Oxgard PRAKTIKA QL-04-SM-660 Instruction sheet

GUARDING THE FUTURE
ООО «VOZROZHDENIE»
ISIC 2 26.30.50.110
Technical regulations 26.30.50-007-33120038-2017
APPROVED
VZR.230200.000 AS
TURNSTILE
MODEL PRAKTIKA QL-04
QL-04-SM-660, QL-04-SM-900, QL-04-SMК-660, QL-04-SMК-900, QL-04-
SMR-660, QL-04-SMR-900, QL-04-SMRK-660, QL-04-SMRK-900,
QL-04-CM-660, QL-04-CM-900, QL-04-CMK-660, QL-04-CMK-900, QL-04-
CMR-660, QL-04-CMR-900, QL-04-CMRK-660, QL-04-CMRK-900,
QL-04-GCM-660/900, QL-04-GCMR-660/900
VZR.230200.000 IG
INSTALLATION GUIDELINES
Pages 48
2018

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
2
CONTENTS
1GENERAL INSTRUCTIONS............................................................................................................. 4
2SAFETY REQUIREMENTS .............................................................................................................. 5
3Preparations for item’s installation................................................................................................ 6
3.1 Transportation of item to the installation place........................................................................ 6
3.2 Unpackaging regulations........................................................................................................ 6
3.1 Item’s inspection regulations .................................................................................................. 6
3.3 Requirements for the installation site...................................................................................... 7
3.2 Procedure for checking the conformity of the installation site.................................................. 8
4Items´s installation and dismantling.............................................................................................. 9
4.1 Installation.............................................................................................................................. 9
4.2 Dismantling .......................................................................................................................... 12
5Items connection and setting-up................................................................................................. 13
5.1 Connecting power supply..................................................................................................... 15
5.1 Connecting control panel...................................................................................................... 16
5.2 Connecting ACS (optionally)................................................................................................. 16
5.3 Connecting Remote control panel to ACS controller............................................................ 18
5.2 Connecting side units........................................................................................................... 22
5.3 Connecting card collector..................................................................................................... 26
6.1 Inspection and verification of the product’s readiness for usage ........................................... 34
6commissioning of installed item.................................................................................................. 35
APPENDIX А—Brief Description of Data Bus CAN2.0..................................................................... 36
APPENDIX B —Power supply units and controllers......................................................................... 38
APPENDIX C —Location of installation turnstile holes.................................................................... 39
APPENDIX D —Block diagram of ACS using the card collector...................................................... 40
APPENDIX E —Block diagram of minimal connections for synchronized operation of wings with
the use of one RC panel...................................................................................................................... 43
APPENDIX F —EXAMPLE OF INSTALLING SEVERAL UNITS ......................................................... 45
APPENDIX G —Designation of reader terminals PROX ................................................................... 46

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
3
This installation guidelines (IG) is composed for Turnstile Oxgard Praktika
QL-04 иand its modifications (hereinafter referred to as - item). Firmware version:
FW v2.4-2.5
1) software turnstile version with swing doors 660 mm –FW v2.4;
2) software turnstile version with swing doors 900 mm –FW v2.5.
IG establishes the rules and procedure for the installation and
commissioning of the item.
Before installing the item you should also read the Operational manual
VZR.230200.000 OM.
Taking into account ongoing work of improving the item’s design, some
changes can be made that won’t be reflected in this edition of the IG.
Turnstile can be integrated with card collector.
List of abbreviations used in this document:
OM —operational manual;
IG —installation guidelines;
PS —power supply;
RCP —remote control panel;
ACS—access control system;
SFAS —security and fire alarm;
NC —normally connected;
NO —normally opened.
NO —normally open connection;
AD —actuation device (turnstile).

