Mutsy NEXO User manual
NEXO
instruction manual
1
6
2
3
9
17
4
14
15
5
12
7
8
10
11
13
16
b
a
c
d
e
f
g
p
q1
q2
r
h
i
j
m
n
o
click!
s
v
u
t
Instruction manual Mutsy Nexo
2
Content
Introduction........................................................................................................... 2
Warnings................................................................................................................ 2
Guarantee .............................................................................................................. 4
Maintenance and points for attention.................................................................... 5
Contents of the box................................................................................................ 6
Summery of parts: part of the drawing.................................................................. 6
Orientation ............................................................................................................ 6
The frame............................................................................................................... 6
The wheels............................................................................................................. 7
The brake ............................................................................................................... 7
The push bar .......................................................................................................... 7
The pushchair seat ................................................................................................. 8
The Maxi-Cosi car seat.......................................................................................... 11
Introduction
·To get the best out of this product, we recommend careful use and
maintenance. Read these instructions for use carefully before you start
using the pushchair and keep the instructions for future reference.
·If you have any questions, comments, problems or complaints, please
contact your retailer.
·If you want to know what accessories are available for this product or if you
want to stay informed of new Mutsy products then go to www.mutsy.com.
؍WARNINGS
·IMPORTANT: Keep these instructions for future reference
·WARNING: Failure to observe the instructions for use may put your child’s safety at
serious risk.
·WARNING: You are responsible for your child’s safety.
! WARNING: To avoid injury or death:
·Always apply the brakes whenever the pram / stroller is stationary.
·Do not leave children unattended.
·Secure the child in the harness at all times.
·Do not carry extra children or bags on this pram / stroller.
·Make sure children are clear of any moving parts if you adjust the pram / stroller.
·WARNING: The pram is suitable for infants from birth up to 25 kg.
·WARNING: For infants from 0 to 6 months, the pram must be set to reclined car-
riage position
·WARNING: For infants from 0 to 6 months, the seating surface must be set to a at
position.
·WARNING: For infants from 0 to 6 months, the backrest must be set to the fully
3
reclined position.
·WARNING: For infants from 0 to 6 months, the padded crotch strap of the safety
belt must be mounted in the rear opening of the seat.
·WARNING: For infants from 0 to 6 months, the shoulder straps must be mounted in
the lowest opening of the backrest.
·WARNING: For infants from 6 months and up to 25 kg, the pram must be removed
from the reclined carriage position.
·WARNING: In both lying position and sitting position, the pram seat is suitable for
infants from 6 months and up to 25 kg.
·WARNING: The maximum permissible weight as indicated on the relevant product
applies when using a car seat.
·WARNING: A car seat combined with the frame is no replacement for a cot or bed.
If your child needs to sleep, place it in a suitable pram, bed or cot.
·WARNING:When using a BeSafe car seat make sure the pushchair seat is assembled.
·WARNING: A shopping basket is located between the wheels underneath the
frame.The maximum permissible weight for this basket is 5 kg.
·WARNING: Overloading can result in a dangerous, instable situation.
·WARNING: Bags, accessories or both, other than recommended by the manufac-
turer, can, when placed on the product, result in an unstable pram. Exclusively use
original Mutsy accessories.
·WARNING: Shopping bags or other heavy objects must not be hung on the push
bar due to the risk of toppling.
·WARNING: Never leave the child in or near the pushchair unsupervised.
·WARNING: Do not allow your child to play with the pram. Doing so can result in
dangerous situations.
·WARNING: To avoid pinching of ngers or other body parts, keep children away
from the chassis when folding and unfolding the product.
·WARNING: Before use of the pram, check that the frame including the push bar has
been unfolded and secured correctly and completely.
·WARNING: Before use of the pram, check that the frame has been unfolded and
secured both correctly and completely.
·WARNING: Before use with the car seat, always check whether the attachment
points of the adapters have been secured correctly.
·WARNING: Always check that the accessories have been secured properly before
you start using the pram.
·WARNING: Only use the pram for one child at a time.
·WARNING: Before placing or lifting your child, always check whether the brakes on
the frame have been applied.
·WARNING: Always use the safety harness when you use the pushchair seat.
·WARNING: Always secure your child with the 5-point safety harness combined
with the strap running between the legs.
·WARNING:You must take your child from the pram before lifting the pram or using
4
stairs, escalators or lifts.
·WARNING:You need to tilt the pram/stroller and drive to the rear wheels if you go
on or o a curb.
·WARNING: Always apply the brakes when parking the pram.
·WARNING: This product is not suitable for running or skating.
