint below.
These instructions for use provide you with important information on the use, adaptation and handling of the
product.
Only put the product into use in accordance with the information contained in the accompanying documents sup
plied.
The product may not be transferred to the patient without prior instruction.
2 Product description
2.1 Design
1. Easy Plug
2. ON switch
3. Strap clamp
4. Charging receptacle
5. Pull cable (mechanical release)
6. AFB dial
7. Humeral rotation feature adjusting screw
2.2 Function
The product is a myoelectrically controlled elbow joint driven by an electric motor. It helps the wearer perform
everyday tasks in combination with other prosthetic components (see Page5).
A Li-Ion battery integrated into the product provides the energy required. The “646C42=V* ElbowSoft” software is
used for the patient-specific adjustment of the product.
If the elbow joint is off or the battery is depleted, the elbow joint can still be locked and unlocked in any position,
even when loaded, by means of the pull cable.
In new condition, the product can lift a load of up to 5kg. Once this load is exceeded, the joint will be locked. Flex
ion and extension are only possible again after the load is reduced.
2.2.1 Definition of terms
AFB (Automatic Forearm Balance)
AFB is a flexion assist in the form of a mechanical gear mechanism in the forearm of the elbow joint. The Automatic
Forearm Balance provides for harmonious movement control, free swing and reduction of energy consumption. It
stores the energy that is released when the arm is extended and uses this to assist with flexion. The degree of flex
ion assistance can be adjusted to the individual weight of the prosthetic forearm and to different clothing by means
of a dial.
The free swing of the forearm corresponds to the natural movement behaviour of the upper limb while walking.
After extension of the forearm, the vario-gear automatically decouples the forearm from the drive unit so it can
3DynamicArm 12K100N
Foreword

swing freely. The AFB slightly dampens the free swing, thereby making a close approximation of the forearm’s
physiological movement behaviour possible.
The product does not consume electrical energy during the free swing. A short muscle signal to flex the product
ends the free swing.
Humeral rotation feature
The humeral rotation feature is an upper arm rotation joint with bilateral stops. It is used for rotation of the forearm.
The resistance of the humeral rotation feature can be changed using the adjusting screw.
Easy Plug
1. No function
2. Electrode
3. Electrode
4. Optional switch
The Easy Plug feature makes it simple to wire myoelectric prostheses.
The connecting cables of the electrodes and an optional switch are connected to the Easy Plug. Its interior cable
routing minimises the risk of cable breaks.
Forearm cable
The forearm cable establishes the electrical connection between the product,
electric wrist rotator and System Electric Hand or System Electric Greifer.
On delivery the forearm cable is rolled up in the forearm of the elbow joint. After
the forearm has been cut to its final length, the forearm cable can be pulled out.
INFORMATION
Do not pull out cables before cutting the forearm to length.
Lock
Releasing and locking the elbow joint is automated according to operating situations, the applied load and the con
trol signal generated by the patient by means of the electronically controlled locking drive.
The product has a load capacity of up to 230N in the locked state with a forearm lever length of 305mm. The lock
will slip under higher loads.
Mechanical release
With the product switched off or when the battery is drained, the elbow can be manually unlocked and locked
again with a slight pull on the unlock cable. In this way, the forearm can be brought into the desired position.
Mechanical release can also take place under load.
4
Product description
DynamicArm 12K100N

