Oxgard CUBE C-03 User manual

VOZROZHDENIE LLC
OKPD 2 26.30.50.110
ТU 26.30.50-007-33120038-2017
APPROVED BY
VZR.247800.001 LU
TURNSTILE
MODELCUBE C-03
VZR.247800.001IM
INSTALLATION MANUAL
36 sheets
2020

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
2
CONTENTS
1General Provisions ......................................................................................................................... 4
2Safety precautions.......................................................................................................................... 5
3Preparing the product for installation ........................................................................................... 6
3.1 Procedure for transporting the product to the installation site ................................................. 6
3.2 Rules for unpacking the product............................................................................................. 6
3.3 Rules for visual inspection of the product ............................................................................... 6
3.4 Product installation site requirements..................................................................................... 8
3.5 Procedure for checking compliance of the installation place................................................... 9
4Installation and dismantling of the product ................................................................................ 10
4.1 Equipment required.............................................................................................................. 10
4.2 Installing the product ............................................................................................................ 10
4.3 Dismantling the product........................................................................................................ 14
5Connecting and setting the product............................................................................................ 15
5.1 Power connection................................................................................................................. 18
5.2 Connecting the control panel................................................................................................ 20
5.3 Connecting the access control system (optional).................................................................. 21
5.4 Connecting the control panel to the ACS controller .............................................................. 26
6Comprehensive inspection .......................................................................................................... 29
6.1 Visual inspection and verification of the product readiness for use....................................... 29
7Acceptance of the installed product............................................................................................ 30
APPENDIX A —Brief description of CAN2.0 data bus...................................................................... 31
APPENDIX B —Position of mounting holes relative to the external dimensions of the turnstile . 32
APPENDIX C —Turnstile connection diagram.................................................................................. 33

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
3
This Installation Manual (IM) applies to Turnstile Oxgard CUBE C-03 and
its variants (hereinafter referred to as the product).
Product firmware version:
FW v.d 4
IM defines rules and a procedure for installation and commissioning of the
product.
Before installing the product, please read the Operation Manual
VZR.247800.001 (OM) as well.
Due to constant work on improving the product, changes to its design may
be made which are not represented in this version of product.
The following abbreviations are used in this document:
OM —Operation Manual;
IM —Installation Manual;
PSU - power supply unit;
CP - control panel;
ACS - access control system;
SFAS - security and fire alarm system;
NC - normally closed connection;
NO - normally open connection.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
4
1 GENERAL PROVISIONS
For general safety when assembling and installing the product, take into
account all the recommendations and instructions contained herein.
Before starting installation work, completely de-energize the product.
IT IS FORBIDDEN:
TO INSTALL THE POWER SUPPLY MODULE INSIDE THE BODY OF
THE TURNSTILE AS IT MAY RESULT IN AN INJURY OF THE HUMAN BEINGS
DUE TO AN ELECTRIC SHOCK.
INSTALL THE TURNSTILE OUTSIDE DRY AND HEATED ROOMS.
PREVENT OR ACCELERATE MOVEMENT OF THE TURNSTILE ARMS.
APPLY PASTES AND LIQUIDS CHEMICALLY AGGRESSIVE TO
MATERIALS OF THE HOUSING WHEN CLEANING THE PRODUCT.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
5
2 SAFETY PRECAUTIONS
Installation should be carried out with observance of "Regulations for
Operation of Consumer Electrical Installations" and "Safety regulations for
Operation of Consumer Electrical Installations".
The product should be installed by qualified personnel, trained to work with
electrical devices, instructed on safety when working with electrical installations
with voltages of up to 1000 V.
ATTENTION: FAILURE TO COMPLY WITH THE SAFETY
REQUIREMENTS SPECIFIED IN THIS SECTION CAN RESULT IN DEATH AND
DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF PERFORMANCE
OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT.
ATTENTION: MANUFACTURER WAIVES ANY RESPONSIBILITY
FOR DEATH AND DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF
PERFORMANCE OF THE PRODUCT AND/OR AUXILIARY EQUIPMENT IF
USER FAILS TO COMPLY WITH THE SAFETY REQUIREMENTS SPECIFIED
IN THIS SECTION, AND ALSO VOIDS THE PRODUCT WARRANTY.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
6
3 PREPARING THE PRODUCT FOR INSTALLATION
3.1 Procedure for transporting the product to the installation site
The product in the original package can be transported without limiting the
range by air, closed motor road and rail transport provided it is protected against
direct exposure to precipitation and dust.
In order to avoid condensation of moisture after transportation at negative
temperatures, the product should be held in a room with normal climatic
conditions for 12 hours.
Loading and unloading operations should be carried out in compliance with
safety regulations.
3.2 Rules for unpacking the product
3.2.1 Perform visual inspection of the packaging. There should not be
visible damage on the package.
3.2.2 Open the transportation box, unpack and check completeness of
the product:
1) turnstile post;
2) CP with cable;
3) base cover.
3.3 Rules for visual inspection of the product
3.3.1 Check completeness of the product.
Completeness should be checked according to the
VZR.247800.001Logbook (LB).

