V2 City7 User manual

L n. 252
ED Z. 22/06/2011
V2 S.p.A.
Corso Principi di Piemonte, 65/67
12035 RACCON G (CN) TALY
tel. [phone] - fax [phone]
www.remotecontrolgates.co.uk
City7
CENTRA E DI COMANDO ANA OGICA
PER CANCE I A BATTENTE
I
ANA OGUE CONTRO UNIT FOR
SWING GATES
GB
ARMOIRE DE COMMANDE ANA OGIQUE
POUR PORTAI S BATTANTS
F
CUADRO DE MANIOBRA ANA ÓGICO
PARA CANCE AS A BATIENTE
E
QUADRO DE COMANDO ANA ÓGICO
PARA PORTÕES DE BATENTE
P
ANA OGSTEUERUNG FÜR F ÜGE TORE
D
ANA OGE STUURCENTRA E VOOR
HEKKEN MET V EUGE S
N

ENG ISH
13
INDEX
MPORTANT REMARKS ........................................................................................................14
DECLARAT ON OF CONFORM TY ........................................................................................14
DESCR PT ON OF THE CONTROL UN T..................................................................................15
TECHN CAL SPEC F CAT ONS................................................................................................15
NSTALLAT ON......................................................................................................................16
POWER SUPPLY....................................................................................................................16
MOTORS..............................................................................................................................16
BL NKER ..............................................................................................................................16
COURTESY L GHT ................................................................................................................16
PHOTOCELLS ......................................................................................................................17
SAFETY EDGES ....................................................................................................................17
START NPUT........................................................................................................................18
PEDESTR AN START ..............................................................................................................18
STOP....................................................................................................................................18
PLUG- N RECE VER ..............................................................................................................19
EXTERNAL ANTENNA ..........................................................................................................19
ELECTR CAL CONNECT ON TABLE........................................................................................20
ADJUSTMENT OF THE POWER AND OPERAT ONAL T MES....................................................21
CONTROL UN T ND CATORS (LEDS) ....................................................................................21
CABLE GLAND ASSEMBLY....................................................................................................21
PROGRAMM NG THE OPERAT ONAL LOG C ........................................................................22

ENG ISH
14
IMPORTANT REMARKS
For any installation problem please contact our
Customer Service at the number +39-0172.812411
operating Monday to Friday from 8:30 to 12:30
and from 14:00 to 18:00.
V2 has the right to modify the product
without previous notice; it also declines any
responsibility to damage or injury to people or
things caused by improper use or wrong
installation.
mPlease read this instruction manual very
carefully before installing and programming
your control unit.
• This instruction manual is only for qualified
technicians, who specialize in installations and
automations.
• The contents of this instruction manual do not
concern the end user.
• Every programming and/or every maintenance
service should be done only by qualified
technicians.
AUTOMATION MUST BE IMP EMENTED IN
COMP IANCE WITH THE EUROPEAN
REGU ATIONS IN FORCE:
EN 60204-1 (Machinery safety. electrical equipment
of machines, part 1: general rules)
EN 12445 (Safe use of automated locking
devices, test methods)
EN 12453 (Safe use of automated locking
devices, requirements)
• The installer must provide for a device
(es. magnetotermical switch) ensuring the
omnipolar sectioning of the equipment from the
power supply. The standards require a
separation of the contacts of at least 3 mm in
each pole (EN 60335-1).
• After making connections on the terminal
board, use one hose clamp to fix dangerous
voltage wires near the terminal board and
another hose clamp to fix safety low voltage
wires used for accessories connection; this way,
in case of accidental detachment of a
conducting wire, dangerous voltage parts will
not come into contact with safety low voltage
ones.
• The plastic case has an P55 insulation; to
connect flexible or rigid pipes, use pipefittings
having the same insulation level.
• nstallation requires mechanical and electrical
skills, therefore it shall be carried out by
qualified personnel only, who can issue the
Compliance Certificate concerning the whole
installation (EEC Machine Directive
2006/42/CEE, Annex A).
• The automated vehicular gates shall comply
with the following rules: EN 13241-1,
EN 12453, EN 12445 as well as any local rule in
force.
• Also the automation upstream electric system
shall comply with the laws and rules in force
and be carried out workmanlike.
• The door thrust force adjustment shall be
measured by means of a proper tool and
adjusted according to the max. limits, which
EN 12453 allows.
• Connect the earthing lead of the motors to the
electricity grid earth system.
• Observe all necessary precautions (e.g. anti-static
bracelet) for handling parts sensitive to
electrostatic discharges.
DEC ARATION OF CONFORMITY
V2 S.p.A. hereby declare that C TY7 products
conform to the essential requirements established
in the following directives:
-2004/108/CEE (EMC Directive in accordance
with standards EN 61000-6-2, EN 61000-6-3 +
EN 50336)
-2006/95/CEE (Low Voltage Directive in
accordance with standards EN 60335-1 +
EN 60335-2-103)
-99/05/CEE (Radio Directive in accordance with
standard EN 301 489-3)
Racconigi, lì 12/01/2010
V2 S.p.A. legal representative.egale della V2 S.p.A.
Cosimo De Falco