On/off switch
Press the on/off switch to operate it (arrow).
A signal sounds and the product briefly vibrates once when it is turned on. It is
recommended for the patient to turn the product off during longer passive
breaks. This increases the period of use before charging the battery.
2.3 Combination possibilities
• 10S17 electric wrist rotator
• 13E200=* electrode
• 13E202=* suction socket electrode
• 13E219=* Control electronics
• bebionic hand EQD: 8E70=*
• bebionic hand Short Wrist: 8E71=*
• bebionic hand Flex: 8E72=*
• 8E33=9* DMC VariPlus System Electric Greifer
• 8E38=8, 8E39=8 Sensor Hand Speed
• MyoHand VariPlus Speed: 8E38=9, 8E39=9,
8E41=9
• Pressure switch: 9X37
• Linear control element: 9X50
• 9X51 4-stage control element
• Linear control element: 9X52
• 9X53 4-stage control element
3 Application
3.1 Intended use
The product is to be used exclusively for exoprosthetic fittings of the upper limbs and serves as an anatomical
replacement for the elbow joint and forearm.
3.2 Conditions of use
The product is suitable for patients with unilateral or bilateral upper arm amputations.
The product is intended exclusively for use on adults.
The product was developed for everyday use and must not be used for unusual activities. These unusual activities
include, for example, sports which involve excessive strain and/or shocks to the wrist joint (pushups, downhill
racing, mountain biking, ...) or extreme sports (free climbing, paragliding, etc.).
The product is intended exclusively for the fitting of a patient. Use of the product by a further person is prohibited
by the manufacturer.
3.3 Qualification
The fitting of a patient with the product may only be carried out by O&P professionals who have been authorised
with the corresponding Ottobock training.
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
5DynamicArm 12K100N
Application

4.2 Structure of the safety instructions
WARNING
The heading describes the source and/or the type of hazard
The introduction describes the consequences in case of failure to observe the safety instructions. Consequences
are presented as follows if more than one consequence is possible:
> E.g.: Consequence 1 in the event of failure to observe the hazard
> E.g.: Consequence 2 in the event of failure to observe the hazard
►This symbol identifies activities/actions that must be observed/carried out in order to avert the hazard.
4.3 General safety instructions
WARNING
Non-observance of safety notices
Personal injury/damage to the product due to using the product in certain situations.
►Observe the safety notices and the stated precautions in this accompanying document.
WARNING
Operating the product near active implanted systems
Interference with active implantable systems (e.g., pacemaker, defibrillator, etc.) due to electromagnetic interfer
ence of the product.
►When operating the product in the immediate vicinity of active implantable systems, ensure that the minimum
distances stipulated by the manufacturer of the implant are observed.
►Make sure to observe any operating conditions and safety instructions stipulated by the manufacturer of the
implant.
WARNING
Use of the product while operating a vehicle or machinery
> Risk of accident due to unexpected behaviour of the product.
> Risk of injury due to faulty control or malfunction of the product.
►Applicable national legal regulations must be complied with when operating vehicles of any kind or when
operating machinery with the product.
►Have your driving ability examined and verified by an authorised test centre.
►Switch off the product before driving.
WARNING
Charging the prosthesis without taking it off
Risk of electric shock due to defects in the power supply unit or in the battery charger.
►For safety reasons, remove the prosthesis prior to charging it.
CAUTION
Overloading due to unusual activities
Injury due to unexpected product behaviour as a result of a malfunction.
►The product was developed for everyday use and must not be used for unusual activities. These unusual activ
ities include, for example, sports with excessive strain and/or shocks to the wrist joint (pushups, downhill
mountain biking, ...) or extreme sports (free climbing, paragliding, etc.).
►Careful handling of the product and its components not only increases their service life but, above all, ensures
the patient's personal safety!
►If the product and its components have been subjected to extreme loads (e.g. due to a fall, etc.), then the
product must be inspected for damage immediately. If necessary, forward the product to an authorised
Ottobock Service Centre.
6
Safety
DynamicArm 12K100N