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
7
3.3.2 Visually inspect the product. There should not be visible damage
on the product.
3.3.3 If a damage is found, prepare a Claim Report.
3.3.4 Figure 1 –overall dimensions of the turnstile.
Figure 1 –Overall dimensions of the turnstile

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
8
3.4 Product installation site requirements
ATTENTION: TO AVOID WAVING AND/OR OVERTURNING DURING
OPERATION, INSTALL THE PRODUCT SECURELY. IN CASE OF PRODUCT
INSTALLATION ON LOW STRENGTH FLOOR - TAKE MEASURES FOR
FLOORS STRENGTHENING IN THE PLACE OF INSTALLATION.
Figure 2 –when installing the turnstile, it is necessary to consider the
possible free travel of the arm (it makes 6 degrees on each side in "STOP" mode).
Figure 2 –Possible free travel of the arm in "STOP" mode
6 deg

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
9
3.5 Procedure for checking compliance of the installation place
ATTENTION: THE PASSAGE ZONES SHALL BE ARRANGED TO
ALLOW RECORDING OF PASSAGES DURING TURNSTILE OPERATION
UNDER ACS CONTROL AND TO AVOID UNAUTHORIZED PASSAGES.
3.5.1 Figure 3 –turnstile passage zone arrangement and guidelines on
product orientation.
Recommended diagram
Not recommended diagram
Figure 3 –Turnstile passage zone arrangement
NMT 50 mm
1- protection

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
10
4 INSTALLATION AND DISMANTLING OF THE PRODUCT
4.1 Equipment required
Equipment to be used for the turnstile installation:
1) electric perforating machine
2) 12 mm carbide drill bit for drilling anchor holes in the floor (we recommend to use the
anchor with the screw of the FHII 12/15 SK type);
3) S5 key for the screws with an internal hexagon;
4) slot head screwdriver;
5) plumb or level;
6) steel shims for turnstile leveling;
7) round file;
8) side-cutting pliers.
4.2 Installing the product
ATTENTION: CAREFULLY READ THIS SECTION OF THE MANUAL
BEFORE INSTALLING THE PRODUCT
4.2.1 Prepare a horizontal area at the product installation site.
4.2.2 Prepare a chase or cable conduit going from the site to the place
of installation of the PSU, CP and, where necessary, to the ACS and SFAS
connection point.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
11
4.2.3 Turnstile installation site:
Figure 4 –prepare 3 holes (12 mm in diameter) in the floor for the turnstile
stand anchors according to the installation dimensions.
Position of mounting holes relative to the external dimensions of the
turnstile is shown in Appendix B.
The depth of the hole –120 mm, should exceed the anchor length by
5 mm. Insert anchors into the holes.
Figure 4 –Installation dimensions of the turnstile site
SECTION F-F
SCALE 1:2
3 hole

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
12
4.2.4 Figure 4 –cable routing is exercised through hole (1) at the lower
turnstile stand plate.
4.2.5 Lay the PU connection cable, PSU cable and, if provided, the
ACS and OPS cables in the cable conduit or chase.
4.2.6 Install the turnstile stand onto the prepared site.
4.2.7 Route the cables from the CP, PSU and, if necessary, ACS and
SFAS cables into the turnstile body.
Secure the cables with cable ties.
The turnstile stand has a removable stainless steel plate (2) for quick
access to the place where control cables are laid down. To remove the plate,
undo screw (1) and slide the plate up.
Figure 5 –Dismounting of the removable plate of the turnstile stand
1 - screw; 2 - removable plate

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
13
4.2.8 Align the holes in the turnstile stand with the floor anchors
(Figure 6 –1).
Check turnstile verticality in 2 planes, if necessary, use steel shims of
required thickness for the turnstile correct installation.
Figure 6 –Preparation to install the turnstile
Fix the turnstile stand with three screws (Figure 6 –2) by screwing them
into the appropriate anchors using S5 key for the screws with an internal hexagon.
1 - turnstile foundation
2 - screws