ENG ISH
15
DESCRIPTION OF THE CONTRO UNIT
The C TY7 control unit is an innovative V2 product
guaranteeing safety and reliability for swing gate
automation.
The C TY7 design has been aimed at creating a
product which adapts to suit all needs, thus
obtaining an extremely versatile control unit
satisfying all the necessary requirements for a
functional and efficient installation.
• 230V - 50Hz or 120V - 60Hz power supplies,
depending on the model, for 2 single phase
motors (700W global).
• nput for keyswitch or push-button.
• nput for safety photocell.
• nput for safety edge, capable of handling
standard edges with switch normally closed and
conductive rubber edges with nominal resistance
of 8.2 kOhms.
• Pre-opening safety device testing.
• Dip-switch programmable operational logic.
• Adjustment of motor power and operation time
by means of a trimmer.
• Quick plug-in connector for inserting a Mr1
series receiver.
• LED monitoring of inputs.
• Courtesy light output.
• P55 casing.
TECHNICA SPECIFICATIONS 230V models 120V models
Power supply 230V / 50Hz 120V / 60Hz
Max motors load 700W 700W
Max accessories load 24V 3W 3W
Working temperature -20 ÷ +60 °C -20 ÷ +60 °C
Protection fuse F1 = 5A delayed F1 = 8A delayed
Dimensions 170 x 185 x 70 mm
Weight 800 g
Protection P55

ENG ISH
16
INSTA ATION
nstallation of the control unit, the safety devices and
accessories must be performed with the power
supply disconnected.
POWER SUPP Y
The control unit must be powered by means of a
230 V - 50 Hz or 120 V - 60 Hz power line,
depending on the model, protected by a differential
magnetothermal switch in compliance with legal
regulations.
Connect the power cables to the control unit and
Nterminals.
MOTORS
The control unit can control one or two
asynchronous AC motors. f the control unit is used
to control only one motor, then this must be
connected to the terminals relating to motor 1.
Connect the cables for motor 1 as follows:
• Opening cable to terminal K3
• Closing cable to terminal K5
• Common return cable to terminal K4
• Start-up capacitor between terminals K3 and K5
Connect the cables for motor 2 (if present) as
follows:
• Opening cable to terminal K6
• Closing cable to terminal K8
• Common return cable to terminal K7
• Start-up capacitor between terminals K6 and K8
B INKER
The control unit provides for the use of a 230V -
40W or
120V - 40W blinker with built-in intermittence.
Connect the cables to terminals K9 and K10.
COURTESY IGHT
This output has a normally-open clean contact relay
which closes for approx. 1 second at the start of an
opening phase. This switch may be used to activate
a courtesy light timer (max. load: 230V - 4 A).
P EASE NOTE: f there is no timer, the courtesy
light can be controlled using channel 4 of receiver
MR1: bistable or timer programmable channel (read
the instructions for the receiver MR1 thoroughly).
The switch is on terminals K1 and K2.

ENG ISH
17
PHOTOCE S
The control unit has a 24VAC power supply for
photocells with switch normally closed, and can
perform an operational test before to starting the
gate opening procedure.
The photocell can be used with two settings:
1. Photocell always active:
ntervention of the photocell during opening or
closing causes the gate to stop.
When the photocell restores, the gate re-opens
completely.
2. Photocell NOT active during opening:
ntervention of the photocell during opening is
ignored.
ntervention of the photocell during closing
causes the gate to re-open completely.
ndependently of the setting selected, when the
gate is paused while opening, the time count for
any automatic re-closure will only start after the
photocell restores.
• Connect the photocell transmitter power cables
between terminals 10 (GND) and 11 (+) on the
control unit.
• Connect the photocell receiver power cables
between terminals 10 (GND) and 9 (+) on the
control unit.
• Connect the photocell receiver output between
terminals 6 and 8 on the control unit.
SAFETY EDGES
The control unit has an input for controlling safety
edges; this input is capable of controlling standard
edges with switch normally closed and conductive
rubber edges with nominal resistance of 8.2 kOhms.
Edges can be used with two settings:
1. Edge always active:
ntervention of the edge during opening or
closing causes inversion of the direction of
movement in order to free the body that caused
the edge to intervene.
The gate stops after approx. 3 seconds.
2. Edge NOT active during opening:
ntervention of the edge during opening is
ignored. ntervention of the edge during closing
causes the gate to re-open completely.
ndependently of the settings selected, any
subsequent automatic re-closure will be cancelled.
Standard edge with switch normally closed:
connect the edge cables between terminals 7 and
8 on the control unit.
n order to satisfy the requirements of standard
EN12978, it is necessary to install safety edges with
a control unit which constantly monitors correct
operation. f control units are used with the option
of running tests by means of interrupting the power
supply, connect the control unit power supply cables
between terminals 10 (GND) and 11 (+).
Conductive rubber edge: connect the edge cables
between terminals 7 and 8 on the control unit.
mP EASE NOTE: operational testing on edges is
reserved for standard edges (only if equipped with
suitable control units).
DO NOT enable testing if conductive rubber
edges are used or standard edges used without
a suitable control unit for controlling function.
mNOTE: use the special interface (code 35A024)
for connection of the optical bars, de-activating the
operational test on the bars.