·WARNING: Only use replacement parts supplied and/or recommended by Mutsy.
! WARNING: Use the tether strap to stop the pram/stroller rolling away.
·WARNING: Always keep the pram/stroller away near an open re or exposed ame.
·WARNING: The pram/stroller is only designed for use on at or gently sloping sur-
faces and may become unstable on higher sloping and uneven surfaces.
·The Mutsy Nexo has been approved according to AS/NZS 2088:2013
Guarantee
All Mutsy products come with a two-year guarantee, which starts on
the day of purchase. In the event of a manufacturing fault, Mutsy will
work with its retailers to provide a solution. Manufacturing faults will be
repaired under the guarantee. The guarantee does cover exchanges or
returns of Mutsy products.
The guarantee will only be honoured if you can provide the following at
the store at which the product was purchased:
·a completed guarantee card
·a copy of the purchase receipt
·a clear description of the defect
·your product
The guarantee card can be found on:
www.mutsy.com/gben/service/warranty
This card must be completed correctly and submitted digitally. You will
also need to enter the serial number. This number can be found on a
white sticker on the product; it is usually located on the underside.
The guarantee does not apply:
·if the problem concerns fabric discolouration
·if the fabric has been damaged by water
·in relation to damage caused by the use of non-original Mutsy accessories.
·if you cannot provide the purchase receipt
·if you have used the product incorrectly or unreasonably
·in relation to regular wear and tear that occurs as a result of day-to-
day use
·in the event of damage caused by bad maintenance, neglect or an
accident
5
·if damage has been caused as a result of modications to the product
that have been carried out by the consumer, without permission from
the manufacturer
·if the damage is not reported promptly (within 2 months)
Mutsy provides no guarantee in relation to shrinkage or defects concer-
ning the fabric elements that have been caused as a result of cleaning.
Safety is a priority for Mutsy. We therefore fulfil the highest safety
standards:
·Europe: EN 1888
·UK: BS EN 1888
·Canada: SOR/ 85 - 379
·US: 16 CFR 1227
·AS/NZS 2088:2013
For questions or comments, please contact us via:
www.mutsy.com/auen/contact
Maintenance and points for attention
The frame
·Regularly check the locking mechanism of the frame. After cleaning
you can spray some Teon spray on it and rub it with a soft cloth. This
also applies to other moving parts.
The wheels
·To let the wheels run smoothly the wheel axles must regularly be
cleaned and lubricated with acid-free vaseline. The wheels can never
be lubricated with oil.
The fabrics
·The upholstery of the pram is not removable.
·You can treat stains on the outer fabric or lining of non-removable fabric
parts with some liquid bleach-free soap. Always treat the whole area.
·Removable fabric parts can be washed in the washing machine at 30°
with a wool wash programme. Wash without bleach and do not tum-
ble-dry. Do not iron and do not dry-clean. Close all zips, velcro parts
and pressing studs before washing.
·All Mutsy fabrics have been tested on water resistance however if the
pram gets really wet, the water can penetrate the inner and outer fab-
rics and leave circles behind. To prevent this we recommend you to al-
ways use the rain covers in case of wet weather.
·Always let a wet pram dry with a fully unfolded hood.
·Even though Mutsy fabrics are selected with the utmost care and are
6
tested on colour fastness, the fabrics can discolour. Mutsy shall not be
liable for any possible discolouration.
Contents of the box
·1 frame with pushchair seat and basket
·2 front wheels
·2 rear wheels
·1 hood
·1 bumper bar
Summary of parts: part of the drawing
01. push bar
02. height adjustment button push bar
03. upper frame unlocking buttons
04. lower frame unlocking buttons
05. fastening adjustment backrest
06. hood
07. upper fabric fastening of seat
08. bumper bar
09. bumper bar release button
10. lower fabric fastening of seat
11. hinge point seat
12. leg support
13. folding safeguard
14. rear wheel release button
15. brake pedal
16. swivelling wheel locking
17. adjustment strap
Orientation
·References in the text to the front, rear, left or right side of the pram
are described from the perspective of a user walking behind the
pram.
The frame
Unfold the frame (a, b)
·Keep children away from all moving parts when unfolding.
·Press the unfolding safeguard inwards (a1) and lift the upper frame
up until the lower support clicks into place. Move the push-bar back-
wards until you hear a second click. (b)
·Before use always check that the pram has been unfolded and se-
cured correctly.
7
Fold the frame (c, d)
·Stand behind the frame and put the frame on the brake. Put the height
adjustment buttons (c1) of the push bar in the lowest position. Pull the
release buttons of the upper frame (c2) towards you on both sides and
turn the push bar forwards until the push bar is on the lower support. (c3)
·Pinch the lower frame unlocking buttons and fold the frame. (d)
·The folding safeguard locks automatically when the product is folded up.
