FAR Rac 83 Setup guide


TRANSLATION OF ORIGINAL INSTRUCTIONS
PNEUMATIC RIVETING TOOL
FOR RIVETS Ø 2.4 ÷ Ø 4.8
(Ø 4.8 ALUMINIUM ONLY)

www.air-allied.com.au
[email protected] www.air-allied.com.au

(Chairman of the Board of Directors)
Far S.r.l. – Giacomo Generali
www.air-allied.com.au
[email protected] www.air-allied.com.au
Quarto Inferiore, 23-03-2010
The undersigned Far S.r.l., having its office in Quarto lnferiore ( BO ) , Via Giovanni XXIII No. 2, herewith
DECLARES
on its sole responsibility that the riveting machine
Type: RAC 83/95 - Pneumatic tool Application: for rivets diameter. 2.4—4.8 mm (4.8 aluminum only)
which is th e objec t o f thi s declaratio n complies wit h th e basic safety requirements established in
the law decree Leg. D. 17/2010 of Machinery Directive 2006/42/CE acknowledge and subse-
quent amendments and integrations.
Th e person who is authorize d t o creat e the technica l brochure is
Giacomo Generali, c/o Far S.r.l., head office in Quarto lnferiore (BO), via Giovanni XXIII n. 2.

CodeLØ DØ A ÷
7170018.52.251.7 ÷ 2.1
717002102.72.15 ÷ 2.4
71700311.23.12.6 ÷ 2.75
71700412.53.42.9 ÷ 3.2
7170051443.4 ÷ 3.5
71700671.91.43
GENERAL NOTES AND USE
The too l must be used for rivets diam. 2.4 - 4.8 mm only.
Diameter is 4.8 mm only in aluminum.
[email protected] www.air-allied.com.au
Follow the prescriptions of the national laws for disposing of the riveting tool.
After disconnecting the tool from the pneumatic system, disassemble and split all the components according to the
material: steel, aluminium, plastic material, etc.
Then proceed to scrap the materials in accordance with current laws.
DISPOSAL OF THE RIVETING TOOL

INSTRUCTIONS FOR USE
INDEX
GUARANTEE 4
SAFETY MEASUREMENTS & REQUIREMENTS 4
MAIN COMPONENTS 4
TOOL IDENTIFICATION 5
TECHNICAL DATA 5
MAINTENANCE & CHANGE OF SIZE 5
GUARANTEE
FAR riveting tools are covered by a 12-month warranty.
The tool warranty period starts on the date of delivery to
the buyer, as specified in the relevant document. The war-
ranty covers the user/buyer provided that the tool is pur-
chased through an authorized dealer and only if it is used
for the purposes for which it was conceived. The warranty
shall not be valid if the tool is not used or maintained as
specified in the instruction and maintenance handbook. In
the event of defects or failures, FAR S.r.l. shall undertake
solely to repair and/or replace the components it judges to
be faulty.
• The workbench and the work surface must be always
clean and tidy. The untidy can cause damages to people.
• Do not allow unauthorized persons to use the working
tools.
• Make you sure that the compressed air feeding hoses
have the correct size to be used.
• Do not carry the connected tool by pulling the hose. The
hole must be far from any heating sources or from cutting
parts.
• Keep the tools in good conditions; do not remove either
safety parts or silencers.
• After repairing and/or adjusting, make sure you have al-
ready removed the adjusting spanners.
• Before disconnecting the compressed air hose from the
tool make sure that there is no pressure in the hose.
• These instructions must be carefully followed.
A)Nozzle
B)Balancerconnecon
C)Tensilestrengthtrigger
D)Compressedairconnecon
E)Headcarringnozzle
MAIN COMPONENTS
[email protected] www.air-allied.com.au
SAFETY MEASURES & REQUIREMENTS
CAUTION!!!
All the operations mustbe done in conformitywith
the safety requirements, in order to avoid any
consequence for your and other people’s security
and to allow the best tool work way.
• Read the instructions carefully before using the tool.
• For all maintenance and/o r repairs please contact FAR
s.r.l. authorized service centers and use only original
spare parts. FAR s.r.l. may not be held liable for dam-
ages from defective parts caused by failure to observe
what above mentioned (EEC directive 85/374).
• The tool must be used only by expert workers.
• A protective visor and gloves must be put on when using
the tool.
• Use equipment recommended in the maintenance chapter
to do any maintenance and/or regulation of the tool.
• For topping up the oil, we suggest using only fluids in ac-
cordance with the features specified in this working book.
• If any drop of oil touches your skin, you must wash with
water and alkaline soap.
• The tool can be carried and we suggest putting it into its
box after using.
• The tool needs a thorough six-monthly overhaul.
• Repairing and cleaning operations must be done when
the tool is not fed.
• If it is possible, we suggest a safety balancer.
• If the A-weighted emission sound pressure level is more
than 70 dB (A), you must use some hearing protections
(anti-noise headset, etc.).

TOOL IDENTIFICATION
The riveting tool RAC 83 AX is identified from a marking
that shows company name and address of manufacturer,
designation of the tool, CE mark and year of manufactur-
ing. If any service is requested, please make reference to
the data shown on the marking.
TECHNICAL DATA
 Working pressure 6 BAR
 Min. int. diam. Of the compressed air feed-
ing hose Min. diam =
8 mm
 Air consumption per cycle 2.2 NI
 Maximum force 6 BAR –
5372 N
 Weight 1.74 Kg
 Working temperature -5°/+50°
 Root mean square in total acceleration fre-
quency (Ac) to which the arms are subjected 3.3 m/s²
 A-weighted emission sound pressure level 86 dBA
 Peak C-weighted instantaneous sound pres-
sure <130 dBC
 A-weighted emission sound pressure 94 dBA
AIR FEED
The air feed must be free from foreign bodies and humidity in
order to protect the tool from premature wear and tear of the
components in movement, therefore we suggest to use a lubri-
cator group for compressed air.
MAINTENACE AND CHANGE OF SIZE (fig. f1)
The extended utilization of the riveting tool can cause the slip-
ping of the clamps on the nail due to the deposited impurities.
For this reason, it is necessary to lubricate the clamps after
having cleaned them. However, if clamps are worn out and as
a consequence their working is jeopardized, replace them.
First remove the head which carries the nozzle (E), by means
of a standard spanner of 27 mm. Then, by using two spanners
of 15 mm and 16 mm, remove the chuck (F) and extract the
clamps (G).
When replacing the nozzle (A), we recommend to use a12-mm
standard spanner and fit the removed nozzle in the proper
housing located on the bottom of your riveting tool, in order to
avoid losing the nozzle.
[email protected] www.air-allied.com.au
WARNING!
Disconnect air feed when performing those
operations.