ENG ISH
18
START INPUT
The START input is preset for connecting devices
with the switch normally open.
Function depends on the mode of operation set by
means of dip-switch 4.
Step mode
Subsequent Start command cause, in order:
opening  stop  closure  stop
“ nversion” mode
Start during opening causes closure.
Start during closure causes opening.
Start with the gate open always results in closure;
The only case where this does not occur
immediately is when automatic closure is enabled
and start while opening is not accepted: in this
specific case, start makes the pause time count start
from zero, after which the gate will be re-closed.
n both modes it is possible to disable the Start
command during gate opening by means of
dip-switch 3.
Connect the start input control device cables
between terminals 3 and 8 on the control unit.
PEDESTRIAN START
With the gate closed, the pedestrian start command
causes partial opening (approx. half way) of the
gate leaf connected to motor 1. Subsequent
pedestrian start commands will function according
to step logic.
During a pedestrian cycle, the start command results
in the complete opening of both gate leaves.
Connect the pedestrian start input control device
cables between terminals 4 and 8 on the control
unit.
STOP
The STOP input is intended for devices with the
switch normally closed.
The STOP command causes the immediate stop of
the gate.
A subsequent START command activates the gate in
the opposite direction of movement.
f the STOP command is given during opening or
pause, then there will be no subsequent automatic
re-closure.
Connect the stop input control device cables
between terminals 5 and 8 on the control unit.

ENG ISH
19
P UG-IN RECEIVER
The control unit is suitable for plugging-in an MR1
series receiver with high sensitivity super-heterodyne
architecture.
mP EASE NOTE: Disconnect the power to the
control unit before performing the following
operations. Pay the utmost attention to the
direction of insertion of plug-in modules.
The MR1 receiver module has 4 channels, each with
an associated command on the City7 control unit:
• CHANNEL 1  START
• CHANNEL 2  PEDESTR AN START
• CHANNEL 3  STOP
• CHANNEL 4  COURTESY L GHTS
mP EASE NOTE:
Read the instructions supplied with the MR1
receiver thoroughly for details on programming the
4 channels and the operational logic.
EXTERNA ANTENNA
t is recommended the external antenna be used in
order to guarantee maximum radio capacity.
Connect the antenna hot pole to terminal 1 of the
control unit and the braiding to terminal 2.

ENG ISH
20
E ECTRICA CONNECTION TAB E
1 Antenna
2 Antenna shield
3
Opening command for a standard
connection device with switch
normally open.
4
Pedestrian opening command for a
standard connection device with
switch normally open.
5 STOP command. N.C. switch
6 Photocell. N.C. switch
7 Edge. Switch N.C. or resistive rubber
edge
8 Commands common (-) line
9 - 10 24 VAC power output for photocells
and other accessories
10 - 11 Power supply for functional test TX
photocell
K1 - K2 Courtesy light timer activation switch
K3 Motor 1 open
K4 Motor 1 common
K5 Motor 1 close
K6 Motor 2 open
K7 Motor 2 common
K8 Motor 2 closed
K9 - K10 230V - 40W / 120V - 40W blinker
N230V / 120V power supply - neutral
230V / 120V power supply - phase
J1 NOT USED
P EASE NOTE: If not used, the normally closed
inputs (STOP, PHOTO, EDGE) must be jumpered
with the commands common line COM (-)