CAUTION
Overheating of drive unit due to continuous activity
Injury due to touching the overheated drive unit.
►Avoid touching the housing of the drive unit in case of overheating.
CAUTION
Independent user manipulation of system components
Injury due to faulty control or malfunction of the product.
►Manipulations to the product other than the tasks described in these instructions for use are not permitted.
►The battery may only be handled by Ottobock authorised, qualified personnel (no replacement by the user).
►The product and any damaged components may only be opened and repaired by authorised, qualified
Ottobock personnel.
CAUTION
Independent manipulation of the product
Injury due to product damage or malfunction.
►Manipulations to the product other than the tasks described in these instructions for use are not permitted.
►The product and any damaged components may only be opened and repaired by authorised, qualified
Ottobock personnel.
CAUTION
Use of unsuitable prosthetic components
Injury due to unexpected product behaviour.
►Use the product only in combination with components listed in the section "Combination Possibilities" (see
Page5).
CAUTION
Improper use
Injury due to loss of product functionality.
►Instruct the patient in the proper use of the product.
CAUTION
Manual unlocking of elbow lock under load
Injury by release of elbow lock under load.
►Particular caution should be exercised when unlocking the elbow lock while lifting heavy loads.
►Be careful when unlocking the lock under such conditions due to the possibility of injury.
CAUTION
Proximity to sources of strong magnetic or electrical interference (e.g. theft prevention systems, metal
detectors)
Injury due to unexpected behaviour of the product caused by interference with internal data communication.
►Avoid remaining in the vicinity of visible or concealed theft prevention systems at the entrance/exit of stores,
metal detectors/body scanners for persons (e.g. in airports) or other sources of strong magnetic and electric
al interference (e.g. high-voltage lines, transmitters, transformer stations, computer tomographs, magnetic
resonance tomographs, etc.).
►When walking through theft prevention systems, body scanners or metal detectors, watch for unexpected
behaviour of the product.
CAUTION
Mechanical stress on the prosthesis
Injury due to faulty control or malfunction of the prosthesis.
►Do not subject the prosthesis to mechanical vibrations or impacts.
►Check the prosthesis for visible damage before each use.
7DynamicArm 12K100N
Safety

CAUTION
Penetration of dirt and humidity into the product
Risk of injury due to unexpected product behaviour or malfunction.
►Ensure that neither solid particles nor liquids can penetrate into the product.
►Do not expose the product, and especially the elbow joint, to dripping or splashing water.
►Wear the product, and especially the elbow joint, under suitably resistant clothing in the rain.
CAUTION
Changing prosthetic components when switched on
Injury due to faulty control or malfunction of the prosthetic components.
►Before changing prosthetic components (e.g. terminal device) switch the product off.
CAUTION
Signs of wear and tear on the product components
Injury due to faulty control or malfunction of the product
►In the interest of patient safety and in order to maintain operating reliability and protect the warranty, the spe
cified service intervals must be observed (see the section "Maintenance").
CAUTION
Injury due to incorrect adjustment of the product.
Loosening of the components.
►In case of a product with a quick-disconnect wrist, position the terminal device before use so that a slight turn
cannot disconnect the terminal device from the prosthesis.
CAUTION
Incorrect donning and doffing of the product
Injuries
►The product should always be flexed for donning and doffing as well as storage.
►Switch off the product before donning or doffing.
CAUTION
Unintentional unlocking of the terminal device
Risk of injury due to releasing the terminal device from the forearm (e.g. while carrying objects).
►When using a quick-disconnect wrist unit, position the terminal device so that slight twisting does not release
the terminal device from the forearm.
CAUTION
Charging the product with damaged power supply unit/charger/charger cable
Injury due to unexpected behaviour of the product caused by insufficient charging.
►Check the power supply unit, charger and charger cable for damage before use.
►Replace any damaged power supply unit, charger or charger cable.
CAUTION
Risk of pinching in the joint flexion area
Injuries due to pinching of body parts.
►Ensure that fingers and other body parts are not in this area when bending the joint.
NOTICE
Coating, gluing or painting the prosthesis
Damage or fracture due to chemical processes.
►The prosthesis must not be coated, glued or painted.
8
Safety
DynamicArm 12K100N

