Teknik 5427427 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS
IMPORTANT SAFETY
INFORMATION.
PLEASE READ AND KEEP
FOR FUTURE REFERENCE.
English pg 1-12
Français pg 13-14
Español pg 15-16
09/22/21 Lot # 566806
Purchased:
__________________
1800x750 Desk
Hudson Elm finish | Model 5427427
Teknik
www.teknikoffice.co.uk

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Page 2
åYou may receive extra hardware with your unit.
LEVELER - 4
46E WOOD DOWEL - 11 42F TOUCH-UP PEN - 1
10M
HOLE PLUG - 8
98P
CORD CLIP - 2
9P
GROMMET - 2
2P GROMMET CAP- 2 3P
Hardware Identification
TWIST-LOCK®
FASTENER COVER - 17
105P
Hardware Identification
Part Identification
Optional Accessories
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
2
3
4
5
4-12
13-14
15-16
17-18
19

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D MODESTY PANEL (1)
A
B
C
D
Page 3

Page 4
Optional Accessories (sold separately)
å This piece of furniture accommodates one or more of the following optional accessories (sold separately).
å Powered Grommet (Item 427829)
å Articulating Keyboard Shelf (Item 426468)
The Articulating Keyboard Shelf is designed to be fastened to the underside of your desk, desk return, or credenza top.
å LED Light (Item 426494)
The LED Light is designed to be fastened to the underside of a hutch.

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Using your hammer, gently tap two LEVELERS (46E)
completely into the holes in the LEFT END (B).
å NOTE: Adjustments to the LEVELERS will be made later in
assembly once your unit is standing upright.
46E
B
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
2.
Push a TWIST-LOCK® FASTENER
into the large hole in the part.
1.
HOW TO USE A TWIST-LOCK®FASTENER
Hardware Usage Guide
Page 5

Step 2
å Insert two WOOD DOWELS (42F) into the exact holes
shown in the LEFT END (B).
å NOTE: You may need to gently tap the WOOD DOWELS
in with your hammer.
å Fasten the LEFT END (B) to the MODESTY PANEL (D).
Tighten three TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the LEFT END
insert into the MODESTY PANEL.
42F
B
D
For support, place packing
foam and magazines here.
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Page 6
Edge with TWIST-LOCK® FASTENERS

Step 3
A
46E
å Using your hammer, gently tap the remaining
LEVELERS (46E) completely into the holes in the
RIGHT END (A).
å NOTE: Adjustments to the LEVELERS will be made later in
assembly once your unit is standing upright.
Page 7

Step 4
å Insert two WOOD DOWELS (42F) into the exact holes
shown in the RIGHT END (A).
å NOTE: You may need to gently tap the WOOD DOWEL in
with your hammer.
å Fasten the RIGHT END (A) to the MODESTY PANEL (D).
Tighten three TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the RIGHT END
insert into the MODESTY PANEL.
A
D
Surface without
TWIST-LOCK®
FASTENERS
Page 8
42F

Step 5
C
å Insert seven WOOD DOWELS (42F) into the exact holes
shown in the TOP (C).
å NOTE: You may need to gently tap the WOOD DOWELS
in with your hammer.
å Push two CORD CLIPS (9P) into the TOP (C).
42F
42F
9P
Page 9
Pilot hole to be used
only if you purchased
the optional
426468 Articulating
Keyboard Shelf.

å Fasten the TOP (C) to the ENDS (A and B) and MODESTY
PANEL (D). Tighten eleven TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the TOP insert
into the ENDS and MODESTY PANEL.
Step 6
A
B
D
C
Page 10

Step 7
427427
427427 427413
427413
å The 427427 Desk may be placed in a variety of
configurations with other units as shown in the
diagrams below.
Page 11
427410 427411
427410 427411

Step 8
3P
2P
10M
98P
98P
To raise a corner of your
unit, rotate the LEVELER
downward. To lower a
corner of your unit, rotate
the LEVELER upward.
å Your unit may need leveling. To raise a corner of your unit, rotate the LEVELER downward. To lower a corner of your unit,
rotate the LEVELER upward.
å For long-term care and maintenance of your unit, you may touch up the edges with the TOUCH-UP PEN (10M).
å Insert a HOLE PLUG (98P) into any unused hole in the ENDS (A and B).
å Insert a GROMMET (2P) and GROMMET CAP (3P) into each large hole in the TOP (C).
å Using your hammer, gently tap a TWIST-LOCK® FASTENER COVER (105P) onto each visible TWIST-LOCK® FASTENER.
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
C
A
B
Page 12
60 lbs.
105P
105P
