aivituvin AIR 24 User manual

INSTRUCTION
MANUAL
AIR 24
www.aivituvin.com

Please retain these instructions for future reference.
NOTICE
Firmly secure all bolts,screws and knobs before use.
Reconfirm that all bolts,screws,and knobs are secure every 90
days.
Fasten screws loosely during initial assembly. Do not fully
tighten screws until the item is completely assembled.
Do not use or store this item in the proximity of open flame or
flammable/combustible chemicals.
Be aware that some parts are heavy and have sharp edges.
Be aware that moving parts can injure,crush and cut.
If any parts are missing,broken,damaged,or worn,stop using
this product until repairs are made and/or factory replacement
parts are installed.
01
Do not use this item in a way inconsistent with the manufacturer’
s instructions as this could void the product warranty.

TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
DRILL
(RECOMMENDED)
2PERSON
ASSEMBLY
APPROXIMATELY
45MIN. ASSEMBLY
HARDWARE
P1 P2
02
M3.5x35mm SCREW
M3.5x45mm SCREW
12PCS+1spare 4PCS+1spare
P3 P4
M3.0x16mm SCREW
M3.5x20mm SCREW
2PCS+1spare 8PCS+1spare
P5 P6
Chewing toy
M3.0x10mm SCREW
2PCS+1spare 1PC
P7
Lock
1PC
P8
M3.0x16mm SCREW
4PCS+1spare

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
BC
DE
1PC
1PC 1PC
03
1PC
1PC
Front panel
Back panel Side panel of wooden
hutch
Middle panel of wooden
hutch
Side panel of pen
F
1PC
Floor of wooden hutch
G H
1PC
1PC
Roof of pen
Wire floor
I
1PC
Plastic tray
A

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
J K L
MN
1PC
2PCS 2PCS
04
2PCS
1PC
Wooden roof
Brake casters Casters without brakes
Roof cap
Folding metal feeder
O
1PC
Wire floor supporter

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
05
Pen
Hutch

PRODUCT ASSEMBLY
01
02
06
①Attach the back panel Part B by 2xP1 at each side and 2xP2 at
the middle.
①Attach the side panel Part E & Part C to the front panel Part A by
2xP1 each.
②Attach the middle panel Part D to the front panel Part A by 2xP2.
P
1
X
B
2
D
C
P
1
X
2
A
P
1
X
2
P
1
X
2
E
P
2
X
2
②Insert the wire floor suppoter Part O into the slots inside the front
and back panel.
O
P
2
X
2

PRODUCT ASSEMBLY
03
07
①
②
③
Put the wooden floor Part F into the wooden hutch.
Put the wire floor Part H into the pen.
Slide in the plastic tray Part I.
P1
X4
H
04
①
②
③
④
Attach the pen roof Part G by 4xP1.
Screw the lock P7 to the side of pen by 4xP8.
Screw the folding metal feeder Part N by 2xP5.
Put inside the chewing toy P6.
N
F
I
P6
X1
P5
X2
G
P7
X1
P8
X4

PRODUCT ASSEMBLY
05
08
Attach the wodden roof Part J by 2xP4 each.
P4
X2
P4
X2
Jx2

PRODUCT ASSEMBLY
06
09
①
②Screw in the casters Part L & K to the legs.
Screw the roof cap Part M by 2xP3.
P3
X2
Kx2
LOCKED
OPEN
Finish
Lx2
M

WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury,property
damage or loss,whether direct,indirect,or incidental,resulting from the incorrect
attachment,improper use,inadequate miantenance,or neglect of this product.