NOTICE
Improper product care
Damage to the product due to the use of incorrect cleaning agents.
►Only clean the product with a damp cloth and mild soap (e.g. 453H10=1-N Ottobock DermaClean).
INFORMATION
► The electrodes are to be placed on intact skin only and with as much electrode-skin contact as possible.
► In case of strong interference from electronic devices, the position of the electrodes should be checked and
changed if necessary.
► If interference cannot be eliminated, please contact the Ottobock branch responsible for your country.
► Allow the patient to rest during the adjustment of the electrodes. Muscle fatigue leads to inconsistent results,
and therefore the therapist will tend to establish electrode settings that are excessively sensitive.
5 Scope of Delivery and Accessories
• 1pc. 12K100N=* DynamicArm
• 1pc. cable lock
• 1pc. cable guide
• 4pcs. oval head self-tapping screw
• 1 pc. electric wrist rotator dummy
• 1pc. 757L24 battery charger with EU and US plug
• 1pc. 10S1=40 lamination ring
• 1pc. hook
• 1pc. Lamination protection cover (hollow ball)
• 1pc. Lamination protection cover (disc with arrow)
• 1pc. O-ring
• 1pc. clamp ring
• 4 pcs. mounting brackets
• 1pc. foam cover
• 1pc. 647G152 instructions for use (qualified per
sonnel)
• 1pc. 646D229 instructions for use (user)
• 1pc. 646T333 instructions for use (qualified per
sonnel)
• 1 pc. 646D644 service pass
Accessories
• 1pc. strap clamp for UNI
• 2pcs. 2.2x6.5 sheet metal cap screw
• 1 pc. EURO power cord
• 1 pc. USA power cord
6 Preparation for use
6.1 Shortening the forearm
INFORMATION
Wrap the elbow area with plastic wrap to prevent swarf from entering it during cutting.
6.1.1 Forearm length and intended use of the 10S17 electric wrist rotator
INFORMATION
Please note that the minimum forearm length is 213mm when using an electric wrist rotator and 187mm without
an electric wrist rotator.
The forearm length is measured from the distal end of the lamination ring to the middle of the elbow axle.
DynamicArm forearm length 10S17 Electric wrist rotator
305–213mm possible
212–187mm not possible
6.1.2 Cutting to length
NOTICE
Do not pull the foam or cable protector cap out of the forearm under any circumstances before the forearm is cut
to length and before the lamination ring is glued in! Doing so will reduce the useable portion of the forearm!
If the cables were pulled out anyway, they have to be pushed back into the forearm and secured with the foam disc
before performing further work. The cables take up more space in the forearm as a result.
9DynamicArm 12K100N
Scope of Delivery and Accessories

1) Mark the length to be cut from the forearm. Apply
measurement X plus 1cm. Reason: The prosthesis
should be approx. 1cm shorter than the sound arm.
2) Cut the forearm using a vibrating saw.
3) Sand all sides of the cut edge at a right angle.
Smooth inner and outer sanded edges. Round the
inside edge slightly.
4) Using the hook, remove the foam cover.
10
Preparation for use
DynamicArm 12K100N

6.2 Gluing in the lamination ring with quick-disconnect wrist unit
1. Lamination cover
2. Lamination ring
3. Socket head screw
4. Dummy for electric wrist rotator
The lamination ring with quick-disconnect wrist unit has to be glued in after the forearm has been cut to length.
Before starting to glue it in, please read these instructions very carefully and proceed exactly in the order
described.
INFORMATION
Read the relevant material safety data sheets before processing the 636K18 Orthocryl sealing resin compact
adhesive and the 617H14 hardener paste.
1) Determine the height of the lamination ring.
2) Mark this measurement on the inside of the fore
arm.
3) Mix 636K18=1 Orthocryl sealing resin compact
adhesive and 2% 617H14 hardener paste.
4) Cover the outside of the forearm with 627B4 poly
ethylene adhesive tape to avoid soiling it while glu
ing.
11DynamicArm 12K100N
Preparation for use

5) Using a paintbrush, apply the resin in a wedge
shape to the marked area of the inside forearm and
the outside of the lamination ring.
6) Insert the lamination ring and lamination ring cover.
The lamination ring must be flush with the socket!
Let the adhesive joint harden.
INFORMATION: Measure the forearm length.
For forearm lengths from 225mm to 213mm with 10S17 electric wrist rotator
►Make sure the 10S17 electric wrist rotator dummy
is pushed over the cable protector cap. This
ensures correct axial alignment of the lamination
ring.
For forearm lengths from 225mm to 187mm without 10S17 electric wrist rotator
1) Pull the 10S17 electric wrist rotator dummy back
and out of the lamination ring. The lamination ring
cover has to remain in the lamination ring.
12
Preparation for use
DynamicArm 12K100N

