Oxgard PRAKTIKA QL-04 Series Quick start guide

Operational
manual
www.oxgard.com
[e-mail]
Тел.[phone]
Praktika QL-04(K) turnstile
VOZROZHDENIE
METALWORKS

Operational manual 3
CONTENTS
List of abbreviations used ............................................................................ 4
2. Delivery set............................................................................................... 4
3. Basic specifications.................................................................................. 6
4. Product design.......................................................................................... 7
5. Transportation and storage..................................................................... 10
6. Safety requirements................................................................................ 11
7. Description of card collector........Ошибка! Закладка не определена.
7.1. Card collector purpose .................................................................... 13
7.2. Product design................................................................................. 13
7.3. Removing guest cards from card collector.................................... 14
8. Speedgate operation ............................................................................... 14
8.1. Turning on....................................................................................... 14
8.2. Operating modes ............................................................................. 15
8.3. Turnstile operstion with control board............................................ 15
Manual alarm unlock mode.................................................................... 16
8.4. Adjustment of remote control panel ............................................... 17
8.5. Control with card collector ............................................................. 18
Appendix 1. Recommended power supplies.............................................. 20
Appendix 2. Troubleshooting for speedgate.............................................. 21

Praktika QL-04(K) turnstile 4
List of abbreviations used
PS –power supply
FA –fire alarm
CB –control board
ACS –access control system
OD –operating device
Speedgate firmware version FW v2.4
Card collector firmware version FWv1.52

Operational manual 5
1. Product purpose
Praktika-QL-04(К) turnstile is designed for access control and
pedestrian flow management. The speedgate can be used at checkpoints at
factories and organizations, institutions, banks, schools, sports and
entertainment facilities, shops, railway stations, etc.
To ensure easy and quick passage of people it is recommended to
install one speedgate for every 500 people working in one shift.
2. Delivery set
Table 1. Delivery set
Item
Qty, pcs.
Praktika QL-04(К)
1
Remote control panel with cable
1
Hatch lock key
8
Datasheet
1
Installation guidelines
1
Operational manual
1.
SORMAT PFG ES 10* anchor
6
М10х60 DIN933 hexagon screw *
6
Connecting cable PVA 2x1,5*
2
Units arrangement diagram *
1
*-supplied optionally

Praktika QL-04(K) turnstile 6
3. Basic specifications
Table 2 Basic specifications
Description
Speedgate
RC panel
Overall dimensions of a side unit
(HxWxD) with a swing opened, mm
1052х1330х208
107х107х25
Overall dimensions of two-sided unit
(HxWxD) with swings opened, mm
1052х1330х208
107х107х25
Overall dimensions of a side unit
(HxWxD), mm
1052х1330х510
107х107х25
Overall dimensions of two-sided unit
(HxWxD), mm
1052х1330х812
107х107х25
Weight of side unit, kg
110,0
0,5
Weight of two-sided unit, kg
130,0
0,5
Temperature range, 0C
- operation
- transportation and storage
+1...+40
+1...+40
+1...+40
+1...+40
Atmosphere relative humidity, no more
than %
80
80
Throughput, people per minute
30
Card collector capacity (pcs.) **
50
Max. number of connected control boards,
pcs
2
Lifetime, years
8
8

Operational manual 7
Table 2. Electrical specifications
Specifications
Speedgate
Card collector**
Control
board
Supply voltage, V:
- nominal
- working
12,0
10,8...15,0
12,0
8…18,0
12,0
7,5...15,0
Average current in standby
mode * A
0,7
0,2
Average current in passage
mode * A
5,0
Maximal current of a side
unit*/***, A
7,5
Maximal current of card
collector*, A
1,5
*- values mentioned at a nominal supply voltage
**- optionally supplied
***- side units required to form a passage area, i.e. 2 power supplies units 12V 5A
The manufacturer reserves the right to change the packaging, technical specifications and
appearance without notice.
4. Product design
Speedgate housing
Speedgate housing is made of brushed stainless steel, wings are made
of tempered glass. Additionally the card collector can be integrated in the
design of the speedgate. Base covers for access to PU, Control board and
ACS cables holes (Fig. 1) are provided at the bottom of side units

Praktika QL-04(K) turnstile 8
LED strip indicates turnstile mode of passage set at the moment.
Indication strip is covered with tempered glass.
With the help of one-sided and two-sided units, it´s possible to
organize unlimited number of passages depending on customer´s needs.
Fig.1 General view of speedgate