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
4
1 GENERAL INSTRUCTIONS
When assembling and installing the product for general safety take into
account all the recommendations and instructions given in this manual.
Before starting the installation work, completely disconnect the power
supply of the item.
IT IS PROHIBITED:
TO INSTALL POWER SUPPLY MODULE INSIDE THE BODY OF THE
TURNSTILE AS IT MAY RESULT IN AN INJURY OF THE HUMAN BEINGS DUE
TO AN ELECTRIC SHOCK.
TO INSTALL THE TURNSTILE OUTSIDE DRY AND HEATED PREMISES.
BLOCK OR ACCELERATE THE MOVEMENT OF ARMS OF THE
TURNSTILE.
TO USE PASTES AND LIQUIDS CHEMICALLY AGGRESSIVE TO THE
MATERIALS OF THE HOUSING FOR CLEANING PURPOSES OF THE
PRODUCT.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
5
2 SAFETY REQUIREMENTS
Installation should be carried out in compliance with the "Rules for the
technical operation of electrical installations of consumers" and "Safety
regulations for the operation of electrical installations of consumers".
The installation of the product should be carried out by qualified personnel
prepared for work with electrical appliances, instructed about safety precautions
when working with electrical installations with voltages up to 1000 V.
ATTENTION: A FAILURE TO OBSERVE SAFETY
REQUIREMENTS, INDICATED IN THIS SECTION, MAY CAUSE DAMAGE TO
LIFE AND HEALTH OF PEOPLE, COMPLETE OR PARTIAL LOSS OF
OPERATING CAPABILITY OF THE PRODUCT AND (OR) AUXILIARY
EQUIPMENT.
ATTENTION: THE MANUFACTURER SHALL DISCLAIM THE
LIABILITY FOR CAUSING INJURY TO HUMAN LIFE AND HEALTH
COMPLETE OR PARTIAL LOSS OF OPERATING CAPABILITY OF THE
PRODUCT AND (OR) AUXILIARY EQUIPMENT IN CASE OF A FAILURE TO
OBSERVE SAFETY REQUIREMENTS, INDICATED IN THIS SECTION, AND
WILL TERMINATE THE VALIDITY OF THE PRODUCT WARRANTY.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
6
3 PREPARATIONS FOR ITEM’S INSTALLATION
3.1 Transportation of item to the installation place
Turnstile in its original packaging shall be transported by air, by road and
by railroad with protection from direct exposure to rain and dust without range
limitation.
After transportation at a negative temperature, in order to avoid
condensation of moisture, the item should be kept in a room with normal climatic
conditions during 12 hours.
Loading and unloading operations must be carried out in compliance with
safety regulations.
3.2 Unpackaging regulations
3.2.1 Perform an external inspection of the packaging. Box should not
have visible damage.
3.2.2 Open the box, unpack it and look for the content:
1) Turnstile units;
2) Remote control panel with cable;
3) Keys from the locks (4 pcs).
3.1 Item’s inspection regulations
3.1.1 Check the complete set of delivery
Set of delivery should be checked in accordance with Datasheet
VZR.230200.000 DS.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
7
3.1.1 Perform an external inspection of the packaging. Box should not
have visible damage.
3.1.2 In case of damage, make a reclamation act.
3.1.3 0 overall turnstile’s dimensions
Picture 1 Overall turnstile’s dimensions
3.3 Requirements for the installation site
ATTENTION: INSTALL THE TURNSTILE RELIABLY IN ORDER TO
AVOID SWINGING AND / OR TURNOVER IN THE PROCESS OF OPERATION.
IN CASE OF MOUNTING THE TURNSTILE TO THE FLOOR OF LOW
STRENGTH - TAKE MEASURES TO STRENGTHEN THE FLOORS IN THE
PLACE OF INSTALLATION.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
8
3.2 Procedure for checking the conformity of the installation site
ATTENTION: DURING INSTALLATION TAKE INTO ACCOUNT THAT
GLASS WINGS CANNOT BE ADJUSTED. IT IS RECOMMENDED TO CHECK
THE CORRECTNESS OF INSTALLATION BEFORE FIXING THE SIDE UNITS.
ATTENTION: DURING PREPARATION OF THE INSTALLATION SITE
TAKE INTO ACCOUNT THAT EACH SIDE UNIT REQUIRES A SEPARATE
POWER SUPPLY.
ATTENTION: DURING INSTALLATION OF THE SPEEDGATE PREPARE
CONDUITS FOR CABLE ROUTING OF CAN-BUS TO CONNECT SIDE UNITS.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
9
4 ITEMS´S INSTALLATION AND DISMANTLING
Required equipment
Equipment used in the process of installation of the turnstile:
1) electric drill;
2) hard alloy drill 16 mm in diameter for drilling holes for anchors in the floor
(recommended anchor shell SORMAT PFG ES 10);
3) wrench for screws DIN 933 М10х60 S17;
4) slotted screwdriver;
5) plummet or leveling gauge;
6) steel liners for turnstile aligning;
7) round file;
8) side cutters.
4.1 Installation
ATTENTION: BEFORE INSTALLATION CAREFULLY LOOK
THROUGH THIS SECTION OF INSTRUCTION.
4.1.1 Prepare horizontal surface at the installation site of the
turnstile.
4.1.2 Prepare cable conduit coming from the site to the installation
area of PS, remote control panel, and as well, if it is required, to the connection
point of ACS and SFAS.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
10
4.1.3 Installation site of the turnstile:
0 according to installation dimensions prepare 8 holes 16 mm in diameter
in the floor for fixation anchors of the two of the turnstile´s stands.
Location of the mounting holes in relation to the outer dimensions of the
turnstile is shown in Appendix B.
The depth of the hole, should exceed the length of the anchor by 5 mm.
Insert the anchors into the holes.
Picture 2 - Installation dimensions of the turnstile site with a passage width 660 (900) mm
4.1.4 0 cable routing is exercised through the hole 40 mm in diameter
the lower turnstile panels.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
11
4.1.5 Lay to the wiring duct or trench the connecting cable for remote
control panel, cable for PS, bus –CAN cable, RS-485 indication bus cable and, if
provided, ACS and SFAS cables.
4.1.6 Mount turnstile stands on the prepared installation site.
0 undo 4 screws М4 (2) and remove base cover (1).
Picture 1 –preparation for turnstile installation
1- Base cover; 2-screws M4 (4 pcs); 2 –screws M4 (4 pcs.)
4.1.7 Lay to the wiring duct or trench the connecting cable for remote
control panel, cable for PS and, if provided, ACS and SFAS cables.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
12
4.1.8 Align together the holes in the lower plate of side unit and
anchors in the floor.
Check the vertical installation in 2 planes. If necessary, use
appropriate steel underlayers for proper installation of the speedgate.
Fix the housing of side unit with 8 screws M10, tightening them
to the corresponding anchors by using a wrench with internal hexagon S17.
4.1.9 Connect necessary cables (Section 5). Secure cables with cable
ties.
4.1.10 Install the base cover to its normal position.
4.1.11 Remove protective film from the housing of the speedgate.
4.2 Dismantling
4.2.1 Disassembly of the product for dispatch for verification or repair
shall be carried out in the following order:
1) switch off turnstile’s power supply;
2) disconnect the item from the power supply;
3) disconnect the cable part of the item from additional cables
4) dismantle the item from the installation site
4.2.2 Before packing, clean the product of dust and dirt.
4.2.3 Pack the item to the packing box.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
13
5 ITEMS CONNECTION AND SETTING-UP
Connection of RC, PS and ACS is performed with the use of crossboard.
Picture 4 - the location of the boards at the stand of the speedgate unit.
Picture 1 –Arrangement of boards at speed gate stand
1 –cross-board, 2- motherboard, 3 –card collector’s board
ATTENTION: OPERATING MODE OF SPEEDGATE IS DEFINED BY
SETTING THE JUMPERS ON CROSSBOARDS OF BOTH SIDE UNITS OF THE
SPEEDGATE.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
14
0 depicts the cross-board and connectors for PS, RC, ACS and FA.
Picture 5 –General view of the cross-board
Table 1 describes different speed gate operation modes with different
positions of jumpers.
Table 1 –Speed gate operating modes
The position of jumpers
Operating mode of speedgate
J1 removed
Pulse mode (see article 5.3.)
J1 installed
Potential mode (see article 5.3).
J2 installed
Speedgate does not respond to the remote commands.
Status of the buttons is transmitted to the outputs I / O1 ... I /
O4 (see article 5.4)
J2 removed
Speedgate is controlled by remote control. Status of the
buttons is transmitted to the outputs I / O1 ... I / O4 (see
article 5.4)
- Jumper J3 is not used
- Jumper J4 is used to establish the normal operation of CAN2.0 bus. (See
Appendix A)