ENG ISH
21
ADJUSTMENT OF THE POWER AND
OPERATIONA TIMES
The power and operating times may be adjusted by
means of 4 trimmers located on the control unit:
POWER: motor power.
WORK: motor operating time (2 - 50 seconds).
mP EASE NOTE: it is recommended that
operating times be set with the slow down function
disabled (D P 5 OFF).
mWARNING: the adjustment of times has
to be made when the gate is still
PAUSE: pause time before automatic re-closure
(2 - 150 seconds).
DE AY: time delay between the two gate
leaves (0 - 90 seconds).
CONTRO UNIT INDICATORS ( EDS)
The highlighted boxes indicate the state of the LEDs
when the gate is resting.
ED ON OFF
START START input closed START input open
IN2 START P. input closed START P. input open
STOP STOP input closed STOP input open
PHOTO PHOTO input closed PHOTO input open
EDGE
Standard edge
EDGE input closed (edge not pressed) EDGE input open (edge pressed)
Resistive rubber edge
EDGE input closed (edge pressed)
EDGE input open (fault)
Edge NO pressed: 8K2 between EDGE input
and common (-)
mains Control unit powered-up Control unit NOT powered-up
overload Accessory power supply overload Accessory power supply within normal
operational limits
CAB E G AND ASSEMB Y
The casing can accept 4 cable glands in the special
easy-break housings.
The type of cable gland is indicated in the figure.
mP EASE NOTE:
• Remove the electronic circuit board before drill
the casing.
• Drill the container using a suitably sized cutter,
according to the dimensions of the cable gland.
• Fix the cable glands using the special nuts.

ENG ISH
22
PROGRAMMING THE OPERATIONA OGIC
t is possible for the control unit to use several different operational logic states, by simply moving the dip-
switches located on the card. The functions associated with each individual dip-switch are listed below.
DIP FUNCTION SETTING DESCRIPTION
1Pre-flashing
ON Disabled The blinker is switched on when the motors are started
OFF Enabled The blinker is switched on for 2 seconds before the motors are
started
2Automatic
closure
ON Enabled The gate is closed automatically after the period of time set by
the PAUSE trimmer
OFF Disabled On completion of the opening step, the gate remains open. t is
necessary to instruct closure with another START command
3Start opening ON Not accepted Any START command issued during opening is ignored
OFF Accepted Any START command issued during opening is accepted
4Operational
logic
ON nversion Start during opening causes closure.
Start during closure causes opening.
OFF Step Commands subsequent to starting cause, in order:
open  stop  close  stop...
5Slow down ON Enabled At the end of each opening and closing step, the motors slow
down in order to avoid noisy closure and bouncing.
OFF Disabled
6Start off ON Disabled At the start of each opening and closing step, the motors are
started at maximum power
OFF Enabled
7Anti-slip
ON Disabled
The time used for opening or closure will always be the value set
by the WORK trimmer, even if the previous operation has been
interrupted before the expiry of such time.
OFF Enabled
When an opening (or closing) operation is interrupted before
expiry of the set time (for example due to the intervention of one
of the safety devices or due to a start command), the duration of
the subsequent closing (or opening) operation will not be that
set by the WORK trimmer, but will be equal to the time
effectively elapsed, plus a short supplemental time in order to
compensate for the inertia of the gate.

ENG ISH
23
DIP FUNCTION SETTING DESCRIPTION
8Photocell
ON Always active
ntervention of the photocell during opening or closing
causes the gate to stop. When the photocell restores, the
gate re-opens completely.
OFF NOT active
during opening
ntervention of the photocell during opening is ignored.
ntervention of the photocell during closing causes the gate
to re-open completely.
9Photocell test
ON Enabled The control unit performs a photocell operational test before
starting each opening or closing operation. f the photocells
are not operating correctly, the gate does not begin to move
and the light flashes for approx. 8 seconds.
P EASE NOTE: connect the photocell TX correctly
OFF Disabled
10 Safety edge
type
ON Conductive
rubber edge
Select this option if using conductive rubber edges with
nominal resistance of 8K2.
OFF Standard or
optical edge
Select this option if using standard edges with switch
normally closed or optical edges.
11 Safety edge
ON Always active
ntervention of the edge during opening or closing causes
inversion of the direction of movement in order to free the
body that caused the edge to intervene. The gate will be
stopped after approx. 3 seconds.
OFF NOT active
during opening
ntervention of the edge during opening is ignored.
ntervention of the edge during closing causes the gate to be
re-opened completely.
12 Safety edge
test
ON Enabled The control unit performs an operational test on the edges
before starting each opening or closing operation. f the
edges are not operating correctly, the gate does not begin to
move and the light flashes for approx. 8 seconds.
DO NOT enable testing if conductive rubber edges are
used or standard edges are used without a suitable
control unit for controlling function.
OFF Disabled