Operational manual 9
LED indication strip
Speedgate indication strip is made of diodes covered with light-
diffusing insertion. Speedgate operating modes are reflected by moving
diodes on the indication strip (Fig 2).
Inserted into the indication strip diodes are covered with tempered
glass. LED strip reflects turnstile mode of passage set at the moment.
Fig. 2 LED indication strip view
Control board
The housing of CB is made of polished stainless steel. On the front
side there are control buttons and LED indicators of CB operational modes
(Fig. 3). The standard supplied cable is 5 m long.

Praktika QL-04(K) turnstile 10
Fig. 4 General view of remote control board
5. Transportation and storage
Speedgate in its original packaging shall be transported by air, by
road and by railroad with protection from direct exposure to rain and dust
without range limitation. It is allowed to stack boxes in 2 rows during
transportation and storage if Euro-pallets used. Keep the speedgate in dry
(no moisture condensation) heated places within +1 to + 40 °C temperature
range. Avoid vapors of acids, alkalis, and corrosive gases at the storage
place. Storage of speedgate in the original package in a dry unheated
premises or closed transport containers is permitted for short periods, no
more than 3 days. Before startup, the speedgate must be kept in a room
with normal climate conditions for 12 hours after storage in unheated
rooms.

Operational manual 11
6. Safety requirements
CAUTION! Failure to comply with the safety requirements specified in
this section may result in damage to human life and health, total or partial
loss of workability of products and (or) auxiliary equipment.
CAUTION! Specific guidance on the use of the speedgate:
1. The sensors are installed in the stands of speedgate at a height of 820
mm.
Children shorter than 820 mm cannot be identified by the speedgate.
Children must be accompanied by adults in charge when passing through
the speedgate!
Baggage, carts, bags etc. cannot be identified by the speedgate.
2. If there is no distance in the passage between the two visitors, they
might be identified as one.
CAUTION! Installation of speedgate must be carried out by qualified
personnel according to the instructions.

Praktika QL-04(K) turnstile 12
CAUTION! The producer disclaims any liability for damage to human life
and health, total or partial loss of workability of products and (or) auxiliary
equipment for non-compliance of the safety requirements specified in this
section, as well as terminate the product warranty.
IT IS NOT ALLOWED TO:
Set the power supply inside the speedgate housing as this might lead
to electric shock to persons;
Set the speedgate other than in dry and heated places;
Impede or accelerate the speedgate wings;
Apply chemically aggressive cleaning detergents (as pastes and
liquids) to the materials of the housing.

Operational manual 13
7. Description of card collector
7.1. Card collector purpose
Card collector (Fig. 4) is designed for collection and storage of
proximity access cards at the exit from the facility. Flexible logic of the
controller allows the integration of the card reader with any access control
systems.
7.2. Product design
Fig.4 General view of the card collector

Praktika QL-04(K) turnstile 14
In the back of the housing there is a storage device for card collector
for quick access to collected cards. The hatch has card storage device
where 50 cards can be stored.
ATTENTION(!) Reader is included in the delivery set of card
collector. Two types of readers can be installed: PROX13 иPROX125.
Customer can choose reader model suitable for the existing system.
7.3. Removing guest cards from card collector
7.3.1. Open the hatch lock of card collector with a key (Fig. 4).
7.3.2. Put a bag to collect cards (not supplied) underneath storage
device.
7.3.3. Lift the storage shutter to remove cards.
7.3.4. Lower the storage shutter and close the hatch with a key.
8. Speedgate operation
8.1. Turning on
Connect power supply units to 220V power network and turn them
on. Wings of speedgate will move to the starting closed position, LED
indication stripes fromn inside and outside will turn blue. Readers of
permanent cards (located on the upper panel) will be lightened with red
color, it means that readers are ready to identify the card. LED indicator of

Operational manual 15
button 2 on the RC panel will turn red (Fig. 3). The speedgate is ready for
operation.
8.2. Operating modes
The speedgate has several modes of operation. The desired mode is
set by using RC panel or proximity cards. Operational modes are displayed
on the panel in the form of mnemonic signs depicting authorization and
non-authorization of passage.
8.3. Control with remote contron board
General view of the RC panel is shown in Fig. 3. Each button is
equipped with the LED indicator displaying operation of the speedgate.
"Stop" mode
Режим «Стоп» устанавливается при включении турникета.
Створки турникета закрыты. Переход из другого режима в режим
«Стоп» осуществляется с помощью кнопки 2, при этом над кнопкой 2
светодиодный индикатор загорается красным.
"Stop" mode is set when the speedgate is turned on. Wings are
closed. Switch from another mode to "Stop" is performed by pressing
button 2, in this case LED indicator above button 2 turns red. In this mode
the passage is non-authorized in both directions.