·You can carry the frame from the push bar when the folding safeguard
has been locked.
The wheels
Assemble the rear wheels (e)
·Slide the axle of the rear wheel in the rear wheel casing until you hear a click.
·Pull the wheel to check that it has been attached rmly.
Disassemble the rear wheels (f)
·Press the button at the back side of the rear wheel casing and take the
wheel o the frame
Assemble the front wheels (g)
·Slide the axle of the front wheel upwards in the front wheel casing until
you hear a click.
·Pull the wheel to check that it has been attached rmly.
Disassemble the front wheels (g)
·Push the button on the back side of the front wheel (g1) and pull the
wheel from the front wheel casing. (g2)
The swivelling wheels (h)
·Turn the ring above the front wheel outwards on both sides in order to
block the swivel setting. The swivelling wheels will automatically be
locked when the wheels are placed in the rear direction.
·Turn the ring above the front wheel on both sides inwards to unlock
the swivelling wheels.
The brake (i)
·Push the brake pedal downwards with your foot to block the rear wheels.
·Push the brake pedal upwards with your foot to unblock the rear wheels.
The push bar (j)
·The push bar has three dierent height positions. Press the height ad-
justment buttons (j1) and move the push-bar higher or lower while
8
keeping the buttons depressed.
·Release the button when the push bar is in the desired position.
The pushchair seat (0 months up to 25 kg)
·The pushchair seat is suitable for children from 0 months and upwards,
up to 25 kg. The back support and leg support are adjustable. Make
sure that the frame has been fully unfolded and the brake is blocked
during all actions indicated below.
Reclined carriage position (0 - 6 months) (t)
Infants younger than 6 months must be strolled in a at fully reclined po-
sition. To do so, you must set the pushchair seat in the reclined position.
This position makes the reclining angle at and ensures more comfort
and safety. The reclined carriage position has ve aspects:
·The seat needs to be set into the at fully reclined position; A double
strap is located at both sides of the seat. Pull the outer strap down-
wards until the top press-stud (t1) is visible. Push the seat slightly high-
er to create more room. Now fasten the press-stud. The seat is now in
the reclined position.
·The backrest must be set in the fully reclined position. See ‘Adjusting
the backrest’.
·The zip for the leg rest barrier is at the bottom of the leg rest.
·Open the zipper and pull it from the pocket.
·Fold back the fabric of the leg support.
·Fasten the press studs of the leg rest barrier to the corresponding studs
on the side of the seat.
·In order to t the crotch strap with small children, unbuckle the shoul-
der- and waist belts. Beneath the fabric at the rear opening on the
seat there is a loop. Take the loop out of the opening. Insert the belt
through the loop, together with the fabric cover.
·The shoulder straps must be mounted in the under most openings of
the backrest. See ‘The 5-point safety belt’.
Never use the reclined carriage position of the seat unless the child is
properly secured with the 5-point safety harness.
The pushchair seat must be removed from the reclined carriage position
for infants from 6 months and up to 25 kg.
·The seat needs to be set be set into the sitting position. Pull the outer
strap partially out of the upholstery to loosen the press-stud (t2). Loos-
en the press-stud. Push the seat down completely.
·The backrest can be set to any desirable position. See ‘Adjusting the
backrest’.
9
·Undo the press studs in order to store the leg rest barrier. Open the zip
on the pocket.
·First fold the two sides with the press studs inwards and then fold in the
centre section. Put the 2 fabric parts under the centre section when
folding and make sure that there are no sharp corners in the ribbing.
·Close the zip on the pocket.
·The padded crotch strap of the safety belt must be mounted in the
foremost opening of the seat. See‘The 5-point safety belt’.
·The shoulder straps must be mounted in one of the top three pairs of
openings of the backrest. See ‘The 5-point safety belt’.
Adjust the back support (m)
·The button for adjusting the back support is located at the rear of the
back support.
·Pinch the button and continue pressing it while moving the back sup-
port backwards to lower the back support. Release the button when
the back support has reached the desired position.
·Pinch the button and continue pressing it while moving the back sup-
port forwards to bring the back support in an upright position. Release
the button when the back support has reached the desired position.
Adjust the leg support (n)
·Lift the leg support to place it upwards.
·Pull the tube (n1) at the bottom of the leg rest to lower it again.
Attach and remove bumper bar (o)
·To secure the front bumper, press the ends of the bumper into the re-
cesses (o1) intended for this purpose on the frame until you hear a click.