2) Pull out the 10S17 electric wrist rotator dummy with
the lamination ring cover by the socket head screw.
3) Or, pull out the lamination ring cover on its own.
4) Remove the cable protector cap using the hook.
5) The cables are rolled up inside the cable protector
cap. When removing the cable protector cap, the
cables are pulled out of the forearm.
13DynamicArm 12K100N
Preparation for use

INFORMATION
Cables pulled out before cutting to length
If the cables were pulled out before the forearm has been cut to length and the lamination ring has not been glued
in yet (for example after a trial fitting), the cables have to be pushed back into the forearm and secured with the
foam disc before performing further work on the forearm.
As a result, the cables take up more space in the forearm compared to the delivery condition from the factory. The
usable length of the forearm will be reduced.
Then the forearm can only be shortened to the following lengths:
• To a minimum of 230mm when using the 10S17 electric wrist rotator.
• To a minimum of 207mm when not using the 10S17 electric wrist rotator.
Proceed as described above to cut to length and glue in the lamination ring
INFORMATION
If the foam disc has been glued into place, the cables can be pulled out carefully through the slotted foam disc
using the hook.
6.3 Checking the symmetry
1) Connect prosthetic components to the forearm.
2) Check the symmetry using the 743L20=230 Ottobock LaserLine.
6.4 Sealing the prosthesis
Consult the enclosed technical information for the fabrication of the patient’s socket and cutting the forearm socket
to length.
1) After laminating the lamination ring, remove the
grease and any dirt.
2) Lubricate the groove, inner edges and thread of the
lamination ring with 633F30 special grease.
6.5 Plugging in the contact
1) Apply a generous amount of 633F11 silicone
grease to the connector contacts of the 13E219
control electronics.
14
Preparation for use
DynamicArm 12K100N

2) Connect the cables.
3) Thoroughly seal the plug and blanking covers from
above with 633F11 silicone grease.
6.6 Assembling the housing
1) Slide the electrode housing with the connected
cables into the greased lamination ring. It has to
engage completely!
2) The circuit board and the edge of the lamination
ring must be parallel to each other.
3) The electrode housing has engaged properly. The
circuit board and the edge of the lamination ring are
parallel to each other.
15DynamicArm 12K100N
Preparation for use

6.7 Installing the elbow joint
1) Do not remove the two joint covers!
2) Screw the elbow joint into the upper arm socket.
Make sure the friction adjustment screw and lamin
ation ring thread recess are applied opposite to
each other.
3) Set the AFB dial to minimum compensation force.
4) Extend the elbow and lock it with the pull cable.
Switch off the product.
5) Remove the Allen head screw.
16
Preparation for use
DynamicArm 12K100N

6) Lift and remove the red assembly clamp.
7) The lifter strap must not be removed from the elbow
ball. Fixing the lifter strap in place (e.g. with a hae
mostat) is no longer necessary.
8) Slide the strap clamp under the lamination ring.
9) Install the Allen head screw.
6.8 The pull cable
1) Bring the forearm into neutral position (no outward
or inward rotation).
2) Affix the cable guide to the socket with cap screws
(centred in relation to the strap clamp and approx.
30mm away from the lamination ring).
CAUTION! The pull cable is to be used for
emergency operation only. For safety reasons,
it must not be removed!
3) Rotate the socket in and out up to the stop. Ensure
that the pull cable does not tighten.
Complete the following additional steps to finish the switch cable:
17DynamicArm 12K100N
Preparation for use

