aivituvin AIR06-C User manual

INSTRUCTION
MANUAL
AIR06-C
www.aivituvin.com
X

Please retain these instructions for future reference.
NOTICE
Firmly secure all bolts,screws and knobs before use.
Reconfirm that all bolts,screws,and knobs are secure every 90
days.
Fasten screws loosely during initial assembly. Do not fully
tighten screws until the item is completely assembled.
Do not use or store this item in the proximity of open flame or
flammable/combustible chemicals.
Be aware that some parts are heavy and have sharp edges.
Be aware that moving parts can injure,crush and cut.
If any parts are missing,broken,damaged,or worn,stop using
this product until repairs are made and/or factory replacement
parts are installed.
01
Do not use this item in a way inconsistent with the manufacturer’
s instructions as this could void the product warranty.

TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
DRILL
(RECOMMENDED)
2PERSON
ASSEMBLY
APPROXIMATELY
45MIN. ASSEMBLY
HARDWARE
P1 P2
P3 P4
P5
02
M3.5x60mm SCREW
M3.5x40mm SCREW
M6.0x50mm BOLT
9PCS+1spare
3PCS+1spare
16PCS+1spare
P6
2PCS+1spare
M3.5x35mm SCREW
11PCS+1spare
M3.5x25mm SCREW
5PCS+1spare
M3.5x20mm SCREW
P7
18PCS+1spare
P8
M3.0x16mm SCREW
2PCS+1spare
M3.0x10mm SCREW

HARDWARE
P9 P10
P11 P12
0 3
1PC
2PCS
M3.5x20mm SCREW
4PCS+1spare
1PC

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
A B C
D E F
G
1PC
1PC 1PC
04
HI
2PCS
1PC
1PC
1PC
1PC
Left side panel
Front upper panel
Front down panel Back upper panel
Right side panel
Back down panel
1PC
Upper plastic tray Down plastic tray Upper divider

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
J K L
MNO
P
1PC
1PC 1PC
05
QR
2PCS
1PC
1PC
1PC
1PC
Supporter of ramp
Down divider
Supporter of tray Upper ramp
Platform
Down ramp
2PCS
Roof Casters without brake Brake casers

PARTS
A B C
C1 D E
F
Side panel
1PC
Bottom panel
1PC
Bottom panel
1PC
Asphalt roof
1PC
1PC 1PC 1PC
S
1PC
06
Folding metal feeder

PRODUCT ASSEMBLY
01
02
07
Attach the side panel Part E & F to the back by 8xP4.
①Connect the back Part C & D by 5xP6.
②Screw the ramp supporter Part N to the down panel Part D by
2xP4.
P6X
5
P4X
8
E
F
C
D
N
P4X
2

PRODUCT ASSEMBLY
03
04
08
Attach the platform Part O to the left side panel by bolt 2xP1.
Fix the platform from back side by bolt 1xP1.
P1
X2
O
P1
X1

PRODUCT ASSEMBLY
05
06
09
①Attach the front Part A & B to the sides by 8xP3.
②Fix Part A & B by 2xP2.
①Insert the divider Part J to the down level.
②Slide in the down plastic tray Part H.
J
H
P
2
X2
A
B
P
3
X8

PRODUCT ASSEMBLY
07
08
10
①Insert the tray supporter Part K to upper layer.
②Fix the Part K from front side by 1XP3.
Fix the Part K from back side by 1XP4.
Screw the ramp Part M to the platform by 2xP7.
①Insert the dividers Part I to the upper level.
②Slide in the upper plastic tray Part G.
Ix2
P
7
X2
G
M
K
P
3
X1
P
4
X1
③
④

PRODUCT ASSEMBLY
09
10
11
①Screw the upper ramp Part L by 2xP7.
②Put the chewing toy P10 into the hutch.
Attach the folding metal feeder Part S to the hutch by 2xP8.
L
P8
X2
P
10
X1
S
P
7
X2

PRODUCT ASSEMBLY
11
12
12
Screw two casters without brake Part Q to the front of hutch legs
by P5x8.
Screw two brake casters Part R to the back of hutch legs by P5x8.
Qx2
P
5
X8
Rx2
P
5
X8

PRODUCT ASSEMBLY
13
14
13
Attach the roof Part P to the hutch by 6xP7.
①Attach the roof hinge P9 with 4xP7 each.
②Attach the lock P11 by 4xP12.
P
7
X6
P
9
X2
P
P
7
X8
P
11
X1
P
12
X4

WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury,property
damage or loss,whether direct,indirect,or incidental,resulting from the incorrect
attachment,improper use,inadequate miantenance,or neglect of this product.