Praktika QL-04(K) turnstile 16
Both stripes: the inner and outer ones will be of blue color,
permanent card readers (located on the upper panel) will be red.
Single passage mode
Button 1 (3) turns on single passage mode to the left (right). This
mode allowes one pass to the left (right) with a subsequent changing to
"Stop" mode. Green arrow indicator turns on on the display showing a free
passage to the left (right). Green LED indicator on the RC panel turns on
above the button corresponding to the authorized passage and a red
indicator - above button 2. If the passage is not perfromed within 5
seconds, the speedgate switches to "Stop" automatically.
Free passage mode
In order to swich to this mode press and hold button 1, then press
button 3 and release both buttons. In this mode an unlimited number of
passages is allowed in both directions. Arrows turn on in both directions.
Green LED indicators on the RC panel LED turn on above the button 1
and 3.
"Antipanic" mode
This mode is turned on by pressing button 4 while in any other mode.
In this mode the speedgate will open wings towards exit direction. Green
indicator on the RC panel will turn on button 4.
Manual alarm unlock mode
The speedgate has manual disblock of thw swings in case of power
loss. In order to disblock them it’s necessary to (fig.5):
1. Remove the storage device from the inner turnstile stand.
2.Press a leverage with a finger through a hole located on the lower part of
the turnstile’s stand, making draft of speedgate disblock moving.

Operational manual 17
3. Move the swing manually.
Fig.5 Manual disblock
8.4. Adjustment of remote control panel
Speedgate can be set in various directions in relation to the user. In
some cases it is needed to reverse left / right passage buttons. This can be
done by the following operations:
• Power off the speedgate;
• Press and hold left (1) and right (3) buttons;
• Turn on the speedgate;
• Press button 2 while still holding buttons 1 and 3;
• Release buttons 1 and 3;
• Release button 2.

Praktika QL-04(K) turnstile 18
Now when you click left button passage will be allowed to the right
and vice versa. The current functions of the buttons are saved and do not
reset when power is turned off. In order to return to the initial modification
re-do the above sequence.
8.5. Control with card collector
8.5. Control with card collector
The card collector is set in the standby mode after power-up. It is
necessary to present access card to switch the mode.
Passage with permanent cards
When an authorized permanent visitor card is presented to the reader
card collector unlocks the speedgate for the time specified by ACS
controller (depending on the operating mode; for 5 seconds in pulse
mode). During the specified time interval other cards are not accepted.
When the passage is performed or the specified time interval is expired
card collector switches into standby mode and can collect the next card.
Green arrow turns on on the LED panel, indicating the authorization of the
passage.
Passage with guest cards
Guest card shall be inserted into the card hole up to the stop
otherwise it will be ignored. In case the presented card is authorized, the
card collector collects it and then unlocks OD for 5 seconds.

Operational manual 19
Storage device is full
When the storage device is overfilled, the card collector stops
collecting guest cards and provides four short audio signals at intervals of
4 sec., the LED panel flashes red cross indicator at an interval of 4
seconds. Audio signal lasts for 3 minutes; then red cross on LED display
continues single blinks 1 time in 2 sec. Passages with permanent cards are
performed normally. In order to switch the card collector in the standard
operating mode, remove cards from the storage device (see. Article 7.3).
Emergency mode
During the operation of the card collector there might be a situation
when a card or a foreign object becomes jammed by shutter of the card
collector. To resolve such situations is an emergency mode.
Open the hatch of the card collector using the key (Fig. 4);
Press and hold BUT1 button on the board of the card collector (Fig.
5). When the button is pressed shutter is open forcedly and a
continuous audio signal is performed;
Remove the object that impedes the normal operation of the system;
Release BUT1 button and close the hatch with a key.

Praktika QL-04(K) turnstile 20
Fig. 6. General view of board