1) Thread the switch cable through the cable lock.
2) Secure the end of the switch cable with a button.
3) Tighten the switch cable and make a loop.
6.9 Adjusting the product
1) The level of compensation (flexion assistance) can
be adjusted and adapted to the weight of different
clothing with the AFB dial. Adjustments are easier
to make when the forearm is not flexed.
2) The adjustment mechanism is protected by a slip
coupling.
3) Hydrodynamic damping of the AFB mechanism is
designed to counterbalance the weight of the fore
arm and terminal device. Therefore hold the upper
arm section of the prosthesis while testing the joint
function.
4) Position 1
Low compensation that allows natural free swing of
the arm while walking.
Position 2
Compensation increases progressively with flexion
of the arm and decreases automatically during
extension.
Position 3
Compensation remains constant. If set correctly,
the weight of the forearm is balanced by the com
pensation and the forearm “floats”.
Position 4
Low compensation until flexion stop.
6.10 Adjusting the humeral rotation feature
►The upper arm rotation joint has bilateral stops (±
80 degrees) to block extreme movements. The fric
tion of the humeral rotation feature at the upper arm
connection is easily adjusted by turning the external
adjustment screw.
18
Preparation for use
DynamicArm 12K100N

6.11 Wiring the product with the electric wrist rotator
1) The MyoRotronic cannot be combined with the
elbow joint. The MyoRotronic would be destroyed
when operating the elbow joint.
2) There are numbers for the plug contacts on the
plastic housing of the electric wrist rotator. These
numbers serve as orientation for connecting the
cables.
3) Attach the motor cable to one of the two contacts.
Connect two-pole receptacle to contact no. 3.
4) Connect three-pole receptacle to contact no. 2.
One of the three-pole connectors is marked with a
coloured dot.
5) If the two three-pole connectors are interchanged
when connecting them to the two contacts, no func
tion of the System Electric Hand or System Electric
Greifer is possible.
6) To secure the coaxial plug, insert the retaining ring
into the groove of the lamination ring using tweez
ers.
7) Then install the electric wrist rotator in the lamina
tion ring.
6.12 Wiring without electric wrist rotator
1) One of the two three-pole connectors is marked
with a coloured dot (arrow). The two receptacles
must not be interchanged!
INFORMATION: The two-pole motor cable must
not be attached to the coaxial plug.
19DynamicArm 12K100N
Preparation for use

2) Install the plastic screw to secure the two connect
ors.
3) Push the coaxial plug in to the stop and rotate it
until the stop noticeably engages.
4) Install the coaxial plug in the lamination ring.
7 Handling
7.1 Charging the battery
The product is powered by an integrated high-quality Li-Ion battery with sufficient capacity to operate for one full
day of usual everyday activities. Turning the product off during longer periods of passive use (e.g. air or rail travel,
visit to a theatre or cinema, etc.) will make the battery last longer. We recommend charging the product once a day
when used by the patient on a daily basis. Electronic battery management provides the patient with information
about the battery charge level (battery management).
The charging unit consists of the charging plug and the power cord. The battery charger has an input voltage
range of 100–240V and may be operated in a mains frequency range of 50–60Hz.
INFORMATION
Please note the corresponding instructions for use of the battery charger.
7.1.1 Charging process
WARNING
Charging the prosthesis without taking it off
Risk of electric shock due to defects in the power supply unit or in the battery charger.
►For safety reasons, remove the prosthesis prior to charging it.
1. Extend and switch off the product.
2. Lock the product with the pull cable.
3. Take off the elbow joint.
4. Connect the power cord to the battery charger.
5. Insert the charging plug into the charging recept
acle (see figure).
Do not force it in!
6. Plug the power cord into a wall socket. If the LED
shows an orange light, the battery is charging.
If the LED shows a green light but the battery is
drained, the charging plug was not inserted cor
rectly.
7. If the LED shows a green light after charging, this
indicates that the battery is fully charged.
8. Disconnect the power cord of the battery charger
from the wall socket.
7.1.2 Charging times
Charging time Capacity Operating time
3 hours 100% approx. 18 hours
1.5 hours 80% approx. 14 hours
20
Handling
DynamicArm 12K100N