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
15
5.1 Connecting power supply
IT IS PROHIBITED:
DO NOT USE POWER SUPPLIES WITH AN OUTPUT CURRENT LESS
THAN 10 A. DO NOT CONNECT THE POWER CABLE WITH CROSS-
SECTION LESS THAN 1.5 ММ2. WHEN THE LENGTH OF THE POWER
CABLE IS MORE THAN 5 M - IT IS RECOMMENDED TO USE A CABLE
WITH 2.5 MM2 CROSS-SECTION.
ATTENTION: DO NOT INSTALL THE POWER SUPPLY AT A DISTANCE
MORE THAN 25 METERS FROM THE SPEEDGATE.
ATTENTION: FOR EACH SIDE UNIT MUST BE A SEPARATE POWER
SUPPLY.
Each passage (two wings) is powered by two sources of 12V DC voltage.
PS unit shall be selected on the basis of these parameters. Also note that
an increase in the length of the supplied cable increases the voltage drop (the
operating voltage range is given in the Operational manual VZR.230200.00 OM).
The list of recommended power supplies is provided in Appendix B.
Install the PS unit in a place with easy access for operator. Connect the
power supply to the POWER contact set on the cross-board. Connect (+) and (-)
contacts of PS unit to (12V) and (GND) terminals respectively.
Make sure the cables are securely connected.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
16
5.1 Connecting control panel
RC panel is connected to Control Board contact set on cross-board.
Marking of contacts: 12V, CL, CH, GND.
Connection of RCP shall be made on the basis of contacts’ marking,
provided in Table 2.
Table 2 - Contact marking for RCP connection
Contacts marking
Wire color
12V
Red
CL
Yellow
CH
Green
GND
Blue
5.2 Connecting ACS (optionally)
ACS Controller will have to be connected to the group of contacts Access
Control System on the cross board.
The contacts will have to be marked as follows: LEFT, RIGHT, STOP,
GND. Contact assignment is indicated in Table 3.
Table 3 - ACS contacts assignment
Marking of contacts
Contact assignment
LEFT, RIGHT
One-pass movement to the left/to the right (lowest
priority)
STOP
No Entry (“Stop” mode)
(medium priority)
AP
Folding arms («Antipanic function»)
(high priority)
GND
Common contact
Inputs for ACS connection will have to be identified by means of priorities:

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
17
1) AP input possesses the highest priority. At GND contact of this input the turnstile works
with open wings (glass doors) and DOES NOT REACT (!) to the other signals except for
AP;
2) STOP mode possesses the medium priority. AT GND contact of this input the turnstile
in stop mode “Stop! and does not react to the other signals except for AP signal;
3) LEFT and RIGHT possess equally low priority and include one pass to one or another
side. If both inputs are closed, the pass will be allowed to the side which input closed first.
In case the pass fails to be done the turnstile will automatically change over to “Stop”
mode 5 seconds later.
ATTENTION: IN CASE OF ONE OF STOP INPUTS ARE CLOSED,
THE INSTRUCTIONS COMING FROM THE CONTROL PANEL WILL NOT BE
RECEIVED AS ACS HAS THE HIGHER PRIORITY.
STOP inputs are potential ones, i.e. until the input is at GND contact, the
turnstile is operating in the corresponding mode, after the contacts are opened
the turnstile changes over to “Stop” mode irrespective of what mode has been
until ACS activated.
Inputs LEFT and RIGHT are able to operate both in potential and pulse
mode (actuation by the fact of GND contact). Pulse mode is installed by default.
In order to switch to potential mode set J1 jumper (0 J1). And J1 shall be
set at both cross-boards of decided passage.
In this case the mode of left / right passage turns on only during the control
signal to LEFT / RIGHT.
Mode of free passage can be set by control signals to both inputs
simultaneously. Priorities of LEFT and RIGHT inputs at the switch to the pulse
mode remain unchanged.