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
14
Secure the base cover with the double-sided adhesive tape.
4.2.9 Remove the protective film from the turnstile body.
4.3 Dismantling the product
4.3.1 When sending the product for calibration or repair, the product
should be dismantled as follows:
1) power off the product;
2) disconnect the product from the power supply source;
3) disconnect the cable part of the product from auxiliary cables;
4) remove the product from the installation site.
4.3.2 Before packing, clean the product from dust and dirt.
4.3.3 Put the product in a packing box.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
15
5 CONNECTING AND SETTING THE PRODUCT
Connection of the PSU, CP and ACS is carried out using the control board
located in the block of barrier arms under the safety cover.
To conveniently connect the turnstile and get access to all necessary
contacts, the turnstile should be partially disassembled. This scope of works
includes dismantling of the safety cover.
To do this, it is necessary to undo two screws (Figure 7 –1) and four
screws (Figure 7 –2), smoothly slide the cover up.
Figure 7 –Dismounting of the turnstile safety cover
Slide the cover till the end and free access to the rotation mechanism.
Figure 8 –the appearance of the control board and layout of the
connectors for connecting the PSU, CP, ACS and SFAS is shown.
1, 2 - screws

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
16
Figure 8 –Appearance of the turnstile control board
Figure 8 –The turnstile operating modes are set using the BUT button.
To select the required turnstile mode, it is necessary:
- press and hold the BUT button until a short beep appears. The turnstile
operation mode is selected based on the number of short beeps.
- it is necessary to release the BUT button after the required number of
signals, a long beep, which indicates that the desired mode has been written into
the controller memory, will sound.
- when the power is off, the selected mode is not reset.
Button

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
17
Table 1 shows the turnstile operation modes with different number of
signals after pressing the BUT button.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
18
Table 1 –The turnstile operation mode
No. of
the
turnstile
operation
mode
Number of short beeps after
pressing the BUT button
The turnstile operation mode
0 (simple
press)
Reboot (the mode is similar to turning on/off
of the turnstile)
1
1
Factory reset:
- pulse control mode of the turnstile
- the turnstile enters the "STOP" mode after
being switched on
- the turnstile enters the "ANTIPANIC" mode
when controlled using the ACS, after the AP
and GND contacts get connected
The turnstile is controlled by the control
panel, the status of the buttons is
transmitted to outputs ACCESS OUT (p.
5.4)
2
2
- switching between the impulse and
potential control modes of the turnstile (p.
5.3)
3
3
- the turnstile enters the mode of free
passage to the left after being switched on.
4
4
- the turnstile enters the mode of free
passage to the right after being switched on.
5
5
- activation of the "ANTIPANIC" input after
the AP and GND contacts are
closed/opened
6
6
Disabling/enabling of the panel
7
7
Possibility to switch the relay contacts into
hold or passage counting mode, in
"ANTIPANIC" mode
8
8
- test mode for checking the turnstile
performance
5.1 Power connection
IT IS FORBIDDEN:
TO USE THE POWER SUPPLY UNITS WITH AN OUTPUT CURRENT OF
LESS THAN 1,5 А.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
19
TO CONNECT THE TURNSTILE USING THE POWER CABLE WITH THE
SECTION OF LESS THAN 1.5 MM2WHEN THE LENGTH OF THE SUPPLY
CABLE IS MORE THAN 10 M –IT IS RECOMMENDED TO USE THE CABLE
WITH THE CROSS-SECTION OF 2.5 MM2.
ATTENTION: IT IS NOT RECOMMENDED TO INSTALL POWER SUPPLY
UNIT AT A DISTANCE OF MORE THAN 25 M FROM THE TURNSTILE.
The turnstile is powered by 12 V DC power supply. The maximum
consumption is 1.5 A. The PSU should be selected based on these parameters.
It should also be taken into account that voltage drop increases when the
supply cable length is increased (operating voltage range is detailed in the
Operation Manual VZR.247800.001 (OM)).
Install the PSU in the place providing easy operator access.
Connect the PSU cable to +12U and GND POWER contact group on the
control board. Make sure that the cable is securely connected.
The POWER block has additional power supply terminals for connecting an
external controller.

VZR.247800.001 IM
Turnstile CUBE C-03
Installation Manual
20
5.2 Connecting the control panel
The CP is connected via RJ 11(G)\6P4C telephone socket to X24 socket
with the PULT inscription using RJ12\6P4C telephone socket.
RJ12\6P4C RJ 11(G)\6P4C
Figure 9 –The turnstile CP should be connected based on the contact
identifications in accordance with the figure.
Figure 9 –Arrangement of the control panel cable wires.
Control panel
