Oxgard CUBE C-03 Specification sheet

VOZROZHDENIE LLC
OKPD 2 26.30.50.110
TU 26.30.50-001-33120038-2017
APPROVED BY
VZR.247800.001 LU
TURNSTILE
MODEL CUBE C-03
VZR.247800.001 LB
LOGBOOK
40 sheets
2020

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
2
CONTENTS
Abbreviations .................................................................................................................................... 4
1General Provisions..................................................................................................................... 5
2Basic information....................................................................................................................... 6
3Basic technical data................................................................................................................... 7
4Individual features...................................................................................................................... 9
5Complete set............................................................................................................................. 10
5.1 Product components............................................................................................................. 10
5.2 Spare parts, tools, and accessories...................................................................................... 11
5.3 Limited resource items ......................................................................................................... 11
5.4 Operational documents ........................................................................................................ 12
6Resources, service and storage life, manufacturer's warranty............................................. 13
6.1 Resources, service and storage life...................................................................................... 13
6.2 Manufacturer's warranty....................................................................................................... 13
7Preservation ............................................................................................................................. 16
8Packing Certificate................................................................................................................... 17
9Acceptance Certificate............................................................................................................. 18
10 Product Service Record........................................................................................................... 19
10.1 Acceptance and handover of the product ........................................................................... 20
10.2 Information on allocation of the product during operation ................................................... 20
11 Product Running Time Record................................................................................................ 21
12 Record of maintenance............................................................................................................ 22
13 Recording work performed according to bulletins and instructions.................................... 23
13.1 Recording work performed according to bulletins ............................................................... 23
13.2 Recording work performed according to customer's instructions ........................................ 23
14 Works performed during the product operation .................................................................... 24
14.1 Record of work performed.................................................................................................. 24
14.2 Special notes regarding operation and emergencies.......................................................... 25
14.3 Periodic monitoring of basic operational and technical characteristics................................ 26
14.4 Information about claims .................................................................................................... 27
15 Storage...................................................................................................................................... 28
16 Repair........................................................................................................................................ 29

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
3
16.1 Summary about repair performed....................................................................................... 29
16.2 Data of acceptance test...................................................................................................... 29
16.3 Acceptance Certificate and warranty.................................................................................. 30
17 Special marks........................................................................................................................... 31
18 Information on utilization......................................................................................................... 33
19 Checking the product condition and maintaining the Logbook............................................ 34
20 Information on purchase ......................................................................................................... 35
21 Information on installation....................................................................................................... 36

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
4
ABBREVIATIONS
The following abbreviations are used in this document:
LB —Logbook;
OM —Operation Manual;
IM —Installation Manual;
PSU - power supply unit;
CP - control panel;
ACS - access control system.

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
5
1 GENERAL PROVISIONS
This Logbook (LB) applies to Turnstile Oxgard CUBE C-03 and its
modifications (hereinafter referred to as the product).
Before using the product, please read the Operation Manual
(VZR.247800.001 OM) as well. The product should be installed according to
Installation Manual (VZR.247800.001 IM).
The Logbook should be kept with the product at all times.
All entries in the Logbook should only be made in black ink, clearly and
accurately. Erasures, blots, and incomplete corrections are not allowed. All
corrections should be certified with sign and stamp of QCD.
A person who accepted the product for use shall be responsible for
safekeeping of the Logbook and correctness of its completion.
The product shall be sent for repair together with the Logbook which
contains information on the number of running hours since the start of the product
operation, and along with Report on Technical Condition.
When transferring the product to another company, final summing records
of running time should be certified with the seal of the company which transfers
the product.
Persons responsible for the product during its operation and storage shall
regularly fill in relevant Logbook sections.
Note - The product operation generally includes its intended use, transportation, storage,
maintenance and repair.