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
18
Cross-board contains two relay outputs for ACS operating on the principle
of "dry contacts» - Pass Okl and Pass Ok2. NO and COMM - normally open
connection, NC and COMM - normally closed connection.
Activation of one of the contact sets suggests the passage in the
corresponding direction (PassOk1 - right or left, PassOk2 - left or right).
Activation of corresponding relay depends on the location of speedgate
and determined by an experiment. Related LED indicators turn on, either D1 for
right or D2 for left, depending on the direction of passage.
Cross-board contains relay output for ACS operating on the principle of
"dry contacts» - Status. NO and COMM - normally open connection, its contacts
close when the speedgate switches to "AP" and D3 LED indicator lights up.
Also the cross-board contains following LED indicators indicating that they
are closed at the following GND inputs:
1) D4 indicates a signal to the «LEFT» input.
2) D5 indicates a signal to the «RIGHT» input.
3) D6 indicates signal to the «STOP» input.
4) D7 indicates a signal to the «AP» input.
Jumper J4 must be installed - used to connect a 120 ohm resistor to the
CAN 2.0 bus in order to ensure its normal operation.
When using two control panels, J4 is not set, since the 120 ohm resistors
are on the CL and CH terminals on Remote control panels.
5.3 Connecting Remote control panel to ACS controller
In some cases remote control panel must be connected directly to ACS
controller, as the passages, permitted by control panel (without controller), are
regarded by the system as «forced entry».

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
19
To use this turnstile connection scheme it is required to install a jumper of
chosen passage to the both cross-boards (Ошибка! Источник ссылки не
найден. J2). With J2 jumper installed the turnstile does not react to the signals
coming from the control panel but transmits their state to the contacts of the
terminals (0 I/O1...I/O4), which are the outputs with bare collector.
Contact assignment is represented in Table 4, 0 numbering of the control
panel buttons. For this group of contacts maximum output current does not
exceed 150 mА, permissible voltage is no more than 24 V.
Picture 6 –Numbering of RCP buttons
Numbering of control panel buttons

VZR.230200.000 IG
Turnstile Praktika QL-04
Installation guidelines
20
Table 4 - Assignment of I/O contact group
Маркировка контактов
Назначение контактов
I/O1
Status of “Left” button (1)
I/O2
Status of “Right” button (3)
I/O3
Status of “Stop” button (2)
I/O4
Status of “Antipanic” button (4)
I/O1 ... I/O3 outputs show the current status of the RC panel buttons, i.e.
transistor is opened by pressing the corresponding button. The I/O4 output
changes its state to the opposite every time the "Antipanic" button is pressed.
I/O1 ... I/O4 outputs can be connected either directly to the ACS controller or
via relay. Picture 7 - when using the relay it is NECESSARY (!) to connect diode
in parallel with the relay coil.
Cross-board
Picture 7 - Connection scheme of diode in parallel with relay coil