·Press the unlock buttons (o2) on the inside of the bumper bar to re-
move the bumper bar from the frame.
Place the hood (p)
·Press the clips of the hood on the correct location on the frame. The
hood is xed on the tubes of the frame. (p1)
·Subsequently, attach the fabric of the hood to the top of the back sup-
port using the studs. (p2)
Adjust the hood (q)
·Hold the front hood bar in the centre and move it forwards or rearwards to
adjust the hood (q1)
·Open the zipper in the centre of the opened hood in order to enlarge it. (q2)
·Close the zipper to again reduce the hood.
10
·Pull the ap on the front side of the hood outwards to additionally en
large
the hood. Push the ap inwards to again reduce the hood.
Remove the hood (r)
·Release the studs at the top of the seat (r1). Then press the lip (r2) at the
bottom of the clips of the hood inwards and remove the hood.
Assemble the rain cover on the pushchair (s)
·Make sure that the hood of the pushchair is in the upright position.
·Possibly open the zipper in the rain cover to adapt it to the enlarged
hood of the pushchair.
·Place the rain cover from top to bottom over the pushchair and make
sure that the rain cover is attached well behind the back support and
over the footrest.
The 5-point safety harness (u)
·Place your child in the pushchair and make sure that the legs of
your child are placed on each side of the leg piece.
·Make sure that the waist and shoulder belt is positioned correctly
over your child and place both plastic clamps in the central part of
the harness attached to the leg piece.
·In order to adapt the length of the shoulder belts, you release the
shoulder protection from the belt by pulling the Velcro loose. The
straps of the belt are now free in order to adapt the length. You
adapt the length by sliding the straps over the shoulder belts un-
til both shoulder belts properly harness your child. Slide the strap
down to make the belt longer. Move the strap upwards to make the
belt shorter. This will create a loop in the belt. Hold on to the strap
and pull the clamps to take the loop out of the belt again. Attach
the shoulder protection to the belt again on both sides after adjust-
ment by pressing the velcro together again.
·The back support contains three positions for the shoulder belts.
Release both shoulder belts by inserting the fastening rings at the
rear of the back support through the openings. Look for the fas-
tening ring through the fabric (v1). Tilt it and push it through the
opening. (v2)
·Move the attachment rings through the desired openings so that
the shoulder belts are positioned properly.
·In order to fit the crotch strap with small children, unbuckle the
shoulder- and waist belts. Beneath the fabric at the rear opening on
the seat there is a loop. Take the loop out of the opening. Insert the
belt through the loop, together with the fabric cover.
11
·Regularly check the length and position of the belts and adjust,
where necessary.
Maxi-Cosi car seat
·The Maxi-Cosi car seat adapters are suitable for use with the following
Maxi-Cosi group 0+ car seats: Maxi-Cosi citi , Maxi-Cosi Mico
·Always observe the instructions in the manual of your Maxi-Cosi car
seat before you start using the car seat.
·Make sure that the frame has fully been unfolded and the brake blocked
during all actions indicated below. The car seat can be combined with
the pushchair seat.
Place the Maxi-Cosi adapters on the frame (y)
·The adapter marked with‘R’is placed on the right side of the frame, the
adapter e adapter marked‘L’ is placed on the left side.
·Remove the bumper bar and the hood.
·There is an opening at the front of the adapter. Put the opening of the
adapter around the cam (y1) on the frame from the outside.
·Turn the top of the adapter inwards (y2) until it clicks. Check that the
adapter has been attached properly by trying to lift it from the frame.
Place the Maxi-Cosi car seat on the adapters
·Orientate the Maxi-Cosi car seat such that it is directed rearwards on
the frame.
·Hold the Maxi-Cosi car seat with the central hinge points of the support
bar directly above the adapters.
·Lower the Maxi-Cosi car seat and press solidly into the adapters until you
hear a click. Check that the Maxi-Cosi car seat has been placed horizon-
tally and has been attached properly by trying to lift it from the frame.
Remove the Maxi-Cosi car seat from the adapters
·Operate the unlocking system of the Maxi-Cosi car seat.
·Lift the Maxi-Cosi car seat straight up from the frame.
Remove the Maxi-Cosi adapters from the frame (z)
·Press the release button (z1) on the adapter. Turn the top of the adapter
outwards (z2) and take the adapter out of the cam from the top. (z3)
mutsy.com
Nieuwkerksedijk 14
5051 HT Goirle
the Netherlands
T + 31 (0)135345152
F + 31 (0)135341163
E info@mutsy.nl
Other manuals for NEXO
4
Table of contents
Other Mutsy Stroller manuals