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
6
2 BASIC INFORMATION
Turnstile Oxgard CUBE C-03 is designed for control of authorized people
traffic, as well as for managing people passing and accessing the enterprise
through checkpoints.
Basic information is given in Table 1.
Table 1 –Basic information on the product
Product name
Turnstile Oxgard CUBE C-03
Manufacturer name
Vozrozhdenie LLC
Manufacturer address
192289, Russia, Saint-Petersburg, 66, Sofiiskaya str.
Specifications
TU 26.30.50-007-33120038-2017
Product serial number
Manufacturer date
Software version
FW v.d 4.
Declaration of conformity Eurasian
economic Union
PROMTEKHSTANDARD certificate

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
7
3 BASIC TECHNICAL DATA
Basic technical data of the product are given in Table 2.
Table 2 –Basic technical data
Parameter
Value
Turnstile
Control panel (CP)
Overall dimensions (HxWxL), mm:
- in operating condition
- with assembled arms
1,024х800х830
1,024х200х300
25х107х107
Weight, kg
25.0
0.5
Temperature range, °С:
- operation
- transportation and storage
+1...+40
+1...+40
+1...+40
+1...+40
Air relative humidity, %, not more than
80
80
Width of formed passage, mm
550-580
Throughput, pers./ min
30
Max. number of connected control panels, pcs.
2
Service life, years
8
8
Electrical characteristics are given in Table 3.

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
8
Table 3 –Electrical characteristics
Parameter
Value
Turnstile
Control panel (CP)
Supply voltage (direct current), V:
- nominal
- working
12.0
10.8...13.2
12.0
7.5...15.0
Average current in standby mode*, A
0.7
Average current in passage mode*, A
0.7
Maximum consumed current*, A
1.5
Note - * Values of current are given for nominal supply voltage
The product inspection results are given in Table 4.
Table 4 –Product inspection
Date
Reason for
inspection
Operating
time since the
beginning of
operation
Inspection result
Position,
surname and
signature of
the person
conducting
the
inspection
Maximum
consumed
current, A
Current in
standby
mode, A
Current at
passing, A

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
9
4 INDIVIDUAL FEATURES
The product should be installed by qualified personnel in accordance with
Installation Manual (VZR.247800.001 IM).
The passage zones shall be arranged to allow recording of passages
during operation of the ASC controlled product and avoid unauthorized passages.
Note —The manufacturer reserves the right to change structure, technical characteristics
and appearance of the product without further notice

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
10
5 COMPLETE SET
5.1 Product components
The product components are listed in Table 5.
Table 5 –Product components
Product designation
Product name
Quantity
Serial number
Note
Turnstile
CUBE C-03
1
Control panel (CP)
Control panel
Praktika
1
Power supply source*
1
Barrier section set
Praktika barrier
1

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
11
5.2 Spare parts, tools, and accessories
Spare parts, tools and accessories for the product are listed in Table 6.
Table 6 –Spare parts, tools, and accessories
Product designation
Product name
Quantity
Serial number
Note
Anchor with a screw*
FH 12/10 SK
3
-
Hex wrench*
S5 hex wrench
1
-
5.3 Limited resource items
Limited resource items are listed in Table 7.
Table 7 –Limited resource items
Product designation
Product name
Quantity
Serial number
Note
Note —In Tables 5, 6, and 7: the product components marked with (*) are optional.

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
12
5.4 Operational documents
Structure of operational documentation is given in Table 8.
Table 8 –Operational documents
Product designation
Product name
Quantity
Serial number
Note
VZR.247800.001 LE
Approval sheet
1
-
VZR.247800.001 LO
List of operational
documents
1
-
VZR.247800.001 LB
Logbook
1
-
VZR.247800.001 OM
Operation Manual
1
-
VZR.247800.001 IM
Installation Manual
1
-

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
13
6 RESOURCES, SERVICE AND STORAGE LIFE,
MANUFACTURER'S WARRANTY
6.1 Resources, service and storage life
Assigned service life of the product is 8 years. During this period (after
warranty period expiration - under separate contract), the supplier company
undertakes to provide servicing for the product operation:
1) assist the operator company in purchasing, repairing, and replacing faulty parts of the
product;
2) To inform independently the operating company about purchase of products which have
been removed from
3) Where necessary, carry out, together with the operator company, assessment of the
condition of the product component parts and develop measures to maintain the
functionality;
4) Carry out work on improvement and development of the product.
Life spans and service lives for incoming components shall be determined
using individual passports (logbooks).
These resources, service and storage life are valid if customer comply with
requirements of current operational documentation.
6.2 Manufacturer's warranty
The warranty period of the product is 24 months from the date of sale by
the manufacturer, provided that the consumer adheres to all the instructions given
in the Installation Manual and Operation Manual.
The sale date is specified in the Product Logbook. If there is no sale date,
the warranty period shall be calculated from the date of manufacture of the
product as detailed in the Logbook.

