Teknik Hudson 5425815 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
For things and such.
Hudson Wall Mounted Night Stand
Model 5425815
Teknik
www.teknikoffice.co.uk

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5-17
18-19
20-21
22
23
Electric drill with 3/32"
and 7/16" bit
(ONLY in indicated step)
Pencil
Tape Measure
Level
Page 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A LEFT END (1)
B RIGHT END (1)
C TOP (1)
D BOTTOM (1)
E SMALL BACK (1)
F SHELF (1)
G MOLDING (1)
H LARGE BACK (1)
A
B
C
D
E
F
G
H
Page 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
CAM SCREW - 12
2WOOD DOWEL - 24 3
WALL ANCHOR - 1
6
BLACK APPLIQUE
CARD - 1
4NAIL - 12
7
Page 4
HIDDEN CAM - 12
1
82-7/16" FLAT HEAD SCREW - 2
WHITE APPLIQUE
CARD - 1
5

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden CamHidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Page 5

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Turn twelve CAM SCREWS (2) into the ENDS (A and B),
TOP (C), BOTTOM (D), and MOLDING (G).
A
B
CD
G
Page 6
Remember:
Righty tighty.
Lefty loosey.
(12 used)
2
2

Arrow
Step 2
å Push twelve HIDDEN CAMS (1) into the ENDS (A and B)
and SHELF (F).
1
Arrow
1
A
B
F
Page 7
(12 used)
Arrow
1

å Insert two WOOD DOWELS (3) into the MOLDING (G).
å Fasten the MOLDING (G) to the SHELF (F). Tighten two
HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the MOLDING
insert into the SHELF.
Step 3
Surface with
HIDDEN CAMS
G
F
3
Page 8

å Insert two WOOD DOWELS (3) into the RIGHT END (B).
å Fasten the SHELF (F) to the RIGHT END (B). Tighten the
HIDDEN CAM.
å NOTE: Be sure the WOOD DOWELS in the RIGHT END
insert into the SHELF.
Step 4
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
F
B
3
Page 9
This notch
must be here.
This notch
must be here.

å Insert four WOOD DOWELS (3) into the RIGHT END (B).
å Push the SMALL BACK (E) onto the WOOD DOWELS in
the RIGHT END (B).
Step 5
These holes will
be smaller than
the holes on the
opposite surface. E
3
B
(4 used)
Page 10

å Insert six WOOD DOWELS (3) into the SMALL BACK (E)
and SHELF (F).
å Fasten the LEFT END (A) to the SMALL BACK (E) and
SHELF (F). Tighten the HIDDEN CAM in the SHELF.
å NOTE: Be sure the WOOD DOWELS in the SMALL BACK
and SHELF insert into the LEFT END.
Step 6
E
A
3
(6 used)
F
Page 11
Now might be a
good time to refresh
your drink.
Surface without holes

å Insert four WOOD DOWELS (3) into the BOTTOM (D).
å Fasten the ENDS (A and B) to the BOTTOM (D).
Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the BOTTOM
insert into the ENDS.
Step 7
A
B
3
(4 used)
Page 12
D
Angled edge

å Insert six WOOD DOWELS (3) into the ENDS (A and B)
and BACK (E).
å Fasten the TOP (C) to the ENDS (A and B) and BACK (E).
Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the ENDS and
BACK insert into the TOP.
Step 8
A
B
3
3
(6 used)
Page 13
Finished edge
E
C

å Turn your unit onto its front edges.
å Place the LARGE BACK (H) into the groove of the
ENDS (A and B) and fasten it to your unit using the NAILS (7).
Step 9
E
D
Page 14
NAIL
(12 used for the BACK)
7
H
Unfinished surface
A
B

Step 10
Wall
Stud
Level
Page 15
Horizontal line to mark
for holes in wall.
Mark for WALL
ANCHOR (6)
Mark in
center of
wall stud for
SCREW.
center line
of wall stud
Desired height of top
of your unit
1-5/8"
å You must fasten your unit to one wall stud and one
WALL ANCHOR (6).
å 1. You will need to locate a stud in your wall to fasten your unit.
Determine the desired height of unit on your wall and move
1-5/8" downward on the center line of the wall stud. Mark this
location on your wall as shown below.
å 2. The second mark will be for the WALL ANCHOR (6). This hole
should be 15-1/8" horizontally from the first mark in part 1. To do
this, place a level onto a horizontal straight edge from your wall
stud mark to the second hole location for the WALL ANCHOR.
Mark this location onto the wall as shown below.
å NOTE: Be sure the two marks are level before going to the next step.
15-1/8"
1st
2nd

å On the marks, drill a 3/32" hole in the center of a wall stud
and a 7/16" hole in your wall for the WALL ANCHOR (6).
å Next, push the wings of the WALL ANCHOR (6) together,
while inserting the WALL ANCHOR into the 7/16" hole
until it is even with the surface of the wall.
Step 11
Page 16
6
1-5/8"
15-1/8"
Drill an 3/32" hole
into the center of
the wall stud.
Horizontal hole line
Desired upper line of
the top of your unit
Drill a 7/16" hole
into the wall
for the WALL
ANCHOR (6).

Step 12
Page 17
å With the help of another person, fasten your unit to the wall. Use two 2-7/16" FLAT HEAD SCREWS (8) into the wall
stud and into the WALL ANCHOR.
å Peel BLACK APPLIQUES from the BLACK APPLIQUE CARD (4) and stick them onto each visible HIDDEN CAM.
å Peel WHITE APPLIQUES from the WHITE APPLIQUE CARD (5) and stick them onto the screw heads in the BACK (E).
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
4
5
E
15 lbs.
15 lbs.
10 lbs.
2-7/16" FLAT HEAD SCREW
(2 used in this step)
8

WARNING
Please use your furniture correctly and safely. Improper use can cause safety hazards,
or damage to your furniture or household items. Carefully read the following chart.
Look out for: What can happen: How to avoid the problem:
• Properly mounting the cabinet to the wall. • If not properly mounted, the cabinet can
tip over and cause injury and damage. • Carefully review and follow the mounting instructions contained in this manual.
• Overloaded furniture. • Risk of injury.
• Overloaded furniture can break. • Never exceed the weight limits shown in the instructions.
Page 22