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
14
If any problems occur, contact authorized dealer or the nearest authorized
service center. The warranty terms and conditions provide for a free-of-charge
replacement of parts, assemblies, units, etc., in which a manufacturing defect is
detected. The warranty is provided if the product owner adheres to maintenance
requirements given in the Maintenance Manual.
The addresses of authorized dealers and service centers are listed in the
Operation Manual and are available on the website: www.oxgard.com
The warranty conditions do not provide for transportation costs and
specialist’s visit to the product’s operation site for connecting, configuring,
repairing the product or for consulting purposes.
Post-warranty service is provided at the rates set by the service center. In
case of a non-warranty repair, the warranty period for replaced parts and
assemblies is 3 months from the date of sending the fault-free product to the
buyer's address.
All replaced parts, assemblies, units, etc. become the property of the
service center which performed the warranty and post-warranty repairs of the
product.
All claims for quantity, completeness and appearance of the delivered
goods should be accepted by the manufacturer in writing not later than 5 (five)

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
15
business days from the date of goods receipt of by the buyer. In case of non-
compliance with the above deadline, claims to the delivered product according to
the listed grounds will not be accepted.
Service center has the right to refuse warranty repairs in the following
cases:
1) if there are defects resulting from customer’s violation of instructions given in the
Installation Manual VZR.247800.001 (IM) and the Operation Manual VZR.247800.001
(OM);
2) if the product is not used for its intended purpose;
3) if there are signs that user has modified the product design;
4) if there is mechanical damage resulting from fire, impact or accident, etc.;
5) if there is mechanical damage resulting from operating the product in excess of the
operational limits and load characteristics specified by the manufacturer;
6) if there is electrical damage to the product’s parts and assemblies, resulting from
voltage surges in the mains, incorrect connections, incorrect power cable selection;
7) if there is electrical and any other damage to the product’s parts and assemblies due to
ingress of water and other liquids;
8) if there is damage related to life activities of small animals and insects;
9) if there are signs of self-repair undertaken anywhere other than in the authorized service
center, as well as defects resulting from use of non-original spare parts;
10) if there are malfunctions that are due to normal wear or expiry of service life of the
product components (consumables, fuses and other components).

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
16
7 PRESERVATION
Information on preservation is given in Table 9.
Table 9 –Preservation
Date
Name of work
Duration, years
Position, surname and
signature

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
17
8 PACKING CERTIFICATE
Turnstile Oxgard CUBE C-03 ___, Serial number No.__________________
Packed ____________________________________________________________________
Manufacturer name or code
according to requirements stipulated in current technical documentation.
Packed ____________________________________________________________________
position personal signature printed name
___ _________ 20__

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
18
9 ACCEPTANCE CERTIFICATE
Turnstile Oxgard CUBE C-03___ serial number _______________ has
been manufactured and accepted in accordance with mandatory requirements of
national standards, current technical documentation; and recognized as fit for
operation.
Head of QCD
Stamp of QCD
_________________/_______________/
___ ________20__
Grounds for delivery ________________________________
Head of enterprise
Stamp
_________________/_______________/
___ ________20__
Customer
Stamp
_________________/_______________/
___ ________20__

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
19
10 PRODUCT SERVICE RECORD
The product service record is detailed in Table 10.
Table 10 –Product Service Record
Installatio
n date
Place of
installatio
n
Decommissio
n date
Operation time
Decommissio
n reason
Signature of the
person who
performed
installation
(decommissioning
)
since the
beginnin
g of
operation
since
last
repai
r

VZR.247800.001 LB
Turnstile CUBE C-03
Logbook
20
10.1 Acceptance and handover of the product
Information on acceptance and handover of the product is given in
Table 11.
Table 11 –Acceptance and handover of the product
Date
Product
condition
Decommission
date
Enterprise, position and
signature
Note
who returned
who accepted
10.2 Information on allocation of the product during operation
Information on allocation of the product during operation is given in
Table 12.
Table 12 –Information on allocation of the product during operation
Product
(component) name
and designation
Position, surname
and initials
Grounds (name, number and date
of the document)
Note
Allocation
Deallocation
